Old 05-20-2013, 08:11 PM   #21
Elite Member

Join Date: Jul 2005
Location: Anacortes, WA
Posts: 2,475
Total Cats: 114
Default

Quote:
Originally Posted by emilio700 View Post
The rearmost holes on the ISC bar look like they are too far rearward to reach the control arm tabs for the end links. What's the angle of the endlinks when they're in the rear holes on the ISC?

Is that a #54104 bar from a 90-93 which is shorter than the bars for the 1.8?
The ISC bar comes with compleatly re-positioned swaybar arm brackets that are at a different water line and for/aft position and that are for/aft adjustable as to where the bar mounts to the chassis with optional positions to mount the pillow ball bushing. With a thick radiator however it would be difficult to use the softest hole without coming up with a creative way to mount the end link I think.

http://www.iscracing.net/miatasuspension.html
bbundy is offline   Reply With Quote
Old 05-21-2013, 06:18 PM   #22
Senior Member
iTrader: (1)

Join Date: Nov 2010
Posts: 951
Total Cats: -252
Default

Not trying to step on Emilio's toes but I did find another rear swaybar option. Suspension Techniques makes a 14mm 3 way adjustable rear swaybar listed for the 99-05 models-part# 51177.

I also confirmed with a box end wrench that the Eibach Spec Miata rear bar is 15mm.

Last edited by wannafbody; 05-21-2013 at 06:29 PM.
wannafbody is offline   Reply With Quote
Old 05-21-2013, 07:35 PM   #23
Supporting Vendor
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Quote:
Originally Posted by wannafbody View Post
Not trying to step on Emilio's toes but I did find another rear swaybar option. Suspension Techniques makes a 14mm 3 way adjustable rear swaybar listed for the 99-05 models-part# 51177.

I also confirmed with a box end wrench that the Eibach Spec Miata rear bar is 15mm.
We tested the ST rear bar. One hole can't be used due to the angle it creates with the end link. The bushings that come with it don't fit a Miata at all or the bar very well. ST was bought by another company so any of the ST bars are old stock, no longer in production. Green PC underneath, a different color painted over that (new owner of ST). For now, the MSM bar is a bit more useful. But yes, the 51177 is indeed 14mm.

We're working on our own sway bars but they're still many months away. Nothing revolutionary. Just a bit better adjustability, lower bushing friction and a bit less expensive than current options. Plus they'll be orange.
emilio700 is online now   Reply With Quote
Old 05-21-2013, 07:43 PM   #24
Junior Member
iTrader: (1)

Join Date: Jan 2009
Location: Bradenton, FL
Posts: 291
Total Cats: 5
Default

Quote:
Originally Posted by emilio700 View Post
We're working on our own sway bars but they're still many months away. Nothing revolutionary. Just a bit better adjustability, lower bushing friction and a bit less expensive than current options. Plus they'll be orange.
Glad my build has a lax finish date. Defiantly holding out for these! Love how Orange is noted plus. LOL
Sokool is offline   Reply With Quote
Old 05-22-2013, 01:29 AM   #25
Senior Member
iTrader: (6)

Join Date: Jun 2010
Location: San Rafael, CA
Posts: 1,124
Total Cats: 41
Default

Quote:
Originally Posted by emilio700 View Post
We're working on our own sway bars but they're still many months away. Nothing revolutionary. Just a bit better adjustability, lower bushing friction and a bit less expensive than current options. Plus they'll be orange.
Tell me you're gonna do delrin, brass or bearing centers and have slide adjustable outside. I have been waiting for that! Way to much stiction with the current design.
k24madness is offline   Reply With Quote
Old 05-22-2013, 12:52 PM   #26
Elite Member

Join Date: Jul 2005
Location: Anacortes, WA
Posts: 2,475
Total Cats: 114
Default

Quote:
Originally Posted by k24madness View Post
Tell me you're gonna do delrin, brass or bearing centers and have slide adjustable outside. I have been waiting for that! Way to much stiction with the current design.
Yea urethane bushing just plain suck for anything that is suppose to pivot freely. They suck even more with the big diameters involved with hollow bars.
bbundy is offline   Reply With Quote
Old 05-22-2013, 01:52 PM   #27
Supporting Vendor
iTrader: (3)

emilio700's Avatar

Join Date: May 2005
Posts: 5,308
Total Cats: 1,326
Default

Acetal (not Dupont Delrin brand) will be an option on our bars due at the end of the year.

Urethane works fine if it's installed properly. Yes it will have more friction than an actual metal bearing but they work, are much lighter and less expensive. For 90% of the owners out there, urethane is still the best option. Acetal bushings generate a huge increase in NVH that most users will not tolerate for daily driving. So no, they don't "suck" for the average guy Bob. Your car is a 99.9th percentile build so what meets your minimum requirements isn't always relevant to the average HPDE guy.

The OEM Racing Beat bushings are made by Prothane in Costa Mesa, CA. They are an imperfect design. I have hesitated to help RB refine their design and propagate those specs to Prothane because.. we will just fix those minor issues with our SuperMiata bars and offer an acetal option.

For those with RB bushings, it's simple. Put a washer under the front brackets to reduce preload and grease the heck out of them. Done so, and re-greased periodically, the breakaway and turning torque required is minimal. Good enough to win a pile of national championships with
emilio700 is online now   Reply With Quote
Old 05-22-2013, 04:01 PM   #28
Elite AbsurdFlow Member

Laur3ns's Avatar

Join Date: Mar 2008
Location: Enschede, NL
Posts: 2,058
Total Cats: 11
Default

Quote:
Originally Posted by emilio700 View Post
For those with RB bushings, it's simple. Put a washer under the front brackets to reduce preload and grease the heck out of them. Done so, and re-greased periodically, the breakaway and turning torque required is minimal. Good enough to win a pile of national championships with
This. Did this years ago, couldn't believe they designed it like this. Suspension binding sucks, unless you want random and hidden spring rates.
Laur3ns is offline   Reply With Quote
Old 05-22-2013, 05:54 PM   #29
Junior Member
iTrader: (3)

Join Date: Apr 2010
Location: South Bay, CA
Posts: 354
Total Cats: -2
Default

Quote:
Originally Posted by emilio700 View Post
We're working on our own sway bars but they're still many months away. Nothing revolutionary. Just a bit better adjustability, lower bushing friction and a bit less expensive than current options. Plus they'll be orange.
Saving my pennies now...car was lacking a little orange underneath anyways.
comradefks is offline   Reply With Quote
Old 05-22-2013, 09:32 PM   #30
Junior Member

Join Date: Jun 2011
Location: Houston
Posts: 409
Total Cats: 17
Default

Acetal bushings AND 949 spec sway bars!?!

Attached Thumbnails
Bar size for big spring rates?-3051083-2091416381-shut-.jpg
Handy Man is offline   Reply With Quote
Old 06-04-2013, 04:50 PM   #31
Junior Member
iTrader: (3)

Join Date: Oct 2011
Location: Naperville
Posts: 369
Total Cats: 3
Default

Quote:
Originally Posted by Savington View Post
RB .125" hollow FSB, MSM RSB.
I don't know Andrew, an 1/8" hollow bar seems kind of small
tomiboy is offline   Reply With Quote
