Old 08-05-2015, 01:45 AM   #4141
Elite Member

Join Date: Oct 2013
Location: Cedar City, UT
Posts: 2,769
Total Cats: 947
Default

It also doesn't help it is 110 outside as well
Jeffbucc is offline   Reply With Quote
Old 08-05-2015, 01:54 AM   #4142
Junior Member

Join Date: Jan 2014
Location: Finland
Posts: 79
Total Cats: -10
Default

It isn't just the temperature, it's the pressure. If you motor is healthy and it's not generating pressure to the coolant the only cause for boiling water in the expansion tank is a broken radiator cap that can't hold the pressure.
Vuti is offline   Reply With Quote
Old 08-05-2015, 09:05 AM   #4143
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,852
Total Cats: 2,125
Default

Yeah I'm not sure an oversized tank is the solution, because I've never seen that needed on high hp cars before. But iono

In fact just this Friday I beat on a turbo miata with a TSE rad and stock overflow, in 90-100F heat, and nothing boiled over or overflowed.
18psi is offline   Reply With Quote
Old 08-05-2015, 09:38 AM   #4144
FAB
Fab9Tuning.com
iTrader: (4)

FAB's Avatar

Join Date: Apr 2013
Posts: 935
Total Cats: 397
Default

This could also be a sign of air in the system - Air is way more effected by thermal expansion than liquids, giving you the exact side effects you're having.

That being said, if the previous expansion tank was suited to an OEM sized cooling system and you've increased capacity. It might not be a bad idea to go bigger as a lot can be said about properly matching expansion tanks, but I'd first work on properly burping the car. I ended up purchasing an AIRLIFT Coolant Bleeder system, it creates vacuum in the system and then sucks the coolant into the negative pressure areas. That being said, I run a rear mount radiator and an electric water pump so it might be overkill for you but it would certainly cross that off your list. I don't mind sending it out to you, just get it back to me in working order.

Edit: There is absolutely something to be said about the importance of your radiator cap and coolant mixture. You can increase the boiling point of water by nearly 50 degrees by simply pressurizing it properly. Furthermore you can increase boiling point by running the proper mixture of antifreeze. I'm sure we've all heard "run water, it runs cooler" - this is true water will dissipate heat more quickly but it will also boil sooner. (Note: some of us are required to run just water depending on where you're running your car, coolant is slippery)

For every additional pound your cap is rated for the boiling of point of the mixture raises 3 degrees. If you had plain water in your cooling system with a 15 pound pressure cap water would boil at 257 degrees. If you had a 50/50 mix of antifreeze and water the coolant would boil at 265 degrees with the same cap rating.

Bottom line - if you're boiling before your car is overheating you have at least one of the following happening: Air in the system or a weak rad cap. I had both of these issues, along with an expansion tank that was smaller than OEM on a system with nearly double the capacity.

Last edited by FAB; 08-05-2015 at 10:04 AM.
FAB is offline   Reply With Quote
Old 08-05-2015, 12:16 PM   #4145
Elite Member

codrus's Avatar

Join Date: Mar 2007
Location: Santa Clara, CA
Posts: 3,189
Total Cats: 250
Default

Quote:
Originally Posted by FAB View Post
This could also be a sign of air in the system - Air is way more effected by thermal expansion than liquids, giving you the exact side effects you're having.
Yeah, did you bleed it with the big yellow funnel? Getting all the air out of the TSE rad can be tricky.

--Ian
codrus is offline   Reply With Quote
Old 08-05-2015, 12:47 PM   #4146
Elite Member

DNMakinson's Avatar

Join Date: Jan 2013
Location: Seneca, SC
Posts: 2,033
Total Cats: 185
Default

<p>
Quote:
Originally Posted by FAB View Post
I ended up purchasing an AIRLIFT Coolant Bleeder system, it creates vacuum in the system and then sucks the coolant into the negative pressure areas.
</p><p>+1 for a vacuum purge system. Suck, Fill, Drive.</p><p>&nbsp;</p>
DNMakinson is offline   Reply With Quote
Old 08-05-2015, 12:47 PM   #4147
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 11,816
Total Cats: 479
Default

A big tank is a load of bull ****.

If there's boiling water in the line going to the tank, there's going to be boiling water in that line whether its 1 cup or 1 million gallons on the other side of the line.

Stop dicking around and pressure test the system, if it holds pressure to whatever your cap is rated to, something else is going on. If not, it's the cap.
curly is offline   Reply With Quote
Old 08-05-2015, 01:19 PM   #4148
FAB
Fab9Tuning.com
iTrader: (4)

FAB's Avatar

Join Date: Apr 2013
Posts: 935
Total Cats: 397
Default

Quote:
Originally Posted by curly View Post
A big tank is a load of bull ****.

If there's boiling water in the line going to the tank, there's going to be boiling water in that line whether its 1 cup or 1 million gallons on the other side of the line.

Stop dicking around and pressure test the system, if it holds pressure to whatever your cap is rated to, something else is going on. If not, it's the cap.
Not complete bullshit but I agree with you. I'm sure he has air in the system and doesn't need a bigger tank. To determine the proper expansion/overflow size you would take the total volume of coolant, and multiply it by the expansion rate of the mix you're using. Then make your tank bigger than that. The reason the large overflow solves his problem for now is related to the air expanding in the system, thus increasing the expansion rate of his mixture.
FAB is offline   Reply With Quote
Old 08-05-2015, 01:29 PM   #4149
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,852
Total Cats: 2,125
Default

I've seen cars with 4-5x the power a turbo miata makes, and cooling systems with twice more capacity, and still they didn't run a bigger tank than stock (which also happens to be not bigger than a stock miata tank).

So yeah, to beat the dead horse for the last time: burp the system. If that doesn't help then pressure test.
18psi is offline   Reply With Quote
Old 08-05-2015, 02:10 PM   #4150
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 13,738
Total Cats: 982
Default

Quote:
Originally Posted by Jeffbucc View Post
Sadly or annoyingly the TSE cap is not your standard cap.
Standard radiator cap for a ~2004 Dodge 2500 Cummins. Available at any auto parts store.

e: I've been racing N/A and turbo cars on our radiator for 6 years. I have never once boiled the system over or seen any need for a larger coolant overflow tank. Consider my extensive experience in varied applications with this specific radiator before you go and design a part that isn't going to fix the problem you have
Savington is online now   Reply With Quote
Old 08-12-2015, 01:22 PM   #4151
Elite Member

Join Date: Oct 2013
Location: Cedar City, UT
Posts: 2,769
Total Cats: 947
Default

Looks like the radiator cap was indeed the issue. no boiling, gurgling, or overflowing the overflow tank now. Temps hold steady at 192 when moving now even with it being 105 outside.

Followed Revlimiter's very detailed advice and managed to get all the air out of the system after several several thermostat cycles and with the aid of some very tall truck jack stands to get the front up as high as I could.

Also decided to put a 13" SPAL fan in place of my OEM fan. Bryan obliged and sent me a package...I had to leave the bakery from laughing so hard at the name on the package.



Also finally got a real coolant and oil temp gauge from VDO. Going to see if I can fit them in the factory coolant temp and oil pressure gauge spots.

Decided to get a new exhaust manifold gasket as well. I reused my old one as my flawed reasoning thought that it hadn't been on the head long so I would be ok using it again.

I'm slowly trying to eliminate variables on my slower spool. 4k rpms is just too slow. No leaks at the manifold to turbo vband, downpipe, or EWG. Going to play around with a MBC to see if something is up with my solenoid. We'll see, slowly but surely I'll figure it out.
Attached Thumbnails
93' Miata stolen and flipped build thread-nvvxytr.jpg
Jeffbucc is offline   Reply With Quote
Old 08-12-2015, 01:50 PM   #4152
Junior Member

Join Date: Jan 2014
Location: Finland
Posts: 79
Total Cats: -10
Default

So you took off the head because of a faulty radiator cap?
Vuti is offline   Reply With Quote
Old 08-12-2015, 02:09 PM   #4153
Elite Member

Join Date: Oct 2013
Location: Cedar City, UT
Posts: 2,769
Total Cats: 947
Default

Quote:
Originally Posted by Vuti View Post
So you took off the head because of a faulty radiator cap?
Well only partially did my stupidity apply to that logic. Mostly I was concerned it was necessary due to my head studs only being torqued to 30 ft lbs.

But looking back, I'm mildly annoyed at myself for ignoring the radiator cap. Lesson learned I guess.

Gotta remember I'm no pro at all this stuff. I'm figuring it out as I go. Throughout the entire car build I never once touched the engine.
Jeffbucc is offline   Reply With Quote
Old 08-12-2015, 02:17 PM   #4154
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,852
Total Cats: 2,125
Default

plus it gave him a reason to polish the inside of his engine
18psi is offline   Reply With Quote
Old 08-12-2015, 02:20 PM   #4155
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,062
Total Cats: 815
Default

Polishing the rods and crank will reduce stress risers thus making them stronger, plus the oil won't cling to them thus lightning the rotating assembly. Polishing the inside of the block itself will help the oil return to the pan too.

Do it Jeff, polish ALLTHETHINGS inside of the block.
EO2K is offline   Reply With Quote
Old 08-12-2015, 02:21 PM   #4156
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,852
Total Cats: 2,125
Default

There is actually a guy on youtubez that does this /\
Successfully.
And then coats it in some anti-friction coating or something.
He must be Jeff's grandfather
18psi is offline   Reply With Quote
Old 08-12-2015, 02:32 PM   #4157
FAB
Fab9Tuning.com
iTrader: (4)

FAB's Avatar

Join Date: Apr 2013
Posts: 935
Total Cats: 397
Default

Also if I recall you had oil in your coolant? I'd say between that and your stud torque (with mileage), a head gasket was in order.
FAB is offline   Reply With Quote
Old 08-12-2015, 02:57 PM   #4158
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 5,845
Total Cats: 559
Default

+1. Oil in coolant = HG.

Localized boiling due to inadequate radiator cap, low stud torque and dyno tuning likely caused the HG failure.

It's all good and we're one step closer to pictures of a fully-polished interior on a BP.
hornetball is offline   Reply With Quote
Old 08-12-2015, 04:59 PM   #4159
Elite Member

Join Date: Oct 2013
Location: Cedar City, UT
Posts: 2,769
Total Cats: 947
Default

Guys don't jinx the block now....I'm sure I'd enjoy polishing all the internals, but the only items I have yet been forced to "fix" are the block, transmission, and differential and suspension. Let's leave those happily untouched!

Bryan/Hornet bring up a good point, the oil in the coolant proved the HG job was not all for naught.

Vlad are you talking about that red rubber like coating the miata guy on youtube coated his block/head with?
Jeffbucc is offline   Reply With Quote
Old 08-12-2015, 05:04 PM   #4160
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,852
Total Cats: 2,125
Default

yeah
