Default FM Springs / Tokico Illumina assembly trouble

Really excited to get this setup in my car, but I'm having trouble assembling them. I rented a strut compressor from Autozone and set to work. The "dead" coils up top make do not work with the compressor, so I only have the lower 3 coils to work with to get the spring compressed enough. I can't go to the bottom because it won't fit on the shock. I fought with it for a while and finally got enough of the shaft to work with, so I pressed the FM top hat down and was able to get it both nuts threaded. Success? No! As I loosened the compressors, the spring started to bend, allowed by the bearing in the top hat. The top of the spring, the end of the coil, doesn't seem to compress enough to properly seat in the top hat, which barely fits the spring and only has a small lip to hold the spring in. I read the instructions, took the logical assembly path. Any tips? Tricks? Did I do something wrong? Didn't take pictures of the "assembled" shock, but it didn't look right at all, so I pressed the spring back down and took the thing apart, I didn't want to leave it there overnight. Thanks y'all.
Philly Miata is offline   Reply With Quote
Old 09-29-2016, 08:59 PM   #2
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,759
Total Cats: 174
Default

Quote:
Originally Posted by Philly Miata View Post
Thanks y'all.
FM Springs / Tokico Illumina assembly trouble-image.jpg
thirdgen is offline   Reply With Quote
Old 09-29-2016, 09:02 PM   #3
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,759
Total Cats: 174
Default

Seriousness...do you have pics with it assembled with compressors off?
thirdgen is offline   Reply With Quote
Old 09-29-2016, 09:18 PM   #4
Junior Member
Thread Starter

Philly Miata's Avatar

Join Date: Jul 2016
Location: Philadelphia
Posts: 295
Total Cats: 14
Default

I'll get some tomorrow.
Philly Miata is offline   Reply With Quote
Old 09-30-2016, 10:15 AM   #5
Junior Member

Join Date: Oct 2011
Location: Montreal, QC
Posts: 191
Total Cats: 28
Default

It's been a few years, but as I recall, on my NB the FM springs were short enough that I was able to install the top mounts into the car beforehand, and then place the springs over the shocks, install into the car, and then use a jack under the control arm to compress everything together before installing and tightening the shaft bolt. I don't think I used spring compressors at all to install the suspension.

It should be noted that this was on an NB with factory mounts, but I recall the install being easier than removing the factory suspension.

Make sure that all the bits and pieces are in the right order and oriented properly. It's pretty easy to get it wrong if you're not looking at a diagram of how it's supposed to go.
TalkingPie is offline   Reply With Quote
Old 09-30-2016, 11:20 AM   #6
Junior Member
Thread Starter

Philly Miata's Avatar

Join Date: Jul 2016
Location: Philadelphia
Posts: 295
Total Cats: 14
Default

I was thinking about trying that, it may work as long as I have the spring seated properly under the top mount. I double and triple checked the make sure I have everything right. Don't need the spacer for the FM mounts, press sleeves into the bearing from top and bottom, big nut little nut then plastic doohicky.
Philly Miata is offline   Reply With Quote
Old 10-04-2016, 03:47 PM   #7
Junior Member

Join Date: Jul 2016
Posts: 191
Total Cats: 3
Default

You can always give FM a call so they can walk you through. They are very helpful and can make sure that you are putting everything together correctly.
2slow is offline   Reply With Quote
Old 10-04-2016, 04:00 PM   #8
Elite Member
iTrader: (6)

Join Date: Feb 2013
Location: Staunton, Va
Posts: 2,308
Total Cats: 190
Default

I have never used a spring compressor. I just put the spring on the shock, put it up into place, install the lower shock bolt, slowly lower the jack- guiding the shock shaft into the top hat. Install nut. Done. Takes me like an hour to do all 4.
ryansmoneypit is offline   Reply With Quote
Old 10-04-2016, 09:36 PM   #9
Junior Member
Thread Starter

Philly Miata's Avatar

Join Date: Jul 2016
Location: Philadelphia
Posts: 295
Total Cats: 14
Default

I am going to post the solution I found. See, there was something wrong with my eyes and the thing between my ears. The problem was that I was trying to put the rear top mounts on the front shocks/springs. My dumb *** was so focused on getting them on that it took two days of scratching my head to realize I was bass ackwards. So once I realized what I was doing, it took an hour to put all four together. Put them in the next day.
