Default Can anyone help me ID this AiResearch turbo?

Looks like a T3. Marks on the cold side look like 84, probably A/R. Also has "M11" cast into it. No ID plate. No marks to speak of on the hot side other than a "12" cast in. I bought it a few years ago because reasons. I just remembered I had it and thought it might be good for my Miata project. Nudes of it:









Any idea on specs or maybe even a compressor map?
Mikel is offline   Reply With Quote
Old 04-17-2015, 07:27 PM   #2
Junior Member
Thread Starter

Join Date: Sep 2007
Posts: 56
Total Cats: 0
Default

Anyone?

Attached Thumbnails
Can anyone help me ID this AiResearch turbo?-wzbpdgr.gif
Mikel is offline   Reply With Quote
Old 04-17-2015, 10:42 PM   #3
Elite Member
iTrader: (1)

Join Date: May 2009
Location: Jacksonville, FL
Posts: 4,682
Total Cats: 216
Default

This may be the turbo from a LeBaron GTC Turbo.

Its basically a Garrett T3. Take some measurements to confirm.

Compressor housing A/R .42
Exhaust housing A/R .48
Compressor inducer 42 mm
Compressor exducer 60 mm
Exhaust turbine diameter 48 mm
Full_Tilt_Boogie is offline   Reply With Quote
Old 04-18-2015, 12:20 PM   #4
Junior Member
Thread Starter

Join Date: Sep 2007
Posts: 56
Total Cats: 0
Default

Thanks, I'll get some measurements.
Mikel is offline   Reply With Quote
Old 04-18-2015, 01:48 PM   #5
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

yes just measure it.
Braineack is offline   Reply With Quote
