Old 01-29-2016, 03:18 PM   #421
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

I thought we decided req fuel doesnt really matter, its just a scalar. Set it to whatever floats your boat.

Flex fuel is easy. cut the return line and stick it in the middle.
aidandj is offline   Reply With Quote
Old 01-29-2016, 03:18 PM   #422
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

Are you sure about that. The inlet and outlet are different sizes.

I was attempting to use the scaler value for useful fuel changes, we all know how useless that is on changing injectors. Same **** on fuel types, another reason not to bother with flex sensor on MS2...
deezums is offline   Reply With Quote
Old 01-29-2016, 03:19 PM   #423
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

Inlet and outlet of what? Thats where i'm installing mine, and where yank installed his.
aidandj is offline   Reply With Quote
Old 01-29-2016, 03:23 PM   #424
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

The inlet and outlet of the cheap flex fuel sensor are different sizes, aren't they?
deezums is offline   Reply With Quote
Old 01-29-2016, 03:23 PM   #425
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

Mine aren't. 3/8 on both sides.
aidandj is offline   Reply With Quote
Old 01-29-2016, 03:29 PM   #426
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

Wonder why I thought they were different?

Oh well
deezums is offline   Reply With Quote
Old 01-29-2016, 03:30 PM   #427
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

As long as they are both bigger or equal to 5/16ths i dont see an issue
aidandj is offline   Reply With Quote
Old 01-29-2016, 05:49 PM   #428
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

Upon further maths, I don't believe my warb 190 HP is up to 5.0 bar. It's probably not even up to 4.0 bar.

Numbers..

.91BSFC for e85, 350hp for 80%dc at crank, ~318lbs/hr

318lbs/hr / 6.59lbs/gal = ~49gal/hr

72psi + 10-14 pounds of boost = ~90psi at WOT

Warb 190HP@90psi = 25gal/hr

lolol, the **** am I even doing

75psi max rail at 4.0 bar is 31gal/hr. This would explain why I'm getting stupid high VE values in boost, my dumbass little fuel pump is sucking at sucking.



Whatever, I have a reverse rising rate FPR till I buy a fuel pump.

Spoonfeed, what does 50gal/hr at 90psi plz? Warb 255hp too small, maybe two cheap pumps?

Warb makes an e85 pump that flows 61 gallons/hr at 90 psi, but eats nearly 20 amps.

lol

Last edited by deezums; 01-29-2016 at 06:01 PM.
deezums is offline   Reply With Quote
Old 01-29-2016, 05:51 PM   #429
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

walbro 450. /thread :P

I doubt a 255 will struggle.
aidandj is offline   Reply With Quote
Old 01-29-2016, 06:07 PM   #430
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

If I get the warb 450 I wonder what kind of whining I'll ha e to deal with, like a supercharger I bet...

Deatchworks 300? It'll be quiet right? Nearly double the price...
deezums is offline   Reply With Quote
Old 01-29-2016, 06:08 PM   #431
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

A walbro 255 will be fine.
aidandj is offline   Reply With Quote
Old 01-29-2016, 06:09 PM   #432
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,425
Total Cats: 2,034
Default

dw200
18psi is offline   Reply With Quote
Old 01-29-2016, 06:10 PM   #433
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

Warb 255HP is only good for 32 gal/hr at 90psi, and that's before pumping losses. DW200 is 170lph/44gph, pretty close.

I'm sure I could tune around it, but I want 90psi at WOT because one of the sponsors said it's good...
deezums is offline   Reply With Quote
Old 01-29-2016, 06:12 PM   #434
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

I hope to install my walbro450 soon. I'll let you know.

I also ordered a connector from racetronix that is e85 compatible. And a new oem pickup sock.

If you install it before me please post pics.
aidandj is offline   Reply With Quote
Old 01-29-2016, 06:12 PM   #435
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,425
Total Cats: 2,034
Default

I'll come back in 10 pages of ADHD banter to tell you to get dw200 again
18psi is offline   Reply With Quote
Old 01-29-2016, 06:13 PM   #436
SOMEOFIT
iTrader: (1)

Girz0r's Avatar

Join Date: Jun 2014
Location: Austin, TX
Posts: 2,573
Total Cats: 224
Default

Taking notes...

Attached Thumbnails
"After failed abortion, deezums sees the 1.8 light" Build-maurice-moss-eating-popcorn-crowd.gif
Girz0r is online now   Reply With Quote
Old 01-29-2016, 06:14 PM   #437
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

But DW200 will drop pressure if I try and run 90psi at WOT...

Well, it probably will be fine since my 50gph calc is off 350hp, but then it will be running 100% wide open. Wouldn't it be wise to oversize the pump, make sure pressure never fails?

I might make some fuel tight passthrus if i go with the warb, I have an easy-ish leakproof idea.
deezums is offline   Reply With Quote
Old 02-05-2016, 07:40 PM   #438
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

So I have a local friend with a 95 1.8 block, a 95 BP05 head, and a 99 BP4W head. He says the 99 head won't fit the 95 block, but that's not right, right?

What's the deal? I haven't seen anything in person yet, so kinda at a loss.
deezums is offline   Reply With Quote
Old 02-05-2016, 07:40 PM   #439
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,208
Total Cats: 976
Default

Friend is wrong
aidandj is offline   Reply With Quote
Old 02-05-2016, 07:42 PM   #440
Sadfab Union President
Thread Starter
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 114
Default

Any reason why he might be having problems? The head just got gone over, so I doubt it has dowels or anything stuck in it?

Donno, might have to drive and go look for myself.
deezums is offline   Reply With Quote
