Default Custom Axles: Taylor Racing Eng.

I've been talking to Mr. Young at Taylor and I'm having some Chromoly 4340 axles made up w/ upgraded CVs and didn't know if other people might be interested.

For a "Group Buy" we would need 10 sets made.

I have a 3.9 torsen with the smaller 2 piece bolt flange.

Normal pricing is around the $485-495 each and with the lot of 10 sets we would be looking at about $425 each.

Let me know what you guys think!

Last edited by Raucky; 12-05-2013 at 08:59 AM.
Raucky is offline   Reply With Quote
Old 12-04-2013, 10:44 AM   #2
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Taylor race makes good stuff. Bit to rich for me. Would be nice to have their tulips at the inner CV for people who run below 4.5" pinch weld height in the back and dont want to break axles on the launch. Or just slightly longer axles.

Are you saying these only work with the 94-95 stub axles in the diff?
Leafy is offline   Reply With Quote
Old 12-04-2013, 12:17 PM   #3
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,367
Total Cats: 1,330
Default

$425 each or $425 a set?
Savington is offline   Reply With Quote
Old 12-04-2013, 12:19 PM   #4
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Quote:
Originally Posted by Savington View Post
$425 each or $425 a set?
$425 for a set sounds too cheap for Taylor race.
Leafy is offline   Reply With Quote
Old 12-04-2013, 08:12 PM   #5
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

Yup these will fit only the 1.8 diff, with the smaller stub bolt pattern since I wanted the smallest dia and weight possible.

Price is per each axle, but should be the last pair you need to buy. On the bright side these are cheaper than 300m axles!

I'm planning on running these on my 400whp+ play toy.

Last edited by Raucky; 12-04-2013 at 09:19 PM.
Raucky is offline   Reply With Quote
Old 12-04-2013, 08:14 PM   #6
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,897
Total Cats: 109
Default

Quote:
Originally Posted by Raucky View Post
Yup these will fit only the smaller 1.6 diff, since I wanted the smallest dia and weight possible.

Price is per each axle, but should be the last pair you need to buy. On the bright side these are cheaper than 300m axles!

I'm planning on running these on my 400whp+ play toy.
Is this a joke?
miata2fast is online now   Reply With Quote
Old 12-04-2013, 08:15 PM   #7
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Ahhhh..... Yeah, lets put $900 worth of 400+hp axles into a diff known to break at ~90hp.

Attached Thumbnails
Custom Axles: Taylor Racing Eng.-guiness-brilliant-.jpg
Leafy is offline   Reply With Quote
Old 12-04-2013, 08:16 PM   #8
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

Torsen break at ~90hp?

Last edited by Raucky; 12-05-2013 at 08:58 AM.
Raucky is offline   Reply With Quote
Old 12-04-2013, 08:18 PM   #9
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Quote:
Originally Posted by Raucky View Post
Torsion break at ~90hp?
Torsens dont, but 1.6 opens and viscous do, no torsen available in the useless 6" ring gear.
Leafy is offline   Reply With Quote
Old 12-04-2013, 08:22 PM   #10
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

I don't know what year my diff came out of but it's a torsen with with the smaller bolt pattern and smaller dia axle "rod". When come paired to my 3.6 torsion with 1 piece axles.

Last edited by Raucky; 12-05-2013 at 08:58 AM.
Raucky is offline   Reply With Quote
Old 12-04-2013, 08:27 PM   #11
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Stop and figure out what **** you have. There are 5 different axles setups (besides abs stuff) that have been in miatas. The 1.6 had different stub shafts (and maybe different axles) between open and viscious diffs. The 94-95 are the start of the diff that dont break as easily and those are all the same with stub shafts. 96-05 are basically all the same, exactly the same as the 94-95 except they're 1 piece axles. The MSM had 1 piece axles as well and they're larger and should be strong enough for a 400hp, only maybe breaking occasionally. Where as a 300-400hp car with 275 slicks would be breaking 1 or 2 standard axles per auto-x season, and only on the pro-solo drag launches. I wouldnt even worry about it in a track car.
Leafy is offline   Reply With Quote
Old 12-04-2013, 08:30 PM   #12
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,897
Total Cats: 109
Default

There is a difference between the Mazdaspeed and regular 1.8 diffs. The splines are beefier at the diff end of the axle on the Mazdaspeed cars. That is probably what you mean.

The 1.6 diff is only good for adding to one's scrap collection. The ring and pinion gears are very weak.
miata2fast is online now   Reply With Quote
Old 12-04-2013, 08:42 PM   #13
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

From your what you're saying it's a 94-95 diff then....Did they have a torsen for those years? I'm newer to Miata's and purchased the car with 2 diffs and axle setups.

3.6 torsion with one piece axles and a 3.9 with 2 piece axles.

It's def not MSM and not 1 piece, so that doesn't leave much else to choose from based on what you listed above.

I'm doing this upgrade to my SSM miata, so it will see some abuse.

Last edited by Raucky; 12-05-2013 at 08:58 AM.
Raucky is offline   Reply With Quote
Old 12-04-2013, 08:52 PM   #14
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,897
Total Cats: 109
Default

They had torsens in those years. 2 piece axles came in 1.8 diffs in 94 and part way through 95. After that they all came with 1 piece axles.

1 piece and 2 piece 1.8 axles are interchangeable in all 1.8 diffs other than the Mazdaspeed's diff. They have their own specific axle.

I hope that clears that up.

Last edited by miata2fast; 12-05-2013 at 07:30 AM.
miata2fast is online now   Reply With Quote
Old 12-04-2013, 09:17 PM   #15
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

Yeah that does, thx.
Raucky is offline   Reply With Quote
Old 12-04-2013, 10:29 PM   #16
Senior Member
iTrader: (14)

Join Date: Jan 2007
Location: Murfreesboro,TN
Posts: 1,279
Total Cats: 53
Default

Most turbo applications are going to want 1 piece axles for the clearance for 3" exhaust.
Midtenn is online now   Reply With Quote
Old 12-04-2013, 10:47 PM   #17
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

My exhaust dumps before the dif, but your point does make sense.
Raucky is offline   Reply With Quote
Old 12-04-2013, 11:52 PM   #18
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: SE NM
Posts: 1,460
Total Cats: 48
Default

OMG IT IS "TORSEN" NOT A "TORSION" DIFFERENTIAL
Chilicharger665 is offline   Reply With Quote
Old 12-05-2013, 07:55 AM   #19
Senior Member
iTrader: (1)

Join Date: Dec 2010
Location: Farmington Hills, MI
Posts: 878
Total Cats: 93
Default

Taylor Race is a great company, would highly recommend!
acedeuce802 is offline   Reply With Quote
Old 12-05-2013, 08:57 AM   #20
Junior Member
Thread Starter
iTrader: (1)

Join Date: Sep 2013
Posts: 96
Total Cats: 1
Default

Yup you're both right
Raucky is offline   Reply With Quote
