Old 04-01-2014, 04:15 PM   #261
Supporting Vendor
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 4,760
Total Cats: 922
Default

Quote:
Originally Posted by NiklasFalk View Post
Wonder if the neutral switch alone would be suitable to do the same, making the stab at the clutch (switch) I do now unnecessary (MS flatshift).
That would have the opposite effect. Revs would rise instead of fall slightly.
emilio700 is offline   Reply With Quote
Old 04-01-2014, 04:17 PM   #262
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Quote:
Originally Posted by emilio700 View Post
That would have the opposite effect. Revs would rise instead of fall slightly.
But for clutchless shifting on a dog box you dont care about the revs change all you need to do is relieve the loading of the dogs. Thats why if you pull on the stick while full throttle it really doesnt move but as soon as you lift it comes right out of one gear and into the next.
Leafy is offline   Reply With Quote
Old 04-01-2014, 04:36 PM   #263
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Sweden
Posts: 1,367
Total Cats: 56
Default

Quote:
Originally Posted by emilio700 View Post
That would have the opposite effect. Revs would rise instead of fall slightly.
using the switch(s) to cut spark of course.
My synchro box got a little upset when I one did a flatshift without the function turned on, the gear went in with a crunch (3-4 in a 5sp, full throttle and close to no clutch).

But if you cannot bang it out of gear without unloading, the neutral switch is useless, but the clutch switch can still be used.
NiklasFalk is offline   Reply With Quote
Old 04-01-2014, 04:40 PM   #264
Senior Member
iTrader: (2)

Join Date: Jan 2010
Location: Denver
Posts: 909
Total Cats: 14
Default

Quote:
Originally Posted by TurboTim View Post
A while back I was talking to a dog box manufacturer. It was said for no-lift racing the simplest and quickest shift was a simple button to cut ignition. You preload slightly the shift ****, push the button and it'd slide into the gear. Quicker than wiggling the gas pedal to take the load off the dogs.

Along the same lines, when I went to the AEM's tuner school the instructor showed how he set up a load cell/strain gauge on the shift handle to trigger the Gen1 AEM EMS cut the ignition, for super fast dogbox shifts. That as trick.
Don't know how much faster you need to shift, up shifts with my current dog box are lightning fast and you don't have to worry about a switch failing. Not to mention all the new timing I have to learn pushing a button and then pulling the shift lever as I am drifting out of a corner and making that next up shift. Not to mention I am not running a car that took hundreds on thousands of dollars to make, for road racing, I will stay with lift and shift, however, for drag racing the nanoseconds saved could make an ignition cut for flat shifting worthwhile. Of course it's JMO.

Last edited by hingstonwm; 04-01-2014 at 08:17 PM.
hingstonwm is offline   Reply With Quote
Old 04-01-2014, 04:40 PM   #265
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

The right way to do it is super-gluing a 40 cent strain gauge to the shifter and setting it up properly with a voltage divider (made from 3 other 40 cent strain gauges glued to a flat plate) and connected to the ecu.
Leafy is offline   Reply With Quote
Old 04-01-2014, 05:13 PM   #266
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,365
Total Cats: 127
Default

Quote:
Originally Posted by Leafy View Post
The right way to do it is super-gluing a 40 cent strain gauge to the shifter and setting it up properly with a voltage divider (made from 3 other 40 cent strain gauges glued to a flat plate) and connected to the ecu.
This sounds genious. No idea how exactly this workd in practice but I am understanding the overall idea.
Ryan_G is online now   Reply With Quote
Old 04-01-2014, 05:33 PM   #267
Junior Member
iTrader: (2)

Join Date: Apr 2010
Location: albion, mi
Posts: 279
Total Cats: 16
Default

Quote:
Originally Posted by Ryan_G View Post
This sounds genious. No idea how exactly this workd in practice but I am understanding the overall idea.

It would work like this I assume

MTI Racing Six Shooter Sequential Transmission:




And I would buy at least 1, if not two if it were like this
glade is offline   Reply With Quote
Old 04-01-2014, 05:43 PM   #268
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Quote:
Originally Posted by Ryan_G View Post
This sounds genious. No idea how exactly this workd in practice but I am understanding the overall idea.
Basically the strain gauge changes resistance with tiny deflections in parts, even the tiny ones you get from pulling on the gear lever while its in gear. The voltage divider converts that resistance into a voltage that varies from 0-5v typically. When the ecu detects the voltage gets to a certain range it activate the NLS. AEM has this function built in, so does haltech, and I'm sure most others. There's a lot of really cool **** you can do with strain gauges.
Leafy is offline   Reply With Quote
Old 04-01-2014, 06:33 PM   #269
Supporting Vendor
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 4,760
Total Cats: 922
Default

Quote:
Originally Posted by glade View Post
It would work like this I assume

MTI Racing Six Shooter Sequential Transmission:

And I would buy at least 1, if not two if it were like this
That is a PPG sequential. Shifter moves fore-aft only, no side to side H pattern. Our concept is an H pattern dog box.
emilio700 is offline   Reply With Quote
Old 04-01-2014, 06:48 PM   #270
Junior Member
iTrader: (2)

Join Date: Apr 2010
Location: albion, mi
Posts: 279
Total Cats: 16
Default

Quote:
Originally Posted by emilio700 View Post
That is a PPG sequential. Shifter moves fore-aft only, no side to side H pattern. Our concept is an H pattern dog box.
My apologies, I was thinking that the rod attached to the shifter (to cut revs, or blip the throttle) would be better visualized with the video.
glade is offline   Reply With Quote
Old 04-01-2014, 06:53 PM   #271
Supporting Vendor
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 4,760
Total Cats: 922
Default

Quote:
Originally Posted by glade View Post
My apologies, I was thinking that the rod attached to the shifter (to cut revs, or blip the throttle) would be better visualized with the video.
ah. I like the idea of a strain gauge on the shifter that others posted. The lever won't move until the load on the gears is reduced sharply, but it will deflect by a few .000. The few times I drove a car with a dog box, it took a while to get accustomed to left foot braking. Once you get that down though, everything is faster and smoother.
emilio700 is offline   Reply With Quote
Old 04-01-2014, 07:53 PM   #272
Senior Member
iTrader: (2)

Join Date: Jan 2010
Location: Denver
Posts: 909
Total Cats: 14
Default


Here is a short video with shift from 2nd-4th
hingstonwm is offline   Reply With Quote
Old 04-01-2014, 07:57 PM   #273
Junior Member
iTrader: (2)

Join Date: Apr 2011
Posts: 360
Total Cats: 10
Default

Vid is private.
codingparadox is offline   Reply With Quote
Old 04-01-2014, 08:31 PM   #274
Senior Member
iTrader: (2)

Join Date: Jan 2010
Location: Denver
Posts: 909
Total Cats: 14
Default

sorry, fixed
hingstonwm is offline   Reply With Quote
Old 04-02-2014, 10:20 AM   #275
hrk
Junior Member
iTrader: (6)

Join Date: Oct 2005
Location: Atlanta GA
Posts: 334
Total Cats: 2
Default

In.
hrk is offline   Reply With Quote
Old 04-03-2014, 03:22 PM   #276
Junior Member
Thread Starter
iTrader: (-1)

Join Date: Jun 2010
Posts: 215
Total Cats: 5
Default

Im in too. so when can i have it? lol
mr2daj is offline   Reply With Quote
Old 04-04-2014, 04:59 AM   #277
Senior Member
iTrader: (1)

Join Date: Nov 2007
Location: Saint Paul, MN
Posts: 1,182
Total Cats: 18
Default

Attached Thumbnails
Gearbox options/experiences-shut-up-take-my-money.jpg
Der_Idiot is offline   Reply With Quote
Old 04-04-2014, 10:38 AM   #278
Junior Member

Join Date: Oct 2009
Location: Ottawa, ON, Canada
Posts: 82
Total Cats: 5
Default

Sounds really interesting. Gotta say though that the noise of straight cut would be pretty awesome.
schmoo is offline   Reply With Quote
Old 04-04-2014, 10:51 PM   #279
Junior Member

Join Date: May 2008
Location: Canada
Posts: 372
Total Cats: 42
Default

Quote:
Originally Posted by schmoo View Post
Sounds really interesting. Gotta say though that the noise of straight cut would be pretty awesome.
For a daily driver, not so much. My Quaife gearset (which is only semi-straight-cut) sounds like a supercharger in lower gears (cool!) but is downright annoying at highway speeds in top gear.
DeerHunter is offline   Reply With Quote
Old 04-05-2014, 02:53 AM   #280
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: Hickory, NC
Posts: 681
Total Cats: 3
Default

My brain hurts!
In for results and people's thoughts though we seemed to have given up on throwing ideas around and instead of pulling the unicorn from our collective asses, we are looking to Emilio to pull one from his?
I have a semi truck and can drive it without a clutch so I feel the dog box would not be a problem to daily, but maybe I don't want to be the only one to drive my car on a long trip? At least for me, street manners matter.
I remember reading the Corky was working on a T5 conversion that wasn't suppose to weigh a ton more. Does anybody know what came of that? Even if he is slow to get it to market if that is a good option for the street car who is not looking to get every last bit out of it on the track like Sav, I will do the fab myself. Thoughts?
Amellrotts is offline   Reply With Quote
