DIY Turbo Discussion greddy on a 1.8? homebrew kit?

Reply



LinkBack Thread Tools
Old 02-08-2012, 02:14 PM   #1
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default Big Turbo Noob...

I have my 2002 ls for a little over a year now. Done my suspension, brake, and wheel/tire upgrades. Ill post a picture of my car. So now Im beginning to get a bit bored with the lack of power. Im not looking for a huge power increase because it is my daily driver. Looking for a reliable 140hp to 160hp. So obviously the Shanghai-S Turbo System is what Ill be purchasing. Ive been doing alot of reading and everything and trying to keep the price as low as possible but want it done right. My car has 101,000 miles, Bone stock motor, has had regular synthetic oil changes, good gas, just had timing belt and water pump done, all new belts, I will be doing a compression test soon to make sure shes good to go. Plan on sticking with stock ecu if thats cool So here is the list of stuff Ill be adding with the system...

-Wideband 02 plug
-T2871 turbo
-BEGi fuel system
-Bypass valve
-Oil pan drill and tap
-All stainless braid lines
-Seperated gases downpipe (mild steel)
-Oil drain line
-Boost Gauge
-May add intercooler

So stock ecu, good motor. What about tuning and everything with stock ecu

So I do have experience working on cars etc. So Im comfortable doing the install myself, just want to double check with you guys before I start to order stuff. Just let me know what you think. Thanks


Untitled by tyler-mckenzie, on Flickr
Attached Thumbnails
Big Turbo Noob...-5872025602_ac1ace9941_z.jpg
02mia is offline   Reply With Quote
Old 02-08-2012, 02:53 PM   #2
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

If you only want 160whp, which is dog slow, just get MS2 or MS3, I/H/E.
hustler is offline   Reply With Quote
Old 02-08-2012, 03:33 PM   #3
Elite Member
iTrader: (7)

samnavy's Avatar

Join Date: Apr 2006
Location: VIRGINIA BEACH, VA
Posts: 6,020
Total Cats: 175
Default

What he said^... +headwork helps.
samnavy is offline   Reply With Quote
Old 02-08-2012, 03:52 PM   #4
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by hustler View Post
If you only want 160whp, which is dog slow, just get MS2 or MS3, I/H/E.
Well Ive never driven or been in a turbo miata, to me it seems like having an extra 30 to 50hp would make a pretty decent increase, but I guess it doesnt...
02mia is offline   Reply With Quote
Old 02-08-2012, 04:44 PM   #5
Junior Member
iTrader: (8)

Join Date: Mar 2007
Location: Sarasota, FL
Posts: 334
Total Cats: 0
Default

Add clutch and megasquirt and you'll have a healthy 200hp, which is lots funner then stock.
chokeasphyxia is offline   Reply With Quote
Old 02-08-2012, 05:08 PM   #6
Antisaint
iTrader: (17)

Vashthestampede's Avatar

Join Date: Feb 2007
Location: Danbury, CT
Posts: 4,659
Total Cats: 54
Default

Quote:
Originally Posted by 02mia View Post
I have my 2002 ls for a little over a year now. Done my suspension, brake, and wheel/tire upgrades. Ill post a picture of my car. So now Im beginning to get a bit bored with the lack of power. Im not looking for a huge power increase because it is my daily driver. Looking for a reliable 140hp to 160hp. So obviously the Shanghai-S Turbo System is what Ill be purchasing. Ive been doing alot of reading and everything and trying to keep the price as low as possible but want it done right. My car has 101,000 miles, Bone stock motor, has had regular synthetic oil changes, good gas, just had timing belt and water pump done, all new belts, I will be doing a compression test soon to make sure shes good to go. Plan on sticking with stock ecu if thats cool So here is the list of stuff Ill be adding with the system...

-Wideband 02 plug
-T2871 turbo
-BEGi fuel system
-Bypass valve
-Oil pan drill and tap
-All stainless braid lines
-Seperated gases downpipe (mild steel)
-Oil drain line
-Boost Gauge
-May add intercooler

So stock ecu, good motor. What about tuning and everything with stock ecu

So I do have experience working on cars etc. So Im comfortable doing the install myself, just want to double check with you guys before I start to order stuff. Just let me know what you think. Thanks
.....and I'm not even one of the guys that picks on this kind of stuff. Its just the only thing I got from your post.

To add. A 180whp miata is fun, no doubt about it, but a 250whp miata is a WHOLE LOT more fun!
Vashthestampede is offline   Reply With Quote
Old 02-08-2012, 05:21 PM   #7
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

add intercooler
run 7 psi on your 2871

enjoy 220 hp.
y8s is online now   Reply With Quote
Old 02-08-2012, 05:31 PM   #8
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by Vashthestampede View Post
.....and I'm not even one of the guys that picks on this kind of stuff. Its just the only thing I got from your post.

To add. A 180whp miata is fun, no doubt about it, but a 250whp miata is a WHOLE LOT more fun!
Thanks for the feeback guys. I would love to go all out and have 250+hp but this is my daily driver on all stock internals and Id like to keep it as reliable as possible. 180hp sounds pretty good to me. Also trying to keep price down.

So is it cool to stick with stock ecu with the BEGi fuel system or should I defiantly go with the megasquirt?
02mia is offline   Reply With Quote
Old 02-08-2012, 05:36 PM   #9
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by Vashthestampede View Post
.....and I'm not even one of the guys that picks on this kind of stuff. Its just the only thing I got from your post.

To add. A 180whp miata is fun, no doubt about it, but a 250whp miata is a WHOLE LOT more fun!
And a 500hp is more than 2x more fun than 250hp. More like 8x as fun.
Faeflora is offline   Reply With Quote
Old 02-08-2012, 05:45 PM   #10
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by Faeflora View Post
And a 500hp is more than 2x more fun than 250hp. More like 8x as fun.
Dude I wish
02mia is offline   Reply With Quote
Old 02-08-2012, 06:13 PM   #11
Antisaint
iTrader: (17)

Vashthestampede's Avatar

Join Date: Feb 2007
Location: Danbury, CT
Posts: 4,659
Total Cats: 54
Default

Quote:
Originally Posted by Faeflora View Post
And a 500hp is more than 2x more fun than 250hp. More like 8x as fun.
See I disagree with you there. Granted, I have yet to drive a 500whp miata, but I assume with that much power its almost undriveable on a day to day basis.

At one point I was DD'ing mine all year round.

OP - If I had it to do ALL over again, I'd start first and foremost with MS. As you learn it, build your turbo kit. Contact Abe (ARTech) or Tim (Absurdflow) and have them make you a mani/dp combo, add an exhaust if you can swing the extra cash. Hunt the classifieds/vendors on here to pick up all the odds and ends like injectors, torsen, clutch, etc.

In the long run you'll have saved quite a bit of money VS buying a pre packaged kit and you'll have a setup that will be very flexible in terms of "moar power" when that time comes.
Vashthestampede is offline   Reply With Quote
Old 02-08-2012, 06:19 PM   #12
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by Vashthestampede View Post
See I disagree with you there. Granted, I have yet to drive a 500whp miata, but I assume with that much power its almost undriveable on a day to day basis.

At one point I was DD'ing mine all year round.

OP - If I had it to do ALL over again, I'd start first and foremost with MS. As you learn it, build your turbo kit. Contact Abe (ARTech) or Tim (Absurdflow) and have them make you a mani/dp combo, add an exhaust if you can swing the extra cash. Hunt the classifieds/vendors on here to pick up all the odds and ends like injectors, torsen, clutch, etc.

In the long run you'll have saved quite a bit of money VS buying a pre packaged kit and you'll have a setup that will be very flexible in terms of "moar power" when that time comes.
I am starting to think thatd be a good idea for, just piecing my own setup together over a period of time and once i get everything just throw it together. I had a friend that did the same with his KA-T 240sx and saved him ALOT of money in the end.
02mia is offline   Reply With Quote
Old 02-08-2012, 08:33 PM   #13
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by Vashthestampede View Post
See I disagree with you there. Granted, I have yet to drive a 500whp miata, but I assume with that much power its almost undriveable on a day to day basis.

At one point I was DD'ing mine all year round.
No, it's not undriveable at all. Scott and others who have gotten ride alongs in my car have commented on how good the low end is. Big turbo = flow. FWIW in 1:1 gear I make 1psi at 2400RPM.

Same deal as 250hp miata-- you just don't go WOT all the time. BTW @ 500HP you will prob have 400TQ which means you can run an ACT XT sprung 6 puck disc. That is a very daily driveable clutch. I DD'd the organic disc which felt nearly identical for 3 years @ 250hp.

You also don't have to run a 4" exhaust for 500hp. E85 or WI? Probably but WI is easy peasy.
Faeflora is offline   Reply With Quote
Old 02-08-2012, 10:08 PM   #14
Junior Member
iTrader: (1)

Join Date: Dec 2010
Location: Knoxville, TN
Posts: 279
Total Cats: 2
Default

maybe I am missing something, but a T2871, for 180 hp?
wouldn't you want something like a T2560 instead?
mx594m is offline   Reply With Quote
Old 02-08-2012, 10:17 PM   #15
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by mx594m View Post
maybe I am missing something, but a T2871, for 180 hp?
wouldn't you want something like a T2560 instead?
Yeah

bitch
Faeflora is offline   Reply With Quote
Old 02-08-2012, 10:20 PM   #16
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,185
Total Cats: 2,582
Default

1.8+VVT+2871 is not laggy at all.
And I'm almost positive OP will want more power within a week (if he's a man)
18psi is offline   Reply With Quote
Old 02-08-2012, 10:23 PM   #17
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by mx594m View Post
maybe I am missing something, but a T2871, for 180 hp?
wouldn't you want something like a T2560 instead?
Yeah Ill just go with t25. Any advice on tuning with BEGi fuel system and stock ecu? And before turbo stuff is installed i figured id go ahead and do head gasket and intake gaskets etc. Any suggestions on head gaskets?
02mia is offline   Reply With Quote
Old 02-08-2012, 10:28 PM   #18
Newb
Thread Starter

Join Date: Jun 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by 18psi View Post
1.8+VVT+2871 is not laggy at all.
And I'm almost positive OP will want more power within a week (if he's a man)
Good point. After I feel what 160 to 180 feels like I will probably want more
02mia is offline   Reply With Quote
Old 02-09-2012, 01:03 AM   #19
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,806
Total Cats: 183
Default

First I'd research a little more.
Then I'd leave your gaskets alone. Just tap your oil pan and install the turbo and all the hardware.
How are you retarding timing?
I'm assuming the BEGI "fuel system" adds fuel pressure in boost? F that POS. Get a voo-doo box at least.
Seriously though, you need a not stock ECU if you ever want to see anything good for your engine that lays down over 170whp.
Best advice: If you don't want to spend the money and do it right, don't do it at all.
thirdgen is offline   Reply With Quote
Old 02-09-2012, 09:04 AM   #20
Elite Member
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,484
Total Cats: 248
Default

The ONLY reason I see keeping the stock ECU is if you must have it to pass emissions.
TurboTim is offline   Reply With Quote
