Default Oil in the IC piping

So i opened the piping to install my HKS SSQV and found some oil in the Intercooler piping. I dont think its good, what causes it and how do i fix it. its a greddy kit.
redturbomiata is offline   Reply With Quote
Old 10-03-2011, 07:54 PM   #2
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Generally speaking, there are two potential causes.

One is that the shaft seals on your turbo are allowing oil to leak from the center housing into the compressor.

The other is that you have your crankcase ventilation system plumbed in such a way as to permit oil vapor to be drawn from the crankcase into the intake tract.
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 08:00 PM   #3
Senior Member
Thread Starter
iTrader: (5)

Join Date: May 2011
Location: London,OH
Posts: 1,125
Total Cats: 13
Default

Quote:
Originally Posted by Joe Perez View Post
Generally speaking, there are two potential causes.

One is that the shaft seals on your turbo are allowing oil to leak from the center housing into the compressor.

The other is that you have your crankcase ventilation system plumbed in such a way as to permit oil vapor to be drawn from the crankcase into the intake tract.
the crankcase is vented to atmosphere. so the seals are probably the cause. ideas on the fix
redturbomiata is offline   Reply With Quote
Old 10-03-2011, 08:16 PM   #4
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by redturbomiata View Post
so the seals are probably the cause. ideas on the fix
Idea: replace seals.
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 08:26 PM   #5
Elite Member

Join Date: Mar 2010
Location: Detroit
Posts: 1,524
Total Cats: 27
Default

Quote:
Originally Posted by Joe Perez View Post
Idea: replace seals.
GENIUS!!
flounder is offline   Reply With Quote
Old 10-03-2011, 08:30 PM   #6
Senior Member
Thread Starter
iTrader: (5)

Join Date: May 2011
Location: London,OH
Posts: 1,125
Total Cats: 13
Default

do they just sell the seals. all i see is rebuild kits.
redturbomiata is offline   Reply With Quote
Old 10-03-2011, 08:51 PM   #7
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by redturbomiata View Post
do they just sell the seals. all i see is rebuild kits.
Well, you could try Seals-Я-Us, Seal Depot, the Crate & Seal, Seal's Club, or perhaps Gap Seal.

Or maybe since the seals are gone, it's time for a rebuild kit anyway.
Joe Perez is offline   Reply With Quote
Old 10-06-2011, 10:56 PM   #8
Senior Member
iTrader: (3)

Join Date: Jul 2011
Location: STL
Posts: 528
Total Cats: 24
Default

Quote:
Originally Posted by Joe Perez View Post
Well, you could try Seals-Я-Us, Seal Depot, the Crate & Seal, Seal's Club, or perhaps Gap Seal.

Or maybe since the seals are gone, it's time for a rebuild kit anyway.
I was not happy with the service from Seal's Club. Their all-in-one club is really only good for baby seals despite being advertised for momma & papa too.
midpack is offline   Reply With Quote
Old 10-06-2011, 11:01 PM   #9
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,165
Total Cats: 2,573
Default

I rodered my seals straight from seals-n-****.
Great seals, and you get a discount on the ****.
18psi is offline   Reply With Quote
Old 10-06-2011, 11:10 PM   #10
Elite Member
iTrader: (12)

GeneSplicer's Avatar

Join Date: Sep 2009
Location: Birmingham, AL
Posts: 2,006
Total Cats: 147
Default

Fur real - get it rebuild or buy a new one... www.workturbochargers.com

Tell tell him Bryan referred you to recieved a 20% discount on your very own seal.
GeneSplicer is offline   Reply With Quote
Old 10-07-2011, 05:20 PM   #11
IHI
Junior Member

Join Date: Oct 2009
Location: The Netherlands
Posts: 200
Total Cats: 1
Default

I heard "Navy Seals" are superb.
IHI is offline   Reply With Quote
Old 10-08-2011, 03:46 PM   #12
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Attached Thumbnails
Oil in the IC piping-fn3lp.jpg
Faeflora is offline   Reply With Quote
Old 10-08-2011, 04:41 PM   #13
Newb

Join Date: May 2011
Location: Rogue Valley, OR
Posts: 5
Total Cats: 0
Default

this noob lol'd
jaredef is offline   Reply With Quote
Old 10-10-2011, 03:42 PM   #14
IHI
Junior Member

Join Date: Oct 2009
Location: The Netherlands
Posts: 200
Total Cats: 1
Default

Attached Thumbnails
Oil in the IC piping-weddellseal.jpg
IHI is offline   Reply With Quote
Old 10-10-2011, 03:47 PM   #15
Newb

Join Date: May 2011
Location: Seattle
Posts: 3
Total Cats: 0
Default

i would recommend seeing if an oil catch can will take care of that issue before you go replacing shaft seals. begi has a really nice oil catch can that doesn't have vacuum leaks like a large majority of them.
doolie is offline   Reply With Quote
Old 10-10-2011, 03:49 PM   #16
IHI
Junior Member

Join Date: Oct 2009
Location: The Netherlands
Posts: 200
Total Cats: 1
Default




I think I have found the cause of your failing seal:

Attached Thumbnails
Oil in the IC piping-129126495207960520.jpg
IHI is offline   Reply With Quote
Old 10-10-2011, 04:34 PM   #17
Junior Member

Join Date: Jan 2011
Location: sacramento ,ca
Posts: 402
Total Cats: 46
Default

awesome...
fastivab6tg25mr is offline   Reply With Quote
Old 10-10-2011, 09:26 PM   #18
Senior Member
Thread Starter
iTrader: (5)

Join Date: May 2011
Location: London,OH
Posts: 1,125
Total Cats: 13
Default

alright i had that coming, need rephrase what i say better. but im going to hold off for a week or two and enjoy the rest of the season, and rebuild it over the winter. before you say it i checked a little more and the leak is not to bad. i already check the oil regularly so its no big deal.
redturbomiata is offline   Reply With Quote
Old 10-11-2011, 12:57 AM   #19
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

A third option, which I failed to mention earlier, is that your drain line is not allowing oil to flow freely and it is thus being pumped through the seals.

I just noticed that you are running a Greddy kit, and if you are using the oil-return solution which came standard with those systems (a long-*** piece of rubber hose which you're meant to run all the way around the engine to the intake side) it's entirely possible that this line may be kinked, crushed, running uphill, etc.
Joe Perez is offline   Reply With Quote
Old 10-11-2011, 07:22 AM   #20
Senior Member
Thread Starter
iTrader: (5)

Join Date: May 2011
Location: London,OH
Posts: 1,125
Total Cats: 13
Default

Quote:
Originally Posted by Joe Perez View Post
A third option, which I failed to mention earlier, is that your drain line is not allowing oil to flow freely and it is thus being pumped through the seals.

I just noticed that you are running a Greddy kit, and if you are using the oil-return solution which came standard with those systems (a long-*** piece of rubber hose which you're meant to run all the way around the engine to the intake side) it's entirely possible that this line may be kinked, crushed, running uphill, etc.
yea i think it is running up about an inch or 2. i wish i would have done the work, would have done it much better than the PO
