Default Carbon Buildup on turbo, Car running poorly.

While I was headed home earlier I got into boost in 2nd gear, and was quickly greeted with a huge stumble; the car fell on its face. I lost most of my power, and had to nurse the car home (it would enter just enough boost for the BOV to be audible). It would barely idle at stop lights, and it frequently died. It was running very rich.

Upon further inspection, my downpipe has a 3"-4" crack at the elbow where it meets the turbo. It is also tremendously caked with carbon, along with the turbine exhaust housing. I had taken the downpipe off expecting to find oil, since ive had some in the charge pipes, and figured the turbo seals had just bit the dust.

so heres a rundown of the symptoms:
  • No power
  • missing boost
  • stumbles/dies while idling
  • running very rich
  • 3"-4" crack in downpipe elbow
  • massive carbon caked on downpipe/exhaust turbine

Could just the crack in the downpipe be causing these symptoms? Is it the stock O2 sensor reading a lean condition and trying to compensate? Or should I look elsewhere?

Here is a cat picture for your trouble:

Attached Thumbnails
Carbon Buildup on turbo, Car running poorly.-cat-ready-ravioli.jpg
mellowout is offline   Reply With Quote
Old 02-06-2013, 11:19 AM   #2
Junior Member
iTrader: (5)

Join Date: Mar 2012
Location: Gilbert, Az
Posts: 337
Total Cats: 26
Default

Quote:
Originally Posted by mellowout View Post
  • No power
  • missing boost
  • stumbles/dies while idling
  • running very rich
  • 3"-4" crack in downpipe elbow
  • massive carbon caked on downpipe/exhaust turbine
A crack would introduce fresh air into the exhaust stream, which makes the o2 sensor think it's running lean, therefore falsely enrichening the AFR. This would cause excess carbon, which you're seeing, and would be most noticeable at idle where the mix of fresh air would probably be greatest (least backpressure).

Fix the crack, and see what happens from there.
SJP0tato is offline   Reply With Quote
Old 02-06-2013, 11:37 AM   #3
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,009
Total Cats: 583
Default

What ECU? Other info? What SJ said might be right, or it might not. Depends.

With an MS, the amount of closed loop adjustment should be limited (I only allow 5% on mine) and would NOT cause these symptoms if the limits are tight.
hornetball is offline   Reply With Quote
Old 02-06-2013, 03:40 PM   #4
Junior Member
Thread Starter
iTrader: (2)

Join Date: May 2011
Location: AL
Posts: 233
Total Cats: 10
Default

Resolved the problem today. I had the downpipe welded back up, and upon entering the vehicle to try to start it, I noticed my boost gauge line was knocked off the tee for my megasquirt's map signal.

Im assuming the downpipe has always been leaking, but the rich condition exacerbated the smoking issue. I hooked the vacuum line back up, zip tied it down, and she runs like a champ.

Thanks for the help gentlemen.
mellowout is offline   Reply With Quote
