Old 07-21-2012, 01:57 AM   #361
A living god
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 5,934
Total Cats: 222
Default

Purple! In honor of FAILflora cuts/welds
viperormiata is offline   Reply With Quote
Old 07-21-2012, 07:28 PM   #362
Senior Member
iTrader: (3)

Join Date: May 2008
Location: Fargo, ND
Posts: 534
Total Cats: 3
Default

Quote:
Originally Posted by TurboTim View Post
Meg suggests I paint the intake black so the fuel rails pop, and to hide the shameful alum. welds front & center. Thoughts?
Purple would really "Pop."

Can you anodize something like that ;-)
chance91 is offline   Reply With Quote
Old 07-21-2012, 07:51 PM   #363
Senior Member
iTrader: (10)

Join Date: Jul 2009
Location: Oakdale, CA
Posts: 1,332
Total Cats: 55
Default

Quote:
Originally Posted by TurboTim View Post
Meg suggests I paint the intake black so the fuel rails pop, and to hide the shameful alum. welds front & center. Thoughts?
If you are really concerned about the look of the welds, you could take some body filler (bondo for most people) and smooth them over then paint it black. I think if you painted it black the welds would probably stick out more. I have gotten decent at welding aluminum, I still hate doing it though.

If it were mine, bondo is what I would do. Smooth them out with that, then paint.
RyanRaduechel is offline   Reply With Quote
Old 07-21-2012, 11:54 PM   #364
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 28,968
Total Cats: 327
Default

------- insanity in this thread.
hustler is offline   Reply With Quote
Old 07-22-2012, 01:35 AM   #365
Elite Member
iTrader: (5)

Join Date: Jan 2007
Location: Freehold, NJ
Posts: 1,577
Total Cats: -2
Default

I 2nd meg lol

looking good sir! i'll have to check her out one day...the miata...not meg lol
disturbedfan121 is offline   Reply With Quote
Old 07-22-2012, 01:06 PM   #366
Boost Czar

iTrader: (60)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 70,179
Total Cats: 1,402
Default

tim makes the best IMs.
Braineack is offline   Reply With Quote
Old 07-24-2012, 12:48 PM   #367
Senior Member
iTrader: (3)

Join Date: May 2005
Location: Mass.
Posts: 815
Total Cats: 41
Default

Quote:
Originally Posted by TurboTim View Post
Meg suggests I paint the intake black so the fuel rails pop, and to hide the shameful alum. welds front & center. Thoughts?
Wrinkle finish powder coat can hide some sins.

Another option is to grind the welds down and pay a good aluminum tig welder to lay some pretty beads on top. Shouldn't charge you more then 60-80 bucks (not a lot labor there). I've seen my father do this a number of times with great success (he often goes over the part twice on cast pieces anyway since they're porous and shitty to weld - it's hard to get pretty beads and 'fill' at the same time, or so he claims)

That being said, welds on cast aluminum only get so good.

Whatever you do, don't just paint it black, even if satin. I did this on an elbow which had some slightly janky welds as a result of how shitty/porous the casting was - if anything, it looked worse. I ended up polishing the part since the reflections caused enough of a distraction to deflect focus from the welds. Reweld, wrinkle, or file/polish IMO.

-Zach
thasac is offline   Reply With Quote
Old 07-24-2012, 01:06 PM   #368
Senior Member
iTrader: (3)

Join Date: May 2005
Location: Mass.
Posts: 815
Total Cats: 41
Default

Quote:
Originally Posted by chance91 View Post
Purple would really "Pop."

Can you anodize something like that ;-)
Castings and the anodizing process do not play nicely together. You see it done on fishing reels, bike components and other smaller 'precision' castings, but it's not terribly common.

As a result, nearly everything you see in the market place which is anodized has been either extruded, machined, forged, etc.

-Zach
thasac is offline   Reply With Quote
Old 08-14-2012, 10:17 PM   #369
Elite Member
Thread Starter
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,177
Total Cats: 198
Default

over 90psi (pegged factory gauge) oil pressure at idle. Looks like I didn't need to shim the pump like the internets & Interprep said. I will have to see what it drops to once it's warm, or else I'll holesaw a hole into the pan and remove the shim, then weld the hole closed. I don't want to yank the engine at this point.

And I plumbed the heatercore return hose after the waterpump. Duh. Time to drain all the coolant back out.

But it fired on first try!!!!!!!!!
TurboTim is offline   Reply With Quote
Old 08-14-2012, 10:21 PM   #370
Cpt. Slow
iTrader: (24)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 11,637
Total Cats: 463
Default

"here, I'll show a shot of my feet for all those pervs on miata turbo with feet fetis...doh!"
curly is online now   Reply With Quote
Old 08-14-2012, 10:24 PM   #371
Elite Member
Thread Starter
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,177
Total Cats: 198
Default

She's tries to show her preggers belly. My kid will want to know where he was when he watches this in a few years. Ya knwo...
TurboTim is offline   Reply With Quote
Old 08-15-2012, 02:53 AM   #372
Elite Member
iTrader: (2)

Faeflora's Avatar

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,763
Total Cats: 115
Default

I hate you tim. You don't want to know what I will do when I get a welder. Imagine.
Faeflora is offline   Reply With Quote
Old 08-15-2012, 09:33 AM   #373
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 12,215
Total Cats: 750
Default

Quote:
Originally Posted by Faeflora View Post
I hate you tim. You don't want to know what I will do when I get a welder. Imagine.
I do not want to imagine you with a welder. That thought is just scary.
shuiend is online now   Reply With Quote
Old 08-15-2012, 09:41 AM   #374
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,170
Total Cats: 1,990
Default

Attached Thumbnails
ABSURDflow Turbo KLDE Mazda V6 Thread-spider_robot_13a.jpg
18psi is offline   Reply With Quote
Old 08-15-2012, 10:14 AM   #375
Elite Member
iTrader: (5)

m2cupcar's Avatar

Join Date: Jan 2005
Location: Atlanta
Posts: 6,950
Total Cats: 139
Thumbs up

That's awesome, congrats! I'm inspired.
m2cupcar is offline   Reply With Quote
Old 08-16-2012, 03:39 AM   #376
Junior Member

Golferluke's Avatar

Join Date: Oct 2009
Location: Springfield, MO
Posts: 497
Total Cats: 3
Default

Congrats on the startup!

Quote:
Originally Posted by shuiend View Post
I do not want to imagine you with a welder. That thought is just scary.
+1
Golferluke is offline   Reply With Quote
Old 08-16-2012, 04:07 AM   #377
Elite Member
iTrader: (12)

Join Date: Dec 2006
Location: Taos, New mexico
Posts: 5,662
Total Cats: 227
Default

whoah congrats! Cant wait to see some in car vids.
Fireindc is offline   Reply With Quote
Old 08-16-2012, 09:12 AM   #378
Boosting since 1984
iTrader: (1)

stefanst's Avatar

Join Date: Sep 2011
Location: Levittown
Posts: 994
Total Cats: 38
Default

Awesome!

What's the time frame for the first drive?
stefanst is offline   Reply With Quote
Old 08-16-2012, 09:22 AM   #379
Elite Member
iTrader: (3)

Join Date: Aug 2011
Posts: 7,237
Total Cats: 554
Default

Quote:
Originally Posted by TurboTim View Post
over 90psi (pegged factory gauge) oil pressure at idle. Looks like I didn't need to shim the pump like the internets & Interprep said. I will have to see what it drops to once it's warm, or else I'll holesaw a hole into the pan and remove the shim, then weld the hole closed. I don't want to yank the engine at this point.

And I plumbed the heatercore return hose after the waterpump. Duh. Time to drain all the coolant back out.

But it fired on first try!!!!!!!!!

Sorry, i'm going to go back and read the whole thread today, but did you remove the squirters and go with solid lifters? Those two things alone will skyrocket the oil pressure on a KL.

I'm not a fan of shimming the pump, i've found that it gives insane oil pressure even with HLAs and squirters still present. Like... 50-60psi hot idle insane.

That said, i'm still going to do it on mine with squirters removed and SLA conversion simply because i'm trying to see if there's a cheaper way to get around the oiling issues that would be present at the 9500rpms i'm going to spin this stock bottom end to.


Looks like i'm going to start necro-replying to posts...

Quote:
Originally Posted by bmxfuel007 View Post
in terms of power, I know a few mx6 guys who were getting 330 hp easy on relatively low boost (7 psi with a t3/t4 ?). On an mx6, it's not the engine that had problems, but rather the weak G series transmission would break like glass. The ones who have turboed their mx6's have gone through 8 or 9 trannies and can swap a tranny in about an hour or so (might be exaggerating a bit, but still). klze heads flow the best, but springs and lifters don't like anything above 7000 rpms. If I ever take my ZE mx6 up in the higher rpm range, I try not to pass 6500

oh yeah, and on the crazy modded KL's out there, I believe one twin turboed monster "KL" had pretty much everything beefed up on the engine, except for a balanced stock crank. So pretty much the only thing making that engine a KL was the crank lol
The ZE heads actually flow the worst. You see people making more power swapping to a ZE top end, but that's because of the cams more than anything. These guys would make more power keeping the DE oval port heads and just dropping in the ZE cams.


Quote:
Originally Posted by TurboTim View Post
Thanks. I searched for threads started by hppWDn and I couldn't a specific build thread. He may have it linked in his sig but I cannot see the links with post count <10. But the most recent shows bent millenia S rods and JE pistons. This is from that thread:
http://forums.probetalk.com/showthread.php?t=1701305652


Sooo he got to the 500 level using race fuel and lots of boost. Kinda granted But it's good to know how much boost it took.

I also found a thread from a few years ago with him trying out a different fabbed intake mani. He said it gained him some, but in more recent pics he's back to an OEM intake. So I dunno.

http://www.iceyrecords.com/drew/mx3/...t/cztboost.htm



Nuttin like rotas on an STi.
CZT Manifold.

CZT is now defunct. (As of... 8 years ago?) That manifold (there were two versions, i believe the one pictured is the better one) dyno'd a 27whp gain on an n/a KLDE with no other modifications. The factory manifolds suck bad. A good friend of mine was one half of CZT, and knows what he did for the manifolds in general, but no longer has the blueprints or equipment to produce them.

Last edited by concealer404; 08-16-2012 at 09:39 AM.
concealer404 is offline   Reply With Quote
Old 08-16-2012, 09:57 AM   #380
Elite Member
Thread Starter
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,177
Total Cats: 198
Default

Quote:
Originally Posted by stefanst View Post
Awesome!

What's the time frame for the first drive?
Last night I drained coolant, welded shut the hole where the heater core return went, welded a bung where it should be, epoxy'ed the 2 pinholes I found in my thermostat housing.

Tonight I refill and see if the holes still leak. If they don't, I let it idle to temperature (tune idle) to see what the oil pressure does once warm and to verify my electric waterpump duty cycle curve is somewhat close. I'm guessing there.

If the oil pressure remains silly high (likely), Friday I will holesaw into the oil pan to access the relief plug and remove the shim. I will machine a cover plate and drill/tap the pan for 10-32 screws.

Then go for a drive.

Quote:
Originally Posted by concealer404 View Post
Sorry, i'm going to go back and read the whole thread today, but did you remove the squirters and go with solid lifters? Those two things alone will skyrocket the oil pressure on a KL.
My block did not have oil squirters. I think that makes it a early 2000's block? It came from some country that does not use VIN tags. Dunno. It did have a forged crank. I don't remember the number engraved onto it, but it matched the internet "this is the crank you want" pics.

KLDE heads (oval) with hydraulic buckets, KLZE (square) intake. That's what was on it when I got it.

My sheetmetal intake has flanges that match the port shape of the head, but the ZE wasn't too far off. I may finish my intake over the winter. Or not.

Quote:
I'm not a fan of shimming the pump, i've found that it gives insane oil pressure even with HLAs and squirters still present. Like... 50-60psi hot idle insane.
I believe it. Allistar/Interprep said do it. But uhh...yeah.

Quote:
That said, i'm still going to do it on mine with squirters removed and SLA conversion simply because i'm trying to see if there's a cheaper way to get around the oiling issues that would be present at the 9500rpms i'm going to spin this stock bottom end to.
I aim for 8000, the limit Allistar said his springs are with the HLA's. Now that you found a cheap source for solid buckets I will do that if/when the engine comes apart next and go higher (and probably redo the oil pan and fuel lines to support that rpm). But I don't know why you'd need extra oil pressure for that. I didn't see anything in the oil galley design that looked bad. In fact, it all looked quite good.

Besides the shim, 'they' say to drill out the feed to the rear mains. Mine was already huge. Much larger than what I saw on the internet on the piston squirter blocks. When mazda took out the squirters they also redid the sizes on the main feeds.
TurboTim is offline   Reply With Quote
