Old 06-08-2015, 01:26 PM   #361
Elite Member
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,024
Total Cats: 129
Default

Quote:
Originally Posted by EO2K View Post
Agreed. I've never found an adhesive product that would stick to an aluminum radiator at track temps. Of course I've not tried very hard, but if someone has a link to something that works, I'd buy a roll.
A long time ago I did this, but I stuck the foam to the car, not the radiator since as you say it just melts off the radiator from temps. That actually lasted for a while. I used medium density foam from Lowes. It got damaged from installing/removing the radiator a lot so I removed it. This thread reminded me I need to redo it. Or use plastic sheets, that would be even better.
patsmx5 is offline   Reply With Quote
Old 06-08-2015, 01:29 PM   #362
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 5,821
Total Cats: 555
Default

This is the stuff that's used on aircraft:

SILICONE BAFFLE SEAL - LIPSTICK RED from Aircraft Spruce
hornetball is offline   Reply With Quote
Old 06-08-2015, 01:31 PM   #363
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: woosta, ma
Posts: 8,689
Total Cats: 93
Default

Yeah The adhesive exists, how else do OEM stick the foam to the radiators. Best thing is probably to go on 3m's website and pick something out. Probably going to be some flavor of silicone adhesive.
Leafy is offline   Reply With Quote
Old 06-08-2015, 01:38 PM   #364
Junior Member
iTrader: (2)

Join Date: May 2014
Location: Arlington, TX
Posts: 311
Total Cats: 39
Default

Try going to Mcmaster:

McMaster-Carr

I bet the high temperature aluminum foil tape (325 F) will work, but the extreme temp stuff (600F) should definately work.

The fiberglass reinforced foil tape seems like it would be good for sealing as well

Last edited by Dustin1824; 06-08-2015 at 01:57 PM.
Dustin1824 is offline   Reply With Quote
Old 06-08-2015, 01:56 PM   #365
Junior Member
iTrader: (2)

Join Date: Sep 2014
Location: PHX, Arizona
Posts: 227
Total Cats: 13
Default

Dustin1824 is right on. I've had some aluminum tape on my radiator for about 6 months now and it still sticks. Surface area is important. If you take your time and get a nice smooth even tape line, it will work pretty good. I didn't even use anything fancy, just the cheap home depot stuff.
humming is offline   Reply With Quote
Old 06-08-2015, 01:59 PM   #366
Junior Member

Join Date: Sep 2014
Location: Portland (left coast)
Posts: 206
Total Cats: 2
Default

Quote:
Originally Posted by Dustin1824 View Post
Try going to Mcmaster:

McMaster-Carr

I bet the high temperature aluminum foil tape (325 F) will work, but the extreme temp stuff (600F) should definately work.

The fiberglass reinforced foil tape seems like it would be good for sealing as well
"Extreme Temperature—This tape functions in temperatures from -65 to 600 F; apply at 0 to 200 F. It also resists moisture and dust. "

wholly crap, apply while it is 200? Flame suit required?


Quote:
Originally Posted by hornetball View Post
This is the stuff that's used on aircraft:

SILICONE BAFFLE SEAL - LIPSTICK RED from Aircraft Spruce
Bad-***.
tazswing is offline   Reply With Quote
Old 06-08-2015, 02:11 PM   #367
Junior Member
iTrader: (2)

Join Date: May 2014
Location: Arlington, TX
Posts: 311
Total Cats: 39
Default

Quote:
Originally Posted by tazswing View Post

wholly crap, apply while it is 200? Flame suit required?
I can see some guys trying to apply at 200 F. Think about what you would do between track sessions to repair an off track excursion that screwed up your ducting. If you tried to put tape on your rad, it would be about 200 F.
Dustin1824 is offline   Reply With Quote
Old 06-08-2015, 02:54 PM   #368
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,437
Total Cats: 2,038
Default

Quote:
Originally Posted by tazswing View Post
Sealing up the top of the radiator made a big difference for my MSM. Does anyone have any tricks for getting the sides of the radiator sealed up better? Such a pain to get to. I am thinking about cutting some sort of plastic to slide down the sides since metal tape won't stay put in there.
on my list of to-do's, but here's what I'm picturing in my head:

top cover out of your choice of plastic, but cut it out with "wings" to fold over the sides and cover up those two holes in the upper rad area near the headlights, if that makes sense.
18psi is offline   Reply With Quote
Old 06-08-2015, 04:05 PM   #369
Junior Member

Join Date: Sep 2014
Location: Portland (left coast)
Posts: 206
Total Cats: 2
Default

Quote:
Originally Posted by 18psi View Post
on my list of to-do's, but here's what I'm picturing in my head:

top cover out of your choice of plastic, but cut it out with "wings" to fold over the sides and cover up those two holes in the upper rad area near the headlights, if that makes sense.
yup. you would lower it in from the top with the wings sliding over the sides and down, with the top part looking like everything else out there. The wings could also have an angle to mate up with the edge of the rad. just before the fins start. Ideally you would mill the edge on the rad. to accept the edge of the wing.

When I did a image search for "slotted aluminum radiator end tank" I did not get anything exciting. But if you could mill in or weld on a flange the length of the radiator and then just fabricate the cover you could just trim as needed.

Last edited by tazswing; 06-08-2015 at 04:54 PM.
tazswing is offline   Reply With Quote
Old 06-08-2015, 04:16 PM   #370
Cpt. Slow
iTrader: (24)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 11,716
Total Cats: 472
Default

Aluminum tape. Not the shitty plasticy stuff.
curly is offline   Reply With Quote
Old 06-08-2015, 05:51 PM   #371
Junior Member

Join Date: Sep 2014
Location: Portland (left coast)
Posts: 206
Total Cats: 2
Default

Quote:
Originally Posted by curly View Post
Aluminum tape. Not the shitty plasticy stuff.

Attached Thumbnails
Miata cooling system thread-80-duck_tape_for_blog_7_10_1024x780_e1ee9e569f281b2c14ec928cd4adc218438a2d5b.jpg
tazswing is offline   Reply With Quote
Old 06-08-2015, 06:38 PM   #372
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 8,895
Total Cats: 775
Default

I mean, that is just about as helpful
EO2K is offline   Reply With Quote
Old 06-09-2015, 12:13 AM   #373
Elite Member
iTrader: (2)

Mobius's Avatar

Join Date: May 2008
Location: Portland, Oregon
Posts: 2,796
Total Cats: 213
Default

I sealed my radiator with Gorilla Tape across the top gap, 1/2 lowes/home depot foam on the sides, and the bottom used vinyl tub/shower liner sealed with aluminum hvac tape.

The aluminum hvac tape would get gummy by the end of a driving season but never detached. The gorilla tape never detached or got gummy.

The caveat is that I'm in the Northwest, my hottest track days were probably 85 ambient last year. In desert heat my solutions may have melted.
Mobius is offline   Reply With Quote
Old 06-09-2015, 12:17 AM   #374
SadFab Sales Lady
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 15,237
Total Cats: 978
Default

<p>Does a 20 degree ambient temperature delta&nbsp;really make that much of a difference in overall temps? Is it exponential in some way?</p>
aidandj is offline   Reply With Quote
Old 06-09-2015, 12:27 AM   #375
Elite Member
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,024
Total Cats: 129
Default

Quote:
Originally Posted by aidandj View Post
<p>Does a 20 degree ambient temperature delta&nbsp;really make that much of a difference in overall temps? Is it exponential in some way?</p>
No, it's linear for the most part.
patsmx5 is offline   Reply With Quote
Old 06-09-2015, 03:28 AM   #376
Junior Member

Join Date: Jan 2014
Location: Western Australia
Posts: 349
Total Cats: 62
Default

Quote:
Originally Posted by patsmx5 View Post
No, it's linear for the most part.
Actual running temp is a fraction of the difference between the temp of the engine (which should stay the same) and the ambient. What the fraction is depends on the car and the cooling efficiency.

So say my engine is at 200 deg, the ambient at 100 deg then the coolant will equalise at a point say 1/4 down that line. ie 175 deg. If the engine is at 200 deg and the ambient is at 80 deg then the coolant will be around 170 deg.

So the relationship is linear, but a 20 degree drop in ambient won't bring down the running temp by 20 degree. It will be some ratio of that at a max of 1/2.

Of course in actuality it's way more complex with engine head load fluctuating but the general physics is the same.
Madjak is online now   Reply With Quote
Old 06-09-2015, 10:03 AM   #377
Junior Member
iTrader: (7)

Join Date: Jun 2012
Location: Columbus, IN
Posts: 395
Total Cats: 7
Default

In industry we correlate ambient to top tank temperatures at a 1:1 relation for coolant package size considerations with all other conditions being equal at ambients above 70 degrees.

Aka a 1 degree rise in ambient relates to a 1 degree rise in coolant temps.

Below 70 degrees the correlation becomes less linear
slammed200 is offline   Reply With Quote
Old 06-09-2015, 10:05 AM   #378
Junior Member
iTrader: (7)

Join Date: Jun 2012
Location: Columbus, IN
Posts: 395
Total Cats: 7
Default

To add another data point, we ran a stock plastic end tank automatic radiator fully ducted from an airdam with a reroute and blocked open thermostat on a stock horsepower racecar for 14 hours this weekend.

Coolant temps never rose above 190 F on a 85 F ambient day.

That's about as hot as we will see here in the Midwest so we'll be putting a thermostat in now that I have a feel for how much overhead cooling capacity we have in the system. I would like to see temps in the 195-205 range on the stock ECM
slammed200 is offline   Reply With Quote
Old 06-09-2015, 09:49 PM   #379
Senior Member
iTrader: (12)

Join Date: Jan 2007
Location: Murfreesboro,TN
Posts: 1,172
Total Cats: 29
Default

We ran the same race with the same setup as slammed200 except we use a thermostat and our temps were 199-201 all day long. Maybe some creep to 205 while pushing hard right behind a car.
Midtenn is offline   Reply With Quote
Old 06-10-2015, 03:18 PM   #380
Junior Member
iTrader: (7)

Join Date: Jun 2012
Location: Columbus, IN
Posts: 395
Total Cats: 7
Default

Andrew which thermostat are you guys running and do you have a 1/4" hole drilled at the top?

I forget if your water pump mixer is capped off, but you do run the reroute on the cold side like we do if I recall correctly.
slammed200 is offline   Reply With Quote
