Default what is this "CLANK-CLANK-CLANK-CLANK" noise?

I have a horrible clanking noise coming from the front of the motor that I thought was a lifter, then pulled the valve cover and everything looks good with no metal and no strange wear. When tuning the crank by hand I hear/feel a tick on the crank rpm, not the valve train.

I'm going to go ahead and buy expensive feelers and check the valves, but I fear bottom end disaster like a spun bearing. Are there any other ideas on what this could be?

So much for TXMC Houston.
hustler is offline   Reply With Quote
Old 01-17-2010, 10:47 AM   #2
Miotta FTW!
iTrader: (24)

Splitime's Avatar

Join Date: Jun 2006
Location: Chicagoland, IL
Posts: 4,295
Total Cats: 26
Default

:(
Splitime is offline   Reply With Quote
Old 01-17-2010, 10:55 AM   #3
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Name:  12410200671002471622.gif
Views: 2
Size:  645.9 KB
hustler is offline   Reply With Quote
Old 01-17-2010, 10:59 AM   #4
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Suspension boo boo?
Faeflora is offline   Reply With Quote
Old 01-17-2010, 11:06 AM   #5
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by faeflora View Post
Suspension boo boo?
great post, would read again.
hustler is offline   Reply With Quote
Old 01-17-2010, 11:15 AM   #6
Elite Member
iTrader: (8)

Join Date: Jun 2009
Location: Albany, NY
Posts: 1,523
Total Cats: 4
Default

Check driven accessories (alt, etc) and idler/tensioner?
webby459 is offline   Reply With Quote
Old 01-17-2010, 11:15 AM   #7
Junior Member
iTrader: (4)

Join Date: Sep 2007
Location: Hampton Roads, VA
Posts: 398
Total Cats: 0
Default

audio/video would help.
gompers is offline   Reply With Quote
Old 01-17-2010, 11:16 AM   #8
AFM Crusader
iTrader: (18)

olderguy's Avatar

Join Date: Oct 2004
Location: Wayne, NJ
Posts: 4,438
Total Cats: 84
Default

Quote:
Originally Posted by hustler View Post
I have a horrible clanking noise coming from the front of the motor that I thought was a lifter, then pulled the valve cover and everything looks good with no metal and no strange wear. When tuning the crank by hand I hear/feel a tick on the crank rpm, not the valve train.

I'm going to go ahead and buy expensive feelers and check the valves, but I fear bottom end disaster like a spun bearing. Are there any other ideas on what this could be?

So much for TXMC Houston.
Someone steal your oil? I'm going to go with bottom end disaster(no pun intended)
olderguy is online now   Reply With Quote
Old 01-17-2010, 11:23 AM   #9
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by webby459 View Post
Check driven accessories (alt, etc) and idler/tensioner?
I can feel and hear the tick (long extension on my cranium) through the base of the head.
hustler is offline   Reply With Quote
Old 01-17-2010, 11:23 AM   #10
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

I had a similar hard to find noise. One of the small bolts on the crank pulley had sheared off and others were loose.

Your problem sounds more serious since you feel it when manually rotating the crank. :(
Ben is offline   Reply With Quote
Old 01-17-2010, 11:25 AM   #11
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by gompers View Post
audio/video would help.
I tried but the audio on my shitty cam is abject failure.
hustler is offline   Reply With Quote
Old 01-17-2010, 11:25 AM   #12
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

brb, going to check a few things. Pray to Satan for me.
hustler is offline   Reply With Quote
Old 01-17-2010, 11:52 AM   #13
Junior Member
iTrader: (4)

Join Date: Sep 2007
Location: Hampton Roads, VA
Posts: 398
Total Cats: 0
Default

Quote:
Originally Posted by hustler View Post
brb, going to check a few things. Pray to Satan for me.
blood orgy!
gompers is offline   Reply With Quote
Old 01-17-2010, 11:57 AM   #14
Elite Member
iTrader: (5)

m2cupcar's Avatar

Join Date: Jan 2005
Location: Atlanta
Posts: 7,245
Total Cats: 291
Default

Pull the timing belt cover just to make sure something hasn't fallen down in there and is binding up with the crank timing gear.
m2cupcar is offline   Reply With Quote
Old 01-17-2010, 12:20 PM   #15
Junior Member
iTrader: (1)

Join Date: Apr 2009
Location: illinois
Posts: 190
Total Cats: -4
Default

I had a similar problem. I could hear it sorta make a wierd noise when manually rotating by wrench. Mine ended up being a spun bearing. It was a super terrible noise even at idle. I thought for sure it was comming from the valve cover so i took that off... Found nothing. So i pulled the motor for the second time and sure enough as soon as i pulled the oil pan and all the caps... one of my rod bearings were toast. Easy way to tell... drain your oil and look for a golden metallic shimmer. At least that was the color i saw when mine spun.
ls1motorsports is offline   Reply With Quote
Old 01-17-2010, 12:30 PM   #16
Junior Member
iTrader: (1)

Join Date: Apr 2008
Location: Bristol
Posts: 442
Total Cats: 0
Default

Quote:
Originally Posted by Ben View Post
I had a similar hard to find noise. One of the small bolts on the crank pulley had sheared off and others were loose.

Your problem sounds more serious since you feel it when manually rotating the crank. :(
+1 on the crank pully. The little dowel pin on mine snapped and the 4 little bolts ovaled out their holes. And since my trigger wheel was on the front pully my timing was rocking +- 10 degrees!

Take off your accessory belts and see if you can rock the damper back and fourth on the boss.
Duckie_uk is offline   Reply With Quote
Old 01-17-2010, 12:51 PM   #17
Elite Member
iTrader: (12)

Join Date: May 2007
Location: Austin, TX
Posts: 1,923
Total Cats: 0
Default

Bring it to the guy who put it together and get a professional opinion.
JayL is offline   Reply With Quote
Old 01-17-2010, 01:02 PM   #18
I haz no trubo
iTrader: (2)

Oscar's Avatar

Join Date: Jan 2007
Location: Bolton, UK
Posts: 3,021
Total Cats: 114
Default

rod's about to take a dump. Your motor is doomed.

/thread
Oscar is offline   Reply With Quote
Old 01-17-2010, 01:24 PM   #19
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

didn't seen any busted valve springs?
y8s is offline   Reply With Quote
Old 01-17-2010, 02:41 PM   #20
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Valve springs are fine but get this, and its confirmed by Kotomile...it looks like the intake cam is jumping on the back side of the lobe when I rotate by hand and pops. We put a little torque on the cap and could no recreate the symptom, but it was crazy looking.

I'm going to buy feelers, check record each measurement, retorque, and crank the car to see what happens tomorrow.
hustler is offline   Reply With Quote
