Old 01-10-2014, 04:09 PM   #801
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,869
Total Cats: 45
Default

Quote:
Originally Posted by Dot3 View Post
What is that dyno chart tyring to say? That this magical intake manifold picks up 40hp by itself. And that a stock K20A makes 240hp?
vehicular is offline   Reply With Quote
Old 01-10-2014, 04:24 PM   #802
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 33,845
Total Cats: 2,123
Default

That site is terrible at best.

Hai guyths I make manifords but no pictures of any of them but here's a random weird dyno plot showing they gain crazy amounts of power on a K motor this is all totally legit guythzzz

herp derp

Also his website was put together by a 5th grader in 2002
18psi is offline   Reply With Quote
Old 01-10-2014, 04:27 PM   #803
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Quote:
Originally Posted by 18psi View Post
That site is terrible at best.

Hai guyths I make manifords but no pictures of any of them but here's a random weird dyno plot showing they gain crazy amounts of power on a K motor this is all totally legit guythzzz

herp derp

Also his website was put together by a 5th grader in 2002
But it works, ***** in logical places, besides the pictures he should have up. Go try to find the sports scores on USA today, its like trying to find bacon recipes on Al Jazeera.
Leafy is offline   Reply With Quote
Old 01-13-2014, 01:28 PM   #804
Senior Member
iTrader: (3)

Join Date: Aug 2005
Location: Gig Harbor, WA
Posts: 504
Total Cats: 3
Default

Pictures are on the home page.

All of his dynos are done on race gas.
TurboRoach is offline   Reply With Quote
Old 01-16-2014, 10:17 AM   #805
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,869
Total Cats: 45
Default

Race gas doesn't make 40hp on a 200hp engine.
vehicular is offline   Reply With Quote
Old 01-16-2014, 10:30 AM   #806
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Quote:
Originally Posted by vehicular View Post
Race gas doesn't make 40hp on a 200hp engine.
No, and he said both dynos were run with vp109 for consistancy, so the baseline is also on race gas.
Leafy is offline   Reply With Quote
Old 01-20-2014, 11:33 PM   #807
Junior Member

Join Date: Nov 2010
Location: Chicagoland
Posts: 158
Total Cats: 2
Default

I put a b18b intake manifold on my car and just need to wire it up. I'm having a hard time finding the wiring pinouts on the internet. anyone help? thanks.

Honda b18b TPS
Green- Ground
Red - signal to ecu
Yellow - 5v power

99 Miata TPS -
light green/ brown stripe-
black /red stripe-
Green / black stripe

99 miata IAC - 2 wires
yellow -
pink/red stripe-

Honda b18b IAC - 2 wires
Black/ blue stripe-
Yellow/ blk stripe-
natedawg is offline   Reply With Quote
Old 01-21-2014, 03:29 AM   #808
I haz no trubo
iTrader: (2)

Oscar's Avatar

Join Date: Jan 2007
Location: Bolton, UK
Posts: 3,012
Total Cats: 108
Default

Quote:
Originally Posted by natedawg View Post
I put a b18b intake manifold on my car and just need to wire it up. I'm having a hard time finding the wiring pinouts on the internet. anyone help? thanks.

Honda b18b TPS
Green- Ground
Red - signal to ecu
Yellow - 5v power

99 Miata TPS -
light green/ brown stripe- +5V ref
black /red stripe- ground
Green / black stripe- signal

99 miata IAC - 2 wires
yellow - polarity doesn't matter on IAC, just connect the two.
pink/red stripe-

Honda b18b IAC - 2 wires
Black/ blue stripe-
Yellow/ blk stripe-

So:
Miata pigtail to honda TPS:

light green/brown to yellow
black/red to green
green/black to red

IAC: just connect the two.

At least that's what I did to put 99/01 sensors in my 94 car. Hope it helps.
Oscar is offline   Reply With Quote
Old 01-21-2014, 03:39 AM   #809
Senior Member
iTrader: (8)

Join Date: Jun 2010
Location: Navarre, FL
Posts: 1,127
Total Cats: 38
Default

looks right ^^. polarity indeed does not matter for the idle valve stuff.
aaronc7 is offline   Reply With Quote
Old 01-21-2014, 08:40 AM   #810
Elite Member
iTrader: (4)

Join Date: Dec 2008
Location: Kingston, Ontario
Posts: 2,653
Total Cats: 61
Default

Im guessing since most of you are using megasquirt that no one uses Honda Map provisions in the throttle body?
shlammed is offline   Reply With Quote
Old 02-20-2014, 01:31 PM   #811
Junior Member
iTrader: (1)

Join Date: Oct 2011
Location: Albuquerque, NM
Posts: 381
Total Cats: -11
Default

Quote:
They are in production we have a tentative date of late May for release.
.
Dot3 is offline   Reply With Quote
Old 02-20-2014, 01:34 PM   #812
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Here's to hoping they didnt massively miss the mark and come out with a super short runner POS or something that's just gonna break.
Leafy is offline   Reply With Quote
Old 03-28-2014, 12:40 PM   #813
Junior Member
iTrader: (1)

Join Date: Oct 2011
Location: Albuquerque, NM
Posts: 381
Total Cats: -11
Default

***** getting real.
Attached Thumbnails
Honda intake manifold-1795259_10152265014304020_647351879_o.jpg
Dot3 is offline   Reply With Quote
Old 03-28-2014, 12:57 PM   #814
Supporting Vendor
iTrader: (1)

Join Date: May 2010
Location: San Diego
Posts: 461
Total Cats: 35
Default

Quote:
Originally Posted by Dot3 View Post
***** getting real.
Ooooo the unicorn exists! Where did you find this photo?
Lincoln Logs is offline   Reply With Quote
Old 03-28-2014, 12:59 PM   #815
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

project g posted it on mnet.
Leafy is offline   Reply With Quote
Old 03-28-2014, 04:48 PM   #816
Senior Member
iTrader: (1)

Join Date: Mar 2008
Location: Cromwell CT
Posts: 1,073
Total Cats: 44
Default

skunk2 also posted it on their Facebook
ctdrftna is offline   Reply With Quote
Old 03-28-2014, 05:23 PM   #817
MT Pony Underground
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Looks rather compact for being able to hit a proper runner length.
Nagase is offline   Reply With Quote
Old 03-28-2014, 05:29 PM   #818
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 8,820
Total Cats: 92
Default

Thats why I'm worried its only like 8" long runners.
Leafy is offline   Reply With Quote
Old 03-28-2014, 05:31 PM   #819
Senior Member
iTrader: (4)

Join Date: May 2010
Location: Iowa City
Posts: 541
Total Cats: 15
Default

I'm going to buy that.

Yes I am.
vteckiller2000 is offline   Reply With Quote
Old 03-28-2014, 05:31 PM   #820
Elite Member
iTrader: (2)

Join Date: Aug 2012
Location: Indianapolis
Posts: 3,325
Total Cats: 231
Default

Gee we've done all this R&D for them for free, you'd think they would just swap out a BP flange for the B18 flange on the manifolds you guys hack together.
thenuge26 is offline   Reply With Quote
