hey guys, new member here.. - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



Meet and Greet Say Hi. De-noob yourself.

Reply



LinkBack Thread Tools
Old 03-28-2011, 07:21 PM   #1
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default hey guys, new member here..

new member
got 93 na
looking to go turbo...
hopefully you guys can help me out..
thanks
charlie
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 10:02 PM   #2
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

It's easy, just do a lot of research and plan everything out. Don't go cheap unless you really know what you are doing. Profit.
dustinb is offline   Reply With Quote
Old 03-28-2011, 10:04 PM   #3
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

thanks dustinb...
i will try my best...
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 10:28 PM   #4
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

Do you have any experience with turbo setups at all? Have you looked into anything so far that's caught your interest? Also, what kind of power goals are you hoping to reach?
dustinb is offline   Reply With Quote
Old 03-28-2011, 10:34 PM   #5
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

actually none at all...
i just want a little more power..
and my goal is only to run around 7-8 psi with NO PROBLEM at all...
just a little power to go around...
would turbo be better or SC?
and which one would be a cheaper route?
for 7-8 psi with as little money as possible..
and where i dont have to change the suspension or clutch or wheels or bigger brakes..
what you think?
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 10:43 PM   #6
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

and this is what i got so far...
1.6l Turbo manifold, downpipe, and TD05-16G (sm) turbocharger

this is what the guy post when i bought it from him:

Bog standard eBay turbo kit, manifold/DP were purchased from CX Racing, who have a good reputation among the mturbo community. These parts are unused, they were bolted up to my engine for about a month while I worked on other aspects of the car. Then I found a too good to pass up deal on FM3 turbo parts and pulled this stuff off.
The turbo manifold has relief cuts between the runners, FM style, to prevent cracking. The #4 runner is tapped for an EGT probe, if you don't/won't run an EGT gauge then it can just be blocked with a bolt. The downpipe has a secondary O2 bung/cap welded in for a wideband o2 gauge. The turbo is also unused, from CX racing. Oil/water cooled. It has been "clocked" which means turning the coldside of the turbo so that the outlet faces down, making intercooler pipe routing easier. 10-12psi internal wastegate. I am including an adapter I made for the outlet that allows you to use standard silicon couplers.

what you think?
and what am i missing to make it work???
thanks
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 11:21 PM   #7
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

Well your turbo kit is pretty garbage. I'm guessing that's the ss autochrome special, which is prone to cracking and not worth the $$ at all. I'm hoping you didn't spend much on it.

As far as supercharger or turbo, you are going to need a new clutch. Also, the 93 1.6L differential is notorious for breaking on stock power, so plan on getting a 1.8 rear diff, drive shaft, and axles. In terms or what is better (SC or Turbo), that's really up to you to decide. Our car works very well with the turbo setup, and yields great power from boost of any kind. Personally I would do turbo on the miata.

SO what you need to get that turbo kit running. Well, you need engine management because it's going to boost at least 10 psi, and knowing those 16g knock off turbo's, it actually realistically has a 14psi waste gate on it. So if you don't have proper engine management, a proper tune, and the right fuel setup, you're going to blow things up quick. You also need a front mount intercooler (or an air to water). Now in the ad you have, it says the turbo is clocked down for easier installation. This is great, unless you have power steering in the way, or the typical coolant hose down there. You might have to spend some time thinking about how you want to route stuff.

So this is what you should be spending to get it to work:
Engine Management: $500
Clutch: $200 ish
Rear Differential + bits : $500ish, maybe more, maybe les
Injectors: $100
Wide Band o2: $200
Intercooler: $200
Paying someone to tune it: $200

So that's $1900 without install, and you're doing it on a horrible manifold and downpipe which will probably break. Plus you have to pay someone to install those things if you don't feel up to doing it yourself. There's also lots of other little bits that go into it, oil feed, oil return (drilling & tapping the pan), various hoses.
dustinb is offline   Reply With Quote
Old 03-28-2011, 11:42 PM   #8
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

damn...
i guess it's time to sell those stuff...
i do not have 2k to throw around...
thanksss
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 11:50 PM   #9
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

Sorry to break your dreams.
dustinb is offline   Reply With Quote
Old 03-28-2011, 11:53 PM   #10
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

it's good...
i should thank you b4 i get into wayyyy over my head...
just hope i can sell the stuff...
charlie7337 is offline   Reply With Quote
Old 03-28-2011, 11:54 PM   #11
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

also, you know how much those things are worth? 1.6l Turbo manifold, downpipe, and TD05-16G (sm) turbocharger???
how much can i sell it for?

Last edited by charlie7337; 03-29-2011 at 01:48 AM.
charlie7337 is offline   Reply With Quote
Old 03-29-2011, 12:04 AM   #12
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

I dunno man. Probably $300 at best.
dustinb is offline   Reply With Quote
Old 03-29-2011, 12:27 AM   #13
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

thanks again dusinb
charlie7337 is offline   Reply With Quote
Old 03-29-2011, 12:54 AM   #14
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Faeflora is offline   Reply With Quote
Old 03-29-2011, 12:55 AM   #15
Elite Member
iTrader: (4)

Pen2_the_penguin's Avatar

Join Date: Dec 2009
Location: Reno, NV
Posts: 3,690
Total Cats: 97
Default

Hey ******,

your fargot *** is welcomed
Dont be a douche, or ape **** will be ******* flying in your face.

Good luck with the build you God damn *** hamster, I doubt you will stay at 7-8psi for long once you feel the raping sex power like a dragon shoving his dick into your intake charge piping you will be like "Whoa ****, I want ******* moar of this ******* sheen **** man! Tiger BLOOD!"

So ******* stick around and enjoy our god damned library of awesome.

**** you.
**** this.


****.



welcome.
Pen2_the_penguin is offline   Reply With Quote
Old 03-29-2011, 01:08 AM   #16
Newb
Thread Starter

Join Date: Oct 2010
Posts: 42
Total Cats: 1
Default

damn i only been on this website for one day...
and everybody just want to **** me....
well, i'm off to selling all the turbo stuff i have..
and screw it... i'll be happy with the stock....
charlie7337 is offline   Reply With Quote
Old 03-29-2011, 01:13 AM   #17
Elite Member
iTrader: (4)

Pen2_the_penguin's Avatar

Join Date: Dec 2009
Location: Reno, NV
Posts: 3,690
Total Cats: 97
Default

Quote:
Originally Posted by charlie7337 View Post
damn i only been on this website for one day...
and everybody just want to **** me....
well, i'm off to selling all the turbo stuff i have..
and screw it... i'll be happy with the stock....
Stock is for m.net ***** bitches... stick around and you will find mind blowing dragon raping deals on this bitch, bitch.
Pen2_the_penguin is offline   Reply With Quote
Old 03-29-2011, 01:44 AM   #18
Elite Member

Join Date: Feb 2008
Location: Victoria, BC
Posts: 2,322
Total Cats: 12
Default

Stock is ****. Monster guerrilla ****.
dustinb is offline   Reply With Quote
Old 03-29-2011, 04:46 PM   #19
I'm Miserable!
iTrader: (11)

Join Date: Apr 2008
Location: Texas, 'Murica
Posts: 2,505
Total Cats: 7
Default

It is ok to turbo. I would really get a manifold though, Charlie. The turbo is probably fine. There is nothing wrong with a china turbo. You should really start with engine management and work from there though, so you aren't crying on the side of the road over your burnt up pistons.
chicksdigmiatas is offline   Reply With Quote
