Default Fully built 95R with a itty bitty turbo

What's up guys, I'm starting this late in the build process but better late than never right?
Im on my fourth miata and have finally found the perfect canvas for a healthy build. I've been gathering parts since late 2014 which I now regret with EFRs being the newish hotness. Whatever, on to the good stuff
Here's where we're at now
1995 R package





Briggs Motorsport manifold that I wish I bought instead of the Begi cast 😩












stance coilovers
6 speed (miata roadaster shifter kit not yet installed)
knock off TE37 wheels (I know) wrapped in 205
dirrezas
begi S3 kit with garret 2560
MSPNP2
DW550s
aeromotive 340lph
Gates racing timing belt
Cometic head gasket
ACL race bearings STD size(thrust,main,rod)
ARP head studs
CP Forged Pistons 83.50mm
Pistons are 9.0:1 Compression
Manley Forged H beam Rods with ARP 2000 rod bolts
BE oil pump
"custom" titanium valve train that my engine builder
sourced to save a bit instead of getting the supertech
balanced crank etc. etc.
exhaust is will be a full 3" into a (probably magnaflow) muffler with an electric cutout dumped at the rear axles.
Mishimoto Rad and fan shroud
also not installed yet: ATI damper
PBGuts is offline   Reply With Quote
Old 12-19-2017, 10:56 AM   #2
Newb

Join Date: Mar 2017
Location: GER
Posts: 41
Total Cats: 1
Default

clean car!

amazing how good the overall condition of the car body and the sway bars etc is after all these years...
makes my german '96 look like it has been laying in a river for a year

Keep up the good work!
der_vierte is offline   Reply With Quote
Old 12-19-2017, 01:01 PM   #3
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Thanks a lot man! I've had this car for a couple years now and am very happy with the guy I purchased it from. I've seen prices on <100k mile R package cars and they are asking about twice as much as I payed for this!
PBGuts is offline   Reply With Quote
Old 12-19-2017, 01:14 PM   #4
Supporting Vendor
iTrader: (6)

Join Date: Mar 2005
Location: Broken Arrow,Ok
Posts: 1,106
Total Cats: 52
Default

Excellent start! This is my kind of build thread.
TheBandit is offline   Reply With Quote
Old 12-19-2017, 01:39 PM   #5
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 74,711
Total Cats: 2,059
Default

whats the tubular manifold and borg turbo???


the 2560 isn't exactly itty bitty -- it's a perfectly matched sized turbo for even a built 1.8L 0-- enjoy 300rwhp.
Braineack is offline   Reply With Quote
Old 12-19-2017, 01:42 PM   #6
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 34,781
Total Cats: 3,048
Default

Great start!
18psi is offline   Reply With Quote
Old 12-19-2017, 02:02 PM   #7
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Quote:
Originally Posted by Braineack View Post
whats the tubular manifold and borg turbo???


the 2560 isn't exactly itty bitty -- it's a perfectly matched sized turbo for even a built 1.8L 0-- enjoy 300rwhp.
that was just a teaser from my builder (Briggs motorsports)
thats where most of my frustration with buying a kit so long ago lies. This build went from wanting a healthy stock engine 2560 good for 200-220 wheel...to a six speed, then fully built engine, then kicking myself for not getting a tubular manifold and BW turbo. Thanks though! I'm very excited!
PBGuts is offline   Reply With Quote
Old 12-19-2017, 02:03 PM   #8
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

i appreciate it guys!
PBGuts is offline   Reply With Quote
Old 12-19-2017, 02:06 PM   #9
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Briggs Motorsports built roll bar finished and should be going in today!
PBGuts is offline   Reply With Quote
Old 12-19-2017, 02:08 PM   #10
Junior Member

sshamrockk's Avatar

Join Date: Oct 2016
Location: Western Mass.
Posts: 236
Total Cats: 13
Default

It's never too late to upgrade, sure you'll lose a few bucks, but you'll lose even more down the line when it's got xx,xxx miles on it. 2560 will sell quick on this forum.
sshamrockk is offline   Reply With Quote
Old 12-19-2017, 02:14 PM   #11
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Quote:
Originally Posted by sshamrockk View Post
It's never too late to upgrade, sure you'll lose a few bucks, but you'll lose even more down the line when it's got xx,xxx miles on it. 2560 will sell quick on this forum.
that is true, but I will be heading to a foreign land for a few months in march so I figured a better option would be to wait till I have more 💰💰💰 when I get home around late July so the new snail isn't just sitting around. Plus, between completion and March, I can't imagine the 2560 and cast mani will have much more than 2500 miles so it should still sell fine. I appreciate the input though!
PBGuts is offline   Reply With Quote
Old 12-19-2017, 05:00 PM   #12
Junior Member

sshamrockk's Avatar

Join Date: Oct 2016
Location: Western Mass.
Posts: 236
Total Cats: 13
Default

Quote:
Originally Posted by PBGuts View Post
that is true, but I will be heading to a foreign land for a few months in march so I figured a better option would be to wait till I have more 💰💰💰 when I get home around late July so the new snail isn't just sitting around. Plus, between completion and March, I can't imagine the 2560 and cast mani will have much more than 2500 miles so it should still sell fine. I appreciate the input though!
Thats fair, then I say run it obv. I recently just sold my 2560r in a matter of minutes with only 3k on it.. Found 3 bananas inside my motor, so now the fun starts. 2560 is plenty though, for most people, you should be happy with it for awhile. If you have e85 available in your area you will be able to make a bit more power than us 93 plebs.
sshamrockk is offline   Reply With Quote
Old 12-20-2017, 12:23 AM   #13
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Quote:
Originally Posted by sshamrockk View Post
Thats fair, then I say run it obv. I recently just sold my 2560r in a matter of minutes with only 3k on it.. Found 3 bananas inside my motor, so now the fun starts. 2560 is plenty though, for most people, you should be happy with it for awhile. If you have e85 available in your area you will be able to make a bit more power than us 93 plebs.
we actually have a few E85 stations in the savannah GA area BUT another thing that I didn't consider when buying all the bits and pieces in 2014-current....I'd need beefier injectors for that...and I'd also prefer to have built it higher compression and just be full time E85....that being said I know I will enjoy it and enjoy having room for improvement.
PBGuts is offline   Reply With Quote
Old 12-20-2017, 08:24 AM   #14
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 74,711
Total Cats: 2,059
Default

keep the 2560:

Braineack is offline   Reply With Quote
Old 12-20-2017, 10:46 AM   #15
Elite Member
iTrader: (2)

Join Date: Aug 2016
Location: Woostuh, MA
Posts: 3,568
Total Cats: 100
Default

Quote:
Originally Posted by Braineack View Post
keep the 2560:

Woah, what all was done to that motor/exhaust?
ridethecliche is offline   Reply With Quote
Old 12-20-2017, 11:03 AM   #16
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 74,711
Total Cats: 2,059
Default



stock 99 motor running MS1 with shitty injectors.
Braineack is offline   Reply With Quote
Old 12-20-2017, 11:15 AM   #17
Elite Member
iTrader: (2)

Join Date: Aug 2016
Location: Woostuh, MA
Posts: 3,568
Total Cats: 100
Default

Quote:
Originally Posted by Braineack View Post


stock 99 motor running MS1 with shitty injectors.
Haha yeah, but a baller tubular manifold, intake manifold, and TurboTim exhaust!

I thought that chart looked familiar! I wonder how long that motor lasted haha.

I guess your point is that you can take the 2560 up quite a ways with some work and not give up the response.
ridethecliche is offline   Reply With Quote
Old 12-20-2017, 12:40 PM   #18
Junior Member
Thread Starter

Join Date: Jan 2012
Location: Savannah Georgia
Posts: 61
Total Cats: 4
Default

Quote:
Originally Posted by Braineack View Post
keep the 2560:

is that on e85?
PBGuts is offline   Reply With Quote
Old 12-20-2017, 12:58 PM   #19
Elite Member
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,873
Total Cats: 161
Default

I think the BEGI cast manifold is about the last remaining piece from my original turbo kit from ~2007. I've considered upgrading several times, but I can't give up how reliable the old boat anchor has been. I'm sure it gives up some spool against a nice tubular manifold, but I'll definitely flow enough to start breaking stuff.
pdexta is offline   Reply With Quote
Old 12-20-2017, 01:00 PM   #20
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,799
Total Cats: 1,665
Default

Paul's car was on gas IIRC. It is also a freak of nature, very few people have even come close to those numbers on a 2560R.
