Default How are you strapping down your car?

All the factory tow points have been removed from the car and spec tow hooks added but you can't use them to secure the car on a trailer. I have been routing axle straps through my wheels to strap it down but an starting to think that is messing with my alinement. How are you all strapping down your cars on your trailers?
jeff_man is offline   Reply With Quote
Old 01-31-2014, 07:41 PM   #2
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,895
Total Cats: 109
Default

I have been using the front and rear sub-frame braces as my tie down points.

At the drag strip, I actually remove the braces after I unload the car and reinstall them when I am ready to load the car back on the trailer. They are just unnecessary weight at the drag strip.
miata2fast is online now   Reply With Quote
Old 01-31-2014, 09:26 PM   #3
Senior Member
iTrader: (1)

Join Date: Mar 2008
Location: Cromwell CT
Posts: 1,106
Total Cats: 48
Default

i used to go through my rear wheels, and I used the front hoop on my tube from with the bumper off, that doesn't apply to most thought.
ctdrftna is offline   Reply With Quote
Old 01-31-2014, 10:57 PM   #4
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,092
Total Cats: 90
Default

I put the tow hooks back on to tow it with. If they were good enough for it getting tossed around on the open ocean for 7000 miles and getting slammed around by some union crane jock, they're good enough for a trailer with suspension.

If I had a trailer with e-track I would use e-track loops over the wheels.
Leafy is offline   Reply With Quote
Old 02-01-2014, 01:33 AM   #5
Elite Member
Thread Starter
iTrader: (7)

jeff_man's Avatar

Join Date: May 2007
Location: Dallas, Tx
Posts: 3,056
Total Cats: 103
Default

I can install e-track, was thinking about that.
jeff_man is offline   Reply With Quote
Old 02-01-2014, 02:26 AM   #6
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,806
Total Cats: 183
Default

Since I drift, I feel that there is no reason to strap my car down. I just pull on the 3' extended e brake handle and if it falls off the trailer, f^ck it. It'll look better with accidental damage than it will after my drift "race".
thirdgen is offline   Reply With Quote
Old 02-01-2014, 12:59 PM   #7
Junior Member

Join Date: Mar 2013
Location: Flower Mound, TX
Posts: 235
Total Cats: 26
Default

I'm using U-Haul trailers, they have straps over the front tires. I'm assuming two things:
1. This allows the car's suspension to handle the weight of the car.
2. Any stresses from bumps on the trailer, with it's suspension, is much less than hitting a curb on track at 70 mph.
EricJ is offline   Reply With Quote
Old 02-01-2014, 10:42 PM   #8
Junior Member

Join Date: Aug 2010
Location: Texas
Posts: 162
Total Cats: 11
Default

I strap through the wheels. As EricJ mentions, the suspension is allowed to work without "working" the straps. Some folks are concerned that this will upset alignment, I can't really speak to that. Savington mentioned that he straps this way and the alignment does not move here: Miata tie down points on trailer [Archive] - MX-5 Miata Forum

robert
robertcope is offline   Reply With Quote
Old 02-02-2014, 12:03 AM   #9
Newb

Join Date: Nov 2013
Posts: 42
Total Cats: 0
Default

Through the wheels here. No problems ever. I also do not keep my car in gear, heard from a spec miata racer years ago that bouncing and rocking can blow the first gear in trans if you keep it gear. Don't know if that's true but never wanted to risk it!
No lift is offline   Reply With Quote
Old 02-02-2014, 11:37 AM   #10
Elite Member
Thread Starter
iTrader: (7)

jeff_man's Avatar

Join Date: May 2007
Location: Dallas, Tx
Posts: 3,056
Total Cats: 103
Default

In my mind over the wheels is just holding the car down with out any side to side force. Through the wheels your putting directional force on the edge of the wheel away from the car. It's like putting your car in a vice and pulling the alignment and/or toe out of whack.

Now that could not be the case as I'm over thinking it and/or the alignment, toe set points are a lot stronger than I think.
jeff_man is offline   Reply With Quote
Old 02-02-2014, 04:09 PM   #11
Junior Member

Join Date: Dec 2010
Location: Phoenix
Posts: 146
Total Cats: 3
Default

Quote:
Originally Posted by EricJ View Post
I'm using U-Haul trailers, they have straps over the front tires. I'm assuming two things:
1. This allows the car's suspension to handle the weight of the car.
2. Any stresses from bumps on the trailer, with it's suspension, is much less than hitting a curb on track at 70 mph.
Slightly off-topic, but I'm renting a U-Haul for the NASA event next weekend... what do you tow that setup with?
Nate99 is offline   Reply With Quote
Old 02-03-2014, 06:31 AM   #12
Senior Member

Join Date: Dec 2004
Location: Brisbane, Australia
Posts: 1,272
Total Cats: 32
Default

Over the tyres here too (around the tread, not across it).
timk is offline   Reply With Quote
Old 02-03-2014, 07:48 AM   #13
I haz no trubo
iTrader: (2)

Oscar's Avatar

Join Date: Jan 2007
Location: Bolton, UK
Posts: 3,021
Total Cats: 114
Default

All our racecars are strapped down like this:

Attached Thumbnails
How are you strapping down your car?-large_5894_0228011233.jpg
Oscar is offline   Reply With Quote
Old 02-03-2014, 09:16 PM   #14
Junior Member

Join Date: Mar 2013
Location: Flower Mound, TX
Posts: 235
Total Cats: 26
Default

Quote:
Originally Posted by Nate99 View Post
... what do you tow that setup with?
2013 F-150 Ecoboost w/ HD Payload and Max Tow. 11,300 tow capacity w/ 2,580 payload.
Get the 7 or 7.5. The fender folds down lower so you can open the Miata's door. The 6.5 is 2 inches taller. The trailers weigh 2,100lbs. My Miata is around 2,200 lbs. For a total of 4,300 lbs. But make sure you tell them you have a 8,000 lb hitch.
EricJ is offline   Reply With Quote
Old 02-05-2014, 04:57 PM   #15
Elite Member
Thread Starter
iTrader: (7)

jeff_man's Avatar

Join Date: May 2007
Location: Dallas, Tx
Posts: 3,056
Total Cats: 103
Default

Quote:
Originally Posted by EricJ View Post
2013 F-150 Ecoboost w/ HD Payload and Max Tow. 11,300 tow capacity w/ 2,580 payload.
Get the 7 or 7.5. The fender folds down lower so you can open the Miata's door. The 6.5 is 2 inches taller. The trailers weigh 2,100lbs. My Miata is around 2,200 lbs. For a total of 4,300 lbs. But make sure you tell them you have a 8,000 lb hitch.
Take your big money and get the **** out of my thread. Poverty tower with 2000 1/2 ton suburban.
jeff_man is offline   Reply With Quote
Old 02-05-2014, 10:49 PM   #16
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

I loop long axle straps through the wheels when there is no good tie down point. The straps have soft sleeves over them to prevent wheel damage. I have never caused an alignment problem or scratched wheels with this method.
Ben is offline   Reply With Quote
Old 02-06-2014, 11:38 AM   #17
Elite Member

Join Date: Jul 2007
Location: Little Rock, AR
Posts: 3,110
Total Cats: 127
Default

When there are no good tie down points I use the lower a arms front and rear, never had a problem that way for over 10 years and thousands of miles. With any form of strap always check them quickly within 30 miles. I use the big yellow industrial ratchets with no problems. Never, ever, even for a lawn mower, use those motorcycle slip cam straps. They have failed every time I've seen someone use them.
jacob300zx is offline   Reply With Quote
Old 02-06-2014, 12:21 PM   #18
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by jacob300zx View Post
Never, ever, even for a lawn mower, use those motorcycle slip cam straps. They have failed every time I've seen someone use them.
Cam straps aren't suitable for holding down a car, but I use them all the time for dirtbikes and what not, never an issue. You have to make sure that the suspension is fully compressed or has a "shock saver" properly installed. I personally have never used a shock saver, and have never had a bike come loose or blown a fork seal.
Ben is offline   Reply With Quote
