Old 03-07-2012, 08:35 AM   #1
Newb
Thread Starter

Join Date: Nov 2010
Posts: 16
Total Cats: 0
Default wideband air fuel gauge?

I am looking for a wideband air fuel gauge for my 97 Miata. I am looking for suggestions for a good gauge to buy and suggestions where to install it. The Miata has a retro look so an analog gauge would be nice.
Westend is offline   Reply With Quote
Old 03-07-2012, 10:44 AM   #2
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

If you can abandon the retro look, the PLX DM6 is great.

AEM wideband is also nice, but less functional than DM6.

Or you can follow the dumb masses and get a crappy LC-1.
Faeflora is offline   Reply With Quote
Old 03-07-2012, 10:51 AM   #3
Elite Member
iTrader: (2)

Mobius's Avatar

Join Date: May 2008
Location: Portland, Oregon
Posts: 3,178
Total Cats: 264
Default

Properly grounded, and sourcing power from the cigarette lighter wire instead of a noisier signal, the LC-1 is fine.

The PLX stuff is sweet, though. They can have their data report alongside OBD data, making consolidated logging easier and tuning easier. If you're running a standalone that's irrelevant, of course.
Mobius is offline   Reply With Quote
Old 03-07-2012, 12:12 PM   #4
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by Mobius View Post
Properly grounded, and sourcing power from the cigarette lighter wire instead of a noisier signal, the LC-1 is fine.

The PLX stuff is sweet, though. They can have their data report alongside OBD data, making consolidated logging easier and tuning easier. If you're running a standalone that's irrelevant, of course.

Do you want fine, or awesome?

The PLX also has a rolling graph which is great for tuning things like tip in, and you can give it a quick glance after a WOT pull to make sure your AFRs were stable.
Faeflora is offline   Reply With Quote
Old 03-07-2012, 12:31 PM   #5
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

Quote:
Originally Posted by Faeflora View Post
Or you can follow the dumb masses and get a crappy LC-1.





Seriously? The dumb masses?

While I won't disagree that the PLX is nice, suggesting an AEM UEGuessingwhatyourAFRreallyis over an LC-1 is like suggest warm water-filled balloons over a nice firm set of C cups. If you're trying to jerk it and you close your eyes, I suppose they'll get the job done. Eventually though you're going to want to take it up a notch and you'll realize how much better the real thing is.
Attached Thumbnails
wideband air fuel gauge?-sawzall_large.jpg
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 03:02 PM   #6
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

+1 for the PLX. It's a sweet setup.
dustinb is offline   Reply With Quote
Old 03-07-2012, 03:14 PM   #7
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Yes, Jeff, the dumb masses.

Do a search here for threads with LC-1

At least 1/4 are discussing some problem.
Faeflora is offline   Reply With Quote
Old 03-07-2012, 03:20 PM   #8
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

Quote:
Originally Posted by Faeflora View Post
Yes, Jeff, the dumb masses.

Do a search here for threads with LC-1

At least 1/4 are discussing some problem.
I'll also point out that if you read the threads completely, Reverant, myself, Joe P, Brain, Hustler, Sav, etcetcetcetc all point out that if you simply read the instructions and wire it up correctly, they perform flawlessly.

To use your own words:
Quote:
Do you want fine, or awesome?
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 06:19 PM   #9
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by Jeff_Ciesielski View Post
I'll also point out that if you read the threads completely, Reverant, myself, Joe P, Brain, Hustler, Sav, etcetcetcetc all point out that if you simply read the instructions and wire it up correctly, they perform flawlessly.

To use your own words:
Also many threads about calibration woes etc.
Faeflora is offline   Reply With Quote
Old 03-07-2012, 06:32 PM   #10
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Is Innovative still shipping the LC-1 with the crap-*** firmware or have they fixed that yet? That's my only gripe.
EO2K is offline   Reply With Quote
Old 03-07-2012, 06:34 PM   #11
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

Quote:
Originally Posted by EO2K View Post
Is Innovative still shipping the LC-1 with the crap-*** firmware or have they fixed that yet? That's my only gripe.
I hear they finally updated it. I have a recently shipped one waiting to be installed. I'll try to confirm when I can.
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 06:56 PM   #12
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by EO2K View Post
Is Innovative still shipping the LC-1 with the crap-*** firmware or have they fixed that yet? That's my only gripe.
Since when do widebands have firmware????

Oh yeah, since they're crappy LC-1s.
Faeflora is offline   Reply With Quote
Old 03-07-2012, 07:06 PM   #13
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

I have a brand spanking new LC-1 in the box on my desk and an AEM UEGO in the car. IF my VEI gauge ever gets here and IF someday I'm feeling less lazy, I'll weld up another bung and do a side-by-side video.

I know SportCompact or one of the magazines did an article a while back, but it really was NOT very technical. I know I've heard Reverant complain about the filtering and reaction time on the AEM, and everyone complain about firmware and grounds on the LC-1. It would be nice if someone who actually had proper equipment could do a comparo.

Where's Joe P? Doesn't he have a bunch of electronic scopes and crap for doing things like this?
EO2K is offline   Reply With Quote
Old 03-07-2012, 07:12 PM   #14
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

If someone wants to send me a UEGO, I would be ------- THRILLED to build a test rig. I have everything necessary ready to go except for the AEM paperweight.
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 07:17 PM   #15
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

My plx matches my hydra wideband. They are side by side.

Also, my AEM is very responsive. Instant response. I can see my throttle pump renrichments as I move the pedal blah balh

You niguz don't know shi you pack of LC-1 lemmings.

http://www.aemelectronics.com/wideba...fuel-gauge-25/
Faeflora is offline   Reply With Quote
Old 03-07-2012, 07:20 PM   #16
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Quote:
Originally Posted by Jeff_Ciesielski View Post
If someone wants to send me a UEGO, I would be ------- THRILLED to build a test rig. I have everything necessary ready to go except for the AEM paperweight.
Done. PM me your address and I'll pull it out and drop it in the mail this weekend. My DIYPNP is non-responsive so the sensor is acting like a plug at the moment. The sensor itself has about 3k miles on it so it should still be in tip-top shape.

Edit: You know... provided I get it back eventually
EO2K is offline   Reply With Quote
Old 03-07-2012, 07:44 PM   #17
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

Quote:
Originally Posted by EO2K View Post
Done. PM me your address and I'll pull it out and drop it in the mail this weekend. My DIYPNP is non-responsive so the sensor is acting like a plug at the moment. The sensor itself has about 3k miles on it so it should still be in tip-top shape.

Edit: You know... provided I get it back eventually

This ---- is totally happening.
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 07:46 PM   #18
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Quote:
Originally Posted by Jeff_Ciesielski View Post
This ---- is totally happening.


Fae, is your car running? Wanna volunteer your PLX?
EO2K is offline   Reply With Quote
Old 03-07-2012, 08:00 PM   #19
Elite Member
iTrader: (10)

Join Date: Oct 2008
Location: Seattle, Wa
Posts: 1,780
Total Cats: 30
Default

Honestly, I don't even need to build something to test this, 'Ford Muscle' magazine already did.

FMM Wideband shootout

Relevant info:


LC1 (xd16 is just the gauge) latency: <100ms
UEGO latency: <400ms
Jeff_Ciesielski is offline   Reply With Quote
Old 03-07-2012, 08:42 PM   #20
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,914
Default

Quote:
Originally Posted by EO2K View Post
Where's Joe P? Doesn't he have a bunch of electronic scopes and crap for doing things like this?
No need for fancy crap.


On the one AEM unit I've personally owned, I found that analog 0-5v output to differ by anywhere from 0.5 to 1.0 from the reading on the gauge itself. By then installing it in parallel with both an LC-1 and a stock narrowband sensor, I confirmed that the display on the AEM gauge was fairly close to correct, and that most of the error (which was non-linear, incidentally) was on the analog output.

So, based on my extremely small sample size, I draw the following conclusions:

If you just want a wideband gauge to look at, and can tolerate a jittery display that's hard to read in direct sunlight, then by all means get the AEM.

If you want a wideband system to connect to an ECU and use for tuning, skip the AEM.
Joe Perez is offline   Reply With Quote
