Default oil pressure?

does anybody on here have oil pressure issues? im assuming its the sensor or gauge itself... but at idle im at 60



and under a little throttle, it spikes at 90 (the highest it goes)

Attached Thumbnails
oil pressure?-2lw5fno.jpg   oil pressure?-1emalj.jpg
supercooper is offline   Reply With Quote
Old 04-22-2013, 02:26 PM   #2
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

im ASSUMING bad gauge/sensor or whatever.... have a pressure tester on the way.... should have had one a while ago........

any thoughts???
supercooper is offline   Reply With Quote
Old 04-22-2013, 02:29 PM   #3
Elite Member
iTrader: (2)

fooger03's Avatar

Join Date: Jan 2009
Location: Columbus, OH
Posts: 4,132
Total Cats: 187
Default

If that's cold-idle....your gauge and your sender are fine, I'd look for problems with the bypass valve in your oil pump...

If that's hot-idle.... I'd clean the connection at the sender first.
fooger03 is offline   Reply With Quote
Old 04-22-2013, 02:37 PM   #4
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

Quote:
Originally Posted by fooger03 View Post
If that's cold-idle....your gauge and your sender are fine, I'd look for problems with the bypass valve in your oil pump...

If that's hot-idle.... I'd clean the connection at the sender first.


yeah, its cold idle... when hot, its usually around 40-50ish... but under load, spikes back up to around 90 again.
supercooper is offline   Reply With Quote
Old 04-22-2013, 05:27 PM   #5
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,008
Total Cats: 583
Default

It is normal for cold oil pressure to be quite a bit higher than hot oil pressure due to the viscosity change of the oil. And we don't mean hot as in "coolant temperature at mid-range." We're talking 15-20 minutes of loaded operation after that -- it takes time for the oil to come up to temperature.
hornetball is offline   Reply With Quote
Old 04-22-2013, 06:24 PM   #6
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

Quote:
Originally Posted by hornetball View Post
It is normal for cold oil pressure to be quite a bit higher than hot oil pressure due to the viscosity change of the oil. And we don't mean hot as in "coolant temperature at mid-range." We're talking 15-20 minutes of loaded operation after that -- it takes time for the oil to come up to temperature.
yeah, i understand that... ive just never seen pressure jump so high under load on any other vehicles... not even my other miata.

its within normal limits at idle after warmup, but a little throttle changes that quickly
supercooper is offline   Reply With Quote
Old 04-22-2013, 06:34 PM   #7
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

All else being equal, assuming your gauge is accurate and your engine is in good health, we expect the oil pressure to behave roughly as follows:

When cold:
Idle = 30-50 PSI
3,00 RPM = 60-70 PSI

When warm:
Idle = 20-30 PSI
3,000 RPM = 60 PSI.

These numbers are not from the manual, just my personal experience.

If the warm oil pressure exceeds 60 PSI by a great amount, this may be indicative that the oil pressure control valve inside the oil pump is stuck closed. It's harder to make accurate judgements about cold oil pressure, simply because it's thick enough to out-flow the valve.
Joe Perez is offline   Reply With Quote
Old 04-22-2013, 06:38 PM   #8
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

Quote:
Originally Posted by Joe Perez View Post
All else being equal, assuming your gauge is accurate and your engine is in good health, we expect the oil pressure to behave roughly as follows:

When cold:
Idle = 30-50 PSI
3,00 RPM = 60-70 PSI

When warm:
Idle = 20-30 PSI
3,000 RPM = 60 PSI.

These numbers are not from the manual, just my personal experience.

If the warm oil pressure exceeds 60 PSI by a great amount, this may be indicative that the oil pressure control valve inside the oil pump is stuck closed. It's harder to make accurate judgements about cold oil pressure, simply because it's thick enough to out-flow the valve.
well... im probably gonna switch over the cluster from my other NA, and see if its the same... then, go to the sender next, then the valve after that, if its not one of those 2...

i wouldnt doubt that the gauge is fucked though, because the tach is about 1k higher than actual RPM's at ALL times... idk what this guy did... didnt care too much for the last few years, because it was just a DD/toy, but i wanna get it all straight, and all these little quirks are pissing me off... lol
supercooper is offline   Reply With Quote
Old 04-22-2013, 06:53 PM   #9
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,164
Total Cats: 2,573
Default

just get one of these:

Attached Thumbnails
oil pressure?-9znck.jpg
18psi is offline   Reply With Quote
Old 04-22-2013, 06:54 PM   #10
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

hah... i should... i would rock the **** out of that cluster.... lol
supercooper is offline   Reply With Quote
Old 04-28-2013, 06:21 PM   #11
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

alright, pulled out the cluster to work on the Tach, and noticed a light i dont recognize. it does NOT come on when i turn key to ACC on either one of my miatas.

What is the indicator above the fuel gauge on the NA miatas(little square light)? airbag, or abs or something???
supercooper is offline   Reply With Quote
Old 04-28-2013, 06:39 PM   #12
I haz no trubo
iTrader: (2)

Oscar's Avatar

Join Date: Jan 2007
Location: Bolton, UK
Posts: 3,020
Total Cats: 114
Default

Hardtop defroster would be my guess.
Oscar is offline   Reply With Quote
Old 04-28-2013, 07:12 PM   #13
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

well.. that would make sense... since as much as i would love to have one, neither of my cars do... haha
thanks!
supercooper is offline   Reply With Quote
Old 04-28-2013, 07:36 PM   #14
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by Oscar View Post
Hardtop defroster would be my guess.
Quite possible.

There have been a couple of different NA gauge clusters. On my '90, for instance, there is no indicator space in that position. So it could well be the HT defroster, which was not available in that year. (My gauge cluster also lacks the cutout for the washer fluid light, as ABS wasn't available in '90. But that light goes in the center, between the speedo and tach.)
Joe Perez is offline   Reply With Quote
Old 04-28-2013, 07:54 PM   #15
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

Quote:
Originally Posted by Joe Perez View Post
Quite possible.

There have been a couple of different NA gauge clusters. On my '90, for instance, there is no indicator space in that position. So it could well be the HT defroster, which was not available in that year. (My gauge cluster also lacks the cutout for the washer fluid light, as ABS wasn't available in '90. But that light goes in the center, between the speedo and tach.)
i have the connectors for the rear defroster, so i assume it was available in '92. my other miata is a 90... does NOT have the connectors.. but still has an indicator space. Im obviously not the original owner of THAT miata either, so i think the cluster may have been replaced at one time, with one that has the same indicator. i just looked around online, and some clusters have them, and some dont.
supercooper is offline   Reply With Quote
Old 04-28-2013, 09:01 PM   #16
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

The defogger wiring was added in late '91 for the '92 model year, I'm not sure when the number of idiot-light positions in the cluster was increased.

Here's what my '90 instrument panel looks like:




You'll note that it's missing both the rectangular light above the fuel gauge (rear defogger) as well as the two round lights to the left and right of the central square panel (ABS and washer fluid.)


Sidebar: if you do a Google Images search for Miata Instrument Cluster, this guy shows up:

Attached Thumbnails
oil pressure?-img_2233.jpg

Last edited by Joe Perez; 04-28-2013 at 09:34 PM.
Joe Perez is offline   Reply With Quote
Old 04-28-2013, 09:12 PM   #17
Senior Member
Thread Starter

Join Date: May 2011
Location: Pennsylvania
Posts: 1,119
Total Cats: 33
Default

Quote:
Originally Posted by Joe Perez View Post

Sidebar: if you do a Google Images search for Miata Instrument Cluster, this guy shows up:

thats because that guy is a Bawsss.... lol

yup, thats what alot of the clusters i found online looked like. thats why my little rectangle cornfused me. i would almost prefer that cluster... although, being that none of those extra indicators are lit up, it doesnt really bother me too much.

Thanks man!!
Attached Thumbnails
oil pressure?-toht.jpg
supercooper is offline   Reply With Quote
