Default Standalone Blinkers/brake lights help

Hello folks, as of recent i got a second vehicle that needs a lot of work. This may not be a miata directly but its similar.

I'm looking to add blinkers and brake lights to a vehicle that doesnt have them. Anyone has any experience with what i need to buy?
triple88a is offline   Reply With Quote
Old 09-02-2015, 10:04 PM   #2
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

There are loads of universal turn signal switches out there. Google "universal turn signal switch"



As for brake lights, a lot of vehicles (including VW Beetles) used to use pressure switches attached to the brake line to actuate the lights. You can find these cheaply and plentifully in the aftermarket with just a Google search as well, and this will probably be easier to implement than a plunger switch on the pedal.

Examples:

JEGS Hydraulic Brake Light Switch |

http://www.summitracing.com/parts/PRF-80174/
Joe Perez is online now   Reply With Quote
Old 09-02-2015, 10:26 PM   #3
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

Well i want 1 bulb for both per side.
triple88a is offline   Reply With Quote
Old 09-02-2015, 10:50 PM   #4
Junior Member
iTrader: (2)

Join Date: Apr 2010
Location: albion, mi
Posts: 303
Total Cats: 17
Default

Quote:
Originally Posted by triple88a View Post
Well i want 1 bulb for both per side.
So run a relay, use the pressure switch to turn it on
glade is offline   Reply With Quote
Old 09-02-2015, 11:01 PM   #5
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

How about these? Would the pressure switch go where the "stoplight" is and then to 12v?

Universal Turn Signal Switch | 7-wire unit for vehicles with combination stop and turn signal lamps requiring brake light circuit.
triple88a is offline   Reply With Quote
Old 09-02-2015, 11:02 PM   #6
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

Quote:
Originally Posted by triple88a View Post
Well i want 1 bulb for both per side.




EDIT: Yeah, the switch you linked to above is the kind you want.
Attached Thumbnails
Standalone Blinkers/brake lights help-signal_3_3rd_light.gif
Joe Perez is online now   Reply With Quote
Old 09-02-2015, 11:35 PM   #7
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

Got any clue what relay i'll need for LEDs?
triple88a is offline   Reply With Quote
Old 09-03-2015, 12:00 AM   #8
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

Quote:
Originally Posted by triple88a View Post
Got any clue what relay i'll need for LEDs?
3 terminal LED turn signal flasher
Joe Perez is online now   Reply With Quote
Old 09-03-2015, 01:35 AM   #9
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

lol are they all made the same? Dont exactly know how they work.
triple88a is offline   Reply With Quote
Old 09-03-2015, 09:50 AM   #10
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

Quote:
Originally Posted by triple88a View Post
lol are they all made the same? Dont exactly know how they work.
No, there are several basic types, mostly differentiated by whether they have two, three or four terminals. But since you're doing this from scratch, any one that works with LEDs can be wired in.

The place you linked to earlier sells this one: LED Flasher - Electronic flasher for LED lights
Joe Perez is online now   Reply With Quote
Old 09-03-2015, 11:22 AM   #11
Hug Life
iTrader: (3)

Monk's Avatar

Join Date: Apr 2014
Location: Huntington, Indiana
Posts: 2,803
Total Cats: 494
Default

Relevant to a build of mine as well.
Thanks for the links.
Monk is offline   Reply With Quote
Old 09-03-2015, 02:25 PM   #12
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

Ah, one more question, do i need relays for the blinkers/tails or do i just run the wires directly from the universal switch i posted above? In the pic i dont see relays but i'm not sure. Thanks
triple88a is offline   Reply With Quote
Old 09-03-2015, 03:35 PM   #13
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

Quote:
Originally Posted by triple88a View Post
Ah, one more question, do i need relays for the blinkers/tails or do i just run the wires directly from the universal switch i posted above? In the pic i dont see relays but i'm not sure. Thanks
No relays needed. These are all fairly low-current loads, even more so if using LEDs.
Joe Perez is online now   Reply With Quote
Old 10-04-2015, 05:20 PM   #14
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

triple88a is offline   Reply With Quote
Old 10-04-2015, 06:05 PM   #15
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,324
Total Cats: 1,922
Default

Attached Thumbnails
Standalone Blinkers/brake lights help-80-led_e0914951b0d21db54ece16ef0d58290efb77bb67.jpg
Joe Perez is online now   Reply With Quote
Old 10-04-2015, 08:40 PM   #16
Elite Member
Thread Starter
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

That was what was already installed on the jeep. Eventually i'll get LEDs but for now i'll just reuse.
