Old 06-15-2014, 09:42 PM   #41
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

If the above doesn't work. How would I be sure the turbo is ok? Like I said before, I tried to clock it, but the c clips I saw I did not have a large enough snap ring pliers to get them apart. Plus all the rust and stuff, the thing would not budge. I suppose I could take it back off (holy moly what a pain) and pb blast the **** out of it. Maybe I can get it to budge.

Do you think if I take a picture of the housing you could tell if it's apart at all?
whinin is offline   Reply With Quote
Old 06-15-2014, 09:58 PM   #42
Senior Member
iTrader: (1)

Onyxyth's Avatar

Join Date: May 2013
Location: Boyertown, PA
Posts: 719
Total Cats: 55
Default

Have you run a compression test?
Onyxyth is offline   Reply With Quote
Old 06-16-2014, 07:02 AM   #43
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

I have not, I will bring home the tester today from work.
whinin is offline   Reply With Quote
Old 06-16-2014, 09:03 AM   #44
Former Vendor

Join Date: Dec 2007
Location: Texas Hill Country
Posts: 271
Total Cats: 16
Default

I've not read all of this thread, but is it possible you've overlooked the wastegate actuator?

check for play on the valve lever arm. If you can wiggle it at all, it is too loose.

IF the actuator is set too loose, the boost can be way off, as well as very sluggish. IF the turbo has a turn buckle push rod, pull the circlip off at the valve end and shorten the rod until the turnbuckle hole is one diameter shorter than dropping onto the pin without any pull on the rod. THat should be enough preload to make 6 psi, or so.

If no turnbuckle, wire the valve shut somehow and drive it. IF this is the culprit, wiring it shut will eliminate boost control, so use a bit of caution.

corky
Corky Bell is offline   Reply With Quote
Old 06-17-2014, 12:23 PM   #45
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

Ok, so I tied the wastegate open, removed the FMU, and took it for a spin. Full throttle at anything under 3k, the motor searches between 13.9-15.3 afrs. After 3k, it dumps fuel and runs an almost steady 11.5 afr. Now I have the 99-00 injectors in there, so that's understandable. But what I don't get is why it's surging at the lower rpm. Is because of the bigger injectors as well?

Any ideas?
whinin is offline   Reply With Quote
Old 06-17-2014, 12:24 PM   #46
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

And I did what you said corky before I did the above, no change in boost.
whinin is offline   Reply With Quote
Old 06-17-2014, 12:26 PM   #47
Senior Member
iTrader: (5)

Join Date: Nov 2013
Location: Wisconsin
Posts: 659
Total Cats: 66
Default

I now understand why everyone says to "get rid of the bandaids", and glad I didn't go that route.

Your low boosting issues aside, it would drive me nuts to not know why my car was at a certain AFR.

You sure you ain't knockin?
mlev is offline   Reply With Quote
Old 06-17-2014, 12:34 PM   #48
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

I have not heard any pinging or anything. Only thing I hear is when I free rev the motor, once it gets close to idle, I hear a few knocks. I think it has something to do with the transmission because I don't hear it if I rev it at the motor.
whinin is offline   Reply With Quote
Old 06-17-2014, 12:49 PM   #49
I'm a terrible person
iTrader: (19)

FRT_Fun's Avatar

Join Date: Apr 2009
Location: Arizona
Posts: 7,293
Total Cats: 180
Default

in before blown motor.
FRT_Fun is offline   Reply With Quote
Old 06-17-2014, 12:50 PM   #50
Junior Member
iTrader: (5)

Join Date: Jul 2007
Location: South Jersey
Posts: 112
Total Cats: 1
Default

So, you've ruled out the following so far:
  • boost leak
  • wastegate

And you say it's not the turbo or the injectors.

As suggested earlier, run it with the catalytic converter/mid pipe off. It will be loud, but all you need is one run to see if it will build boost with an open pipe.

Which spot are you using as your signal line for the rising rate FMU? I've had good results with teeing off the stock FPR.
bogly is offline   Reply With Quote
Old 06-17-2014, 12:52 PM   #51
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

Yeah, I dunno. Like I said, I've had this car for a few months now so I'm still learning how the PO took care of it. It very well could be on its last leg. I don't think the knocking sound is in the motor though. I can hear it when I'm sitting the car, but not outside at the front of the car.
whinin is offline   Reply With Quote
Old 06-17-2014, 12:54 PM   #52
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

It was tee'd off at the FPR after I fixed the lines. They had like a mini vacuum block thing with about 5 lines coming off it. I didn't think that was good. I will have to see if I can get the bolts loose on the catalytic converter. If I can't I may just sawzall it off. Might be trying that today.
whinin is offline   Reply With Quote
Old 06-17-2014, 12:56 PM   #53
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,192
Total Cats: 2,583
Default

Clogged cat is starting to sound more and more likely
18psi is offline   Reply With Quote
Old 06-17-2014, 01:20 PM   #54
Senior Member
iTrader: (5)

Join Date: Nov 2013
Location: Wisconsin
Posts: 659
Total Cats: 66
Default

Attached Thumbnails
Turbo boosting 2psi only, stumped.-cat2.jpg
mlev is offline   Reply With Quote
Old 06-17-2014, 04:51 PM   #55
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

Ummmmmmmmmm. How do I turn the boost down?

Cut the cat out, holy ****. Runs 8psi, afr spikes to 14.2 around 5k. Bad. Bandaid, I know. Will be fixing soon.

EEeeeeeeeeeee!!!! It works!

I cut myself pretty bad, but worth it! OMG the pull!
whinin is offline   Reply With Quote
Old 06-17-2014, 04:58 PM   #56
Junior Member
iTrader: (5)

Join Date: Jul 2007
Location: South Jersey
Posts: 112
Total Cats: 1
Default

Extend the threaded wastegate actuator arm a little bit, but make sure that it's still pulling on the wastegate to keep it closed.
If it's too loose (too long), it will essentially keep the wastegate open or open prematurely, causing you to lose spool.

14.2 AFR @ 8 psi is dangerously *lean*. Once the FMU sees positive pressure, your AFR should start dipping into 13 and continue to get more fuel down to 11's the more you get into boost.
Fix/adjust that first.
bogly is offline   Reply With Quote
Old 06-17-2014, 05:05 PM   #57
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 782
Default

Quote:
Originally Posted by FRT_Fun View Post
in before blown motor.
Quote:
Originally Posted by whinin View Post
Ummmmmmmmmm. How do I turn the boost down?

Cut the cat out, holy ****. Runs 8psi, afr spikes to 14.2 around 5k. Bad. Bandaid, I know. Will be fixing soon.

EEeeeeeeeeeee!!!! It works!

I cut myself pretty bad, but worth it! OMG the pull!

Well then!
concealer404 is offline   Reply With Quote
Old 06-17-2014, 05:12 PM   #58
Senior Member
iTrader: (3)

Join Date: Apr 2011
Location: Volo, IL
Posts: 1,247
Total Cats: 140
Default

Quote:
Originally Posted by whinin View Post
How do I turn the boost down?
On the right side of the car's floorboard there is a pedal attached to the throttle body via a cable. When driving, press lighter on that pedal. If you are still getting into boost, depress the pedal even lighter.
dieselmiata is offline   Reply With Quote
Old 06-17-2014, 05:15 PM   #59
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

You gays. I mean guys.

I think why I was boosting that much was because the clip fell off the actuator arm and the actuator slid off the valve. But fixed now, car hits 6psi then pulls back to 5psi, all under 12.1 afr. Sometimes as rich as 11.0.
whinin is offline   Reply With Quote
Old 06-17-2014, 05:18 PM   #60
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Elgin, SC
Posts: 359
Total Cats: -4
Default

If not and that has nothing to do with it I will still make the arm longer.

Above question deserved that answer diesel, I was just too excited. Literally shaking, I held my hands out and they slowly started twitching, then onto full on seizure. Way too much adrenaline going, but so happy we figured it out.
whinin is offline   Reply With Quote
