DIY Turbo Discussion greddy on a 1.8? homebrew kit?

Reply



LinkBack Thread Tools
Old 05-08-2012, 06:34 PM   #1
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default Occasional Buck

Hey guys, got an issue that bugs me a bit, just curious if anyone has any input
specs
93 NA with a SNC 1.6l
MS1 3.0
stock coils
mitsu 16g
dsm 340cc
blah blah

problem im getting is, occasionally, more random, nothing specific causes it, it can do it under load, or not
i get a buck. like a cylinder cuts out, then comes back, like i said it will just randomly do it when driving, very rarely it will do it in boost.

other question is, which im leaning towards either the turbo seals or valve stem seals
if i completely let off the throttle, engine brake, then start giving it gas again, it smokes, but thats the only time.
now, its not the PCV or breather, as i can unhook both, and it still does it at the same situation.
im replacing the turbo tomorrow, so that will eliminate the possibility of that, assuming it still smokes
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 06:36 PM   #2
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,684
Total Cats: 555
Default

Deceleration smoke is usually valve seals.
rleete is offline   Reply With Quote
Old 05-08-2012, 06:41 PM   #3
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

thats what i was thinking, as long as i press the clutch in when i let off its fine, i just have a habit of engine braking
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 06:49 PM   #4
Senior Member
iTrader: (6)

Join Date: Aug 2009
Location: Charlotte, NC
Posts: 924
Total Cats: 16
Default

I had the same issue as you with the bucking. in my case the cas was missing an event on the very rare occasion and thus spark would not fire.
Gryff is offline   Reply With Quote
Old 05-08-2012, 06:51 PM   #5
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

like a failing cas? or incorrect settings in wheel decoder settings?
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 08:38 PM   #6
Elite Member
iTrader: (10)

soviet's Avatar

Join Date: Jan 2010
Location: VA
Posts: 3,517
Total Cats: 257
Default

I don't know if this applies to MS1 but...


I had the same issues on MS2. It was getting sync loss on the CAS signal. Just log when it happens (easier said than done). If it's a sync issue, you will see "Sync Loss Count" count go up, and "Sync Loss Reason" will go to 38 or 39.

Building an opto isolator circuit fixed it for me.
soviet is offline   Reply With Quote
Old 05-08-2012, 09:34 PM   #7
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

Quote:
Originally Posted by soviet View Post
I don't know if this applies to MS1 but...


I had the same issues on MS2. It was getting sync loss on the CAS signal. Just log when it happens (easier said than done). If it's a sync issue, you will see "Sync Loss Count" count go up, and "Sync Loss Reason" will go to 38 or 39.

Building an opto isolator circuit fixed it for me.
i havent found anything in terms sync in tuner or megaview
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 10:17 PM   #8
Junior Member

Join Date: Jan 2011
Location: sacramento ,ca
Posts: 402
Total Cats: 46
Default

i had a similar issue but mine is during cruise. At the event my afr's would drop into the 12's then pop up to 15:1-16:1 and be fine again. it seemed to me like it was getting a false acceleration signal cause my injector PW would jump up just before each event. so i opened acceleration wizard on tunerstudioMS to check my settings and everything looked good so i drove with it open to see if the green ball was jumping around but it stopped doing it. at first i was mad cause it wouldnt fail while i was watching so just saved my settings and closed the window. that was 2 weeks ago and it has yet to act up yet and i drive the car daily. not sure what fixed it but it stopped.
fastivab6tg25mr is offline   Reply With Quote
Old 05-08-2012, 10:25 PM   #9
Senior Member
iTrader: (6)

Join Date: Aug 2009
Location: Charlotte, NC
Posts: 924
Total Cats: 16
Default

Yeah, I have no idea what fixed mine either, but the cas is still the same one.
Gryff is offline   Reply With Quote
Old 05-08-2012, 10:52 PM   #10
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

my afr is staying almost exact at 14.7-15.2 cruising, it doesnt change when it bucks though
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 10:59 PM   #11
Junior Member

Join Date: Jan 2011
Location: sacramento ,ca
Posts: 402
Total Cats: 46
Default

if its a misfire your afrs should change alot... do your injector PW's change during the buck? can you get a data log of the event?
fastivab6tg25mr is offline   Reply With Quote
Old 05-08-2012, 11:10 PM   #12
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

i have a datalog i left running for a while, but i dont see anything that shows any sign of it happening
Attached Files
File Type: msl 2012-04-16_13.01.15.msl (1.79 MB, 53 views)
skullzaflare is offline   Reply With Quote
Old 05-08-2012, 11:53 PM   #13
Junior Member

Join Date: Jan 2011
Location: sacramento ,ca
Posts: 402
Total Cats: 46
Default

do you not have a TPS or an intake air temp sensor?
fastivab6tg25mr is offline   Reply With Quote
Old 05-09-2012, 12:00 AM   #14
Elite Member
iTrader: (4)

MartinezA92's Avatar

Join Date: Aug 2009
Location: Mountain View, CA
Posts: 1,702
Total Cats: 28
Default

This is exactly what is happening to me. In for details. I'm gonna throw a CAS at it and see if it stops. Mostly happens on the freeway.
MartinezA92 is offline   Reply With Quote
Old 05-09-2012, 12:02 AM   #15
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

Quote:
Originally Posted by fastivab6tg25mr View Post
do you not have a TPS or an intake air temp sensor?
1.6 throttle body still
i have a IAT sensor, but i still need to tune it in, it completely leans out the car when i plug it in
Quote:
Originally Posted by MartinezA92 View Post
This is exactly what is happening to me. In for details. I'm gonna throw a CAS at it and see if it stops. Mostly happens on the freeway.
i had a CAS fail on me shortly after getting the car, so this one was my spare
skullzaflare is offline   Reply With Quote
Old 05-11-2012, 04:42 PM   #16
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

new turbo etc is on, still has the smoke, so must be valve seals, never felt any bucks, putting DP on this evening, car sounds like a cummins (no joke)
skullzaflare is offline   Reply With Quote
Old 05-14-2012, 03:25 AM   #17
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

car is running better now, still running e85. running 10psi on the 57/73mm, 12 makes clutch slip.
found myself running short of fuel saturday night, out messing around, after 4000rpm my afrs started dropping to 13.2
pulled the 305cc's today, threw in some low imp 660cc's, after rewiring the injector harness, i retuned the fuel, however, im having an issue at idle, its popping and idle searching
any ideas?
skullzaflare is offline   Reply With Quote
Old 05-21-2012, 12:11 AM   #18
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

the video is sideways for some reason, but it started bucking again
Attached Thumbnails
Occasional Buck-th_vid_20120520_213138.jpg
skullzaflare is offline   Reply With Quote
Old 05-24-2012, 01:31 AM   #19
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

so with gas or e85
340cc or 660cc
more advance or retarded timing
too rich to lean

i still get the buck, i completely redid my settings in TS, even disabled accel/decel, still have the buck. its almost like im loosing power when it bucks, since the tach and oil pressure gauge drops as seen in the video.
wet or dry out doesnt make a difference, however im wondering if i have a failing coil, or if by the off chance i have a spark plug partly fouled. although even if it was a miss from a plug, the tach wouldnt drop 800rpm then bounce back
the IAT is hooked up now as well, and still no change
skullzaflare is offline   Reply With Quote
Old 05-27-2012, 02:31 AM   #20
Junior Member
Thread Starter
iTrader: (2)

Join Date: Aug 2009
Location: WV
Posts: 151
Total Cats: 2
Default

so it turns out in my case, i had killed the plug wires in less than 7k miles (ngk's) and fouled 1 plug. replaced those, double checked base timing with light, was 3d advance, changed that, and its running alot smoother now, still a random pop every now and then, but no where near as bad as before
skullzaflare is offline   Reply With Quote
