The thickness of the flange needs to be controlled within like 1 thread length of that stud too.
Leafy is offline   Reply With Quote
Old 04-21-2016, 04:02 PM   #22
Junior Member

Join Date: May 2011
Location: Signal Hill, CA
Posts: 246
Total Cats: 11
Default

Quote:
Originally Posted by w002 View Post
there's only one face which is needed to be controled - ∅66,10. it has 0.1mm for a press fit. other are basically free dimensions. And Oscar is right - there is 2mm wide chamfer, not two chamfers.
i have not measured it - just made a drawing out of a cad model which was uploaded in here earlier.
i' ve done two bushings for myself out of hdpe according to this drawing - works well, fitting was kinda tight into the diff bushing holes.
Yeah, after viewing the drawing on my computer, I understood how you dimensioned it I admit I was wrong and should have paid closer attention to your dimensioning but for future reference, the way you did it is confusing.

Attached Thumbnails
Miata differential bushing dimensions-mnm2gdx.jpg
.one lane is offline   Reply With Quote
Old 04-22-2016, 02:17 AM   #23
Newb

Join Date: Jun 2014
Location: Vilnius
Posts: 5
Total Cats: 0
Default

Quote:
Originally Posted by .one lane View Post
Yeah, after viewing the drawing on my computer, I understood how you dimensioned it I admit I was wrong and should have paid closer attention to your dimensioning but for future reference, the way you did it is confusing.

well, what could i say - i'm from europe - things are a little bit different in here
w002 is offline   Reply With Quote
