Old 03-07-2014, 11:12 AM   #141
Elite Member
iTrader: (13)

Join Date: Dec 2006
Location: Taos, New mexico
Posts: 5,701
Total Cats: 236
Default

Quote:
Originally Posted by hornetball View Post
It was a Mazdaspeed short shifter. It was basically the same overall length as the OEM (so it didn't move the shifter closer to the wheel or anything) but it moved the fulcrum up. End result was that effort increased, distances between the gates got minimized and, because of the increased effort, you really didn't shift any faster (which isn't much of a limitation on a 5-speed anyway). Felt like a money-shift setup to me -- and, since Mazdaspeed sells crate engines, that makes sense. LOL.

The discussion on the long/angled Roadstersport shifter in the other thread has me intrigued though. But, honestly, I've never been unhappy on track with the OEM 5-speed shifter.
I was looking at some of those 3" extensions that thread onto the oem shifter. What do you track guys think about that?
Fireindc is offline   Reply With Quote
Old 03-07-2014, 11:32 AM   #142
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,460
Total Cats: 781
Default

Quote:
Originally Posted by Fireindc View Post
I was looking at some of those 3" extensions that thread onto the oem shifter. What do you track guys think about that?


It's really good for powering through syncros.
concealer404 is offline   Reply With Quote
Old 07-16-2014, 10:04 PM   #143
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,008
Total Cats: 583
Default

I'm going through the engine on my Red car to fix an oil consumption issue (rings never seated after last rebuild by PO).

Just noticed that you did Supertech 11:1 but shaved them to reduce the compression ratio. Right now my engine has the 2001 pistons, but I was thinking about Supertechs to get the extra point of compression. Now, I'm like "hmmmmm . . . ."

Was that just a concession to CA91? Or was there a performance/longevity reason?
hornetball is offline   Reply With Quote
Old 07-16-2014, 10:21 PM   #144
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Quote:
Originally Posted by hornetball View Post
I'm going through the engine on my Red car to fix an oil consumption issue (rings never seated after last rebuild by PO).

Just noticed that you did Supertech 11:1 but shaved them to reduce the compression ratio. Right now my engine has the 2001 pistons, but I was thinking about Supertechs to get the extra point of compression. Now, I'm like "hmmmmm . . . ."

Was that just a concession to CA91? Or was there a performance/longevity reason?
CA91

It's oxygenated, farm raised, free range, vegan and made from all organic ingredients. Depending on the build, we have struggled to hit MBT in every cell at 11.0:1 so we just dial it back. With coated chambers or small cams like an NA8, it's easier to do. Get it breathing with an NB head and a bit of porting/chamber work and you'll see 105kpa at 5500rpm. Too much cylinder pressure for the coors light we call gasoline out here. Jelly of all the states with 93 where you can safely run 11.0:1 with careful tuning.
emilio700 is offline   Reply With Quote
Old 09-03-2014, 12:38 AM   #145
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default Deviate

We just dropped in a 1.9L built race engine, our +2 exhaust CNC head, Tomei cams, ceramic thermal coated chambers/crowns/valves, exhaust ports and of course, that C30-74 Rotrex from Jackson Racing. ID1000's, on E85. We're aiming for 300whp+. We will be giving rides in it this weekend at MRLS. Renamed it "Deviate". Seemed appropriate as we deivated from the cars original mission to exemplify a simple N/A HPDE build, plus it is a mischievous car with instant boost.

Rushing to get it tuned and ready for MRLS so we're leaving a few things undone. Will update in the coming weeks

emilio700 is offline   Reply With Quote
Old 09-03-2014, 12:43 AM   #146
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,008
Total Cats: 583
Default

Hmmmmm . . . . You might have to give up your quote.

Still no oil cooler?
hornetball is offline   Reply With Quote
Old 09-03-2014, 12:49 AM   #147
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Quote:
Originally Posted by hornetball View Post
Hmmmmm . . . . You might have to give up your quote.

Still no oil cooler?
It's had a cute little Setrab with a fan for years. It now has a much bigger Setrab and another Setrab for the Rotrex oil. Not mounted in ideal location now but we'll have time to rework that after MRLS.
emilio700 is offline   Reply With Quote
Old 09-03-2014, 01:01 AM   #148
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,163
Total Cats: 2,573
Default

So...umm...can I "book" a ride in this beast?
18psi is offline   Reply With Quote
Old 09-03-2014, 01:20 AM   #149
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Quote:
Originally Posted by 18psi View Post
So...umm...can I "book" a ride in this beast?
No list. Just first come first serve.
emilio700 is offline   Reply With Quote
Old 09-03-2014, 01:29 AM   #150
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,008
Total Cats: 583
Default

Quote:
Originally Posted by emilio700 View Post
It's had a cute little Setrab with a fan for years. It now has a much bigger Setrab and another Setrab for the Rotrex oil. Not mounted in ideal location now but we'll have time to rework that after MRLS.
Yeah, I put a huge Canton Racing unit on mine.

I saw the lines for the Rotrex, but couldn't spot the lines for engine oil. They're well hidden!

You ever plan to visit Hallett or any TX tracks again? Hallett's been resurfaced!

Good luck at MRLS!
hornetball is offline   Reply With Quote
Old 09-03-2014, 03:44 AM   #151
NB/VVT Connoisseur
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 6,065
Total Cats: 253
Default

Neat.
viperormiata is offline   Reply With Quote
Old 09-03-2014, 04:33 AM   #152
Senior Member
iTrader: (14)

Join Date: Oct 2006
Location: Las Cruces, NM
Posts: 1,401
Total Cats: 257
Default

Emilio, any plans for a cold air intake?
99mx5 is offline   Reply With Quote
Old 09-03-2014, 11:49 AM   #153
Elite Member
iTrader: (2)

Mobius's Avatar

Join Date: May 2008
Location: Portland, Oregon
Posts: 3,176
Total Cats: 261
Default

Very nice.

What diameter nose pulley is that? I notice many ribs on that belt ... details on the crank pulley? I've had several people inquire about my setup, and I use the 80mm 4 rib pulley which Skunk2 no longer produces. Attempts by them to use the 4 rib belt with the higher rib count nose pulleys that are available have resulted in the belt walking around.
Mobius is offline   Reply With Quote
Old 09-03-2014, 12:17 PM   #154
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Quote:
Originally Posted by viperormiata View Post
Neat.


Doth mine eyes deceive or is that an IAT sensor plugged into the back of the manifold?
EO2K is offline   Reply With Quote
Old 09-03-2014, 01:54 PM   #155
Junior Member

Join Date: Sep 2011
Location: finger lakes NY
Posts: 444
Total Cats: 17
Default

Is your clutch master reservoir doing double duty as a catch can? That's genius!
DaveC is offline   Reply With Quote
Old 09-03-2014, 01:59 PM   #156
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

I'm pretty sure that's a Moroso catch can in front of the clutch master. Perspective y0
EO2K is offline   Reply With Quote
Old 09-03-2014, 02:03 PM   #157
Supporting Vendor
Thread Starter
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Quote:
Originally Posted by hornetball View Post
Yeah, I put a huge Canton Racing unit on mine.

I saw the lines for the Rotrex, but couldn't spot the lines for engine oil. They're well hidden!

You ever plan to visit Hallett or any TX tracks again? Hallett's been resurfaced!

Good luck at MRLS!
Not likely to ever visit Hallett again. Too far. The relative order under the hood is a reflection on John's sensibilities, the guy that builds everything here. He likes things visually simple. Complete wire tuck on his car "Mental":

IMAG0044_zps5652fd19.jpg?
IMAG0047_zpsd038a282.jpg?

Quote:
Originally Posted by EO2K View Post
Doth mine eyes deceive or is that an IAT sensor plugged into the back of the manifold?
That's where we always run them on F/I builds here.
You missed the 40mm wastegate with vband flange welded onto the squaretop right next to it.

Quote:
Originally Posted by 99mx5 View Post
Emilio, any plans for a cold air intake?
Nope. That's the production location but with a slightly larger filter. We'll add some heat insulation on the intake piping next to the header. In practice, we see very low IAT's so it's more to make the silicone couplers happy. On a purpose built track or autocross car, one could relocate and shroud the filter.

Quote:
Originally Posted by Mobius View Post
Very nice.

What diameter nose pulley is that? I notice many ribs on that belt ... details on the crank pulley? I've had several people inquire about my setup, and I use the 80mm 4 rib pulley which Skunk2 no longer produces. Attempts by them to use the 4 rib belt with the higher rib count nose pulleys that are available have resulted in the belt walking around.
95mm x 150mm, 119,800 @ 8000rpm.

This is the proprietary SuperMiata steel crank damper and aluminum overlay pulley we will offer for the kits. It is configured as an overlay so the S/C loads are fed directly into the steel hub, not the damped steel outer ring. This allows the damper ring to do it's job just it does in an N/A application.

The belt centerline of the the JR Rotrex is different that pretty much all other S/C kits so this is a JR Rotrex only setup. We will have these special S/C dampers available for about $600 when the production S/C kits begin shipping in a few months.

emilio700 is offline   Reply With Quote
Old 09-03-2014, 02:07 PM   #158
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Quote:
Originally Posted by emilio700 View Post
That's where we always run them on F/I builds here.
You missed the 40mm wastegate with vband flange welded onto the squaretop right next to it.
Oh it didn't escape my notice. I've been sitting here trying to grok why one would put a wastegate after the throttle body, but have been afraid to ask

I didn't realize John had a Miata. Needs something to drive when the 928 goes all Porsche on him?
EO2K is offline   Reply With Quote
Old 09-03-2014, 02:14 PM   #159
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,008
Total Cats: 583
Default

Quote:
Originally Posted by EO2K View Post
I've been sitting here trying to grok why one would put a wastegate after the throttle body
Actually, why have a wastegate with a supercharger? It's not like we're trying to keep the turbo spooled. Are you using it to protect components around the intake from being overpressurized? And what are the rubber hoses around the wastegate? Something to do with CARB? There seems to be a lot of stuff here that I'm not familiar with. It's pretty cool.
hornetball is offline   Reply With Quote
Old 09-03-2014, 02:27 PM   #160
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

My Rotrex had a BOV in front of the throttle body for the same reason a turbo has a BOV in front of the throttle body. Its the back of the manifold that has me screwed up.

The Rotrex does its best work in the upper RPM range, so spinning the hell out of it is actually beneficial provided you are under the -74's 120,000 RPM redline. The problem is that you may actually be moving more air that you want/need. You don't want to compromise things with a restrictor at the compressor, so bleeding off the air (like a wastegate bleeds off exhaust) makes some sense. You still have flat boost response at WOT and you keep the blower in its efficiency range without blowing things up.

So I'm guessing its some sort of epic boost control. It's been discussed in the past, but I've not seen it implemented. I bet it'd be loud as ****.

I'm probably totally wrong though
EO2K is offline   Reply With Quote
