NA 1.6: glowing manifold and turbo - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



DIY Turbo Discussion greddy on a 1.8? homebrew kit?

Reply



LinkBack Thread Tools
Old 09-28-2009, 09:34 PM   #1
I'm Miserable!
Thread Starter
iTrader: (33)

Join Date: Jan 2009
Location: San Jose, CA
Posts: 1,066
Total Cats: -3
Default NA 1.6: glowing manifold and turbo

Ever since getting my new motor in and driving around my mani and turbo glow lava red BUT ONLY after freeway driving.
Its a 1.6 with mspnp

From what i've read after searching for the syptoms it doesnt make sense

My timing is spot on, i checked it 3 times to make sure by pulling the #1 spark plug out and using a ratchet extension piece and watching when it becomes TDC so the timing marks line up and its spot on like i said.

All sensors are plugged in and reading.

My freeway cruising AFR's are good

And im pretty sure my ignition timing is set properly ( with Marc D's help)
Its weird though when we set the timing the timing mark went all the way to the left so its at like 18* 20*??wtf?

Right now i have the wastegate disconnected for the engine break in. The break in is complete now and i want to get this fixed before any serious tuning happens.
And if it matters the MS was street tuned with the wastegate disconnected so i could drive around to break the motor in.

Help please im completely stumped
railz is offline   Reply With Quote
Old 09-28-2009, 09:39 PM   #2
Elite Member
iTrader: (15)

Join Date: Sep 2007
Location: Incline Village, NV
Posts: 2,073
Total Cats: 5
Default

My understanding is glowing red is from high EGTs. What kind of temps are you getting? I know you said your AFRs are good, but still. I have only seen my mani glow red once. I don't check on a regular basis either tho.

On a side note what kind of "engine break in" are you doing?
thesnowboarder is offline   Reply With Quote
Old 09-28-2009, 09:39 PM   #3
Elite Member
iTrader: (12)

Join Date: Aug 2006
Location: Central-ish VA
Posts: 4,449
Total Cats: 16
Default

Make sure your timing is not still locked in Megatune from when you set your base timing. Not that I've ever done that before.
neogenesis2004 is offline   Reply With Quote
Old 09-28-2009, 09:43 PM   #4
Elite Member
iTrader: (3)

Mach929's Avatar

Join Date: Oct 2004
Location: lansdale PA
Posts: 2,500
Total Cats: 0
Default

well what are your timing values in the cells you cruise on the highway with?
Mach929 is offline   Reply With Quote
Old 09-28-2009, 10:09 PM   #5
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Glowing manifolds are awesome. My car does it because it makes mad powah.


Yours does it because you are not running enough timing advance.
Ben is offline   Reply With Quote
Old 09-28-2009, 10:15 PM   #6
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,915
Default

Name:  danger20to20manifold.jpg
Views: 5
Size:  19.7 KB



Heh.

Definitely suggests insufficient timing advance. It posts a recently saved MSQ?
Joe Perez is offline   Reply With Quote
Old 09-28-2009, 10:24 PM   #7
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,857
Total Cats: 1,788
Default

Quote:
Originally Posted by neogenesis2004 View Post
Make sure your timing is not still locked in Megatune from when you set your base timing. Not that I've ever done that before.

this.
Braineack is offline   Reply With Quote
Old 09-28-2009, 10:27 PM   #8
Elite Member
iTrader: (6)

Join Date: Sep 2007
Location: CA
Posts: 1,990
Total Cats: 9
Default

How about a plugged cat?
kenzo42 is offline   Reply With Quote
Old 09-28-2009, 10:32 PM   #9
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,857
Total Cats: 1,788
Default

hot cat?

Braineack is offline   Reply With Quote
Old 09-28-2009, 10:37 PM   #10
I'm Miserable!
Thread Starter
iTrader: (33)

Join Date: Jan 2009
Location: San Jose, CA
Posts: 1,066
Total Cats: -3
Default

no cat lol

SOOOOOOO after reading what you guys suggested and talking to Marc my fixed timing was set at 10...?.....?. set it at -10 and it runs even better. will take it for a quick freeway run tonight to make sure that was it
railz is offline   Reply With Quote
Old 09-28-2009, 10:40 PM   #11
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,362
Total Cats: 1,323
Default

Yes, timing that varies depending on RPM and manifold pressure will generally work pretty well for you.
Savington is offline   Reply With Quote
Old 09-28-2009, 10:42 PM   #12
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,857
Total Cats: 1,788
Default

Quote:
Originally Posted by railz View Post
no cat lol

SOOOOOOO after reading what you guys suggested and talking to Marc my fixed timing was set at 10...?.....?. set it at -10 and it runs even better. will take it for a quick freeway run tonight to make sure that was it

that.

/thread
Braineack is offline   Reply With Quote
Old 09-28-2009, 10:43 PM   #13
Elite Member
iTrader: (12)

Join Date: Aug 2006
Location: Central-ish VA
Posts: 4,449
Total Cats: 16
Default

Omg what do i win!!!!!!!!!!!!!!!!!
neogenesis2004 is offline   Reply With Quote
Old 09-28-2009, 11:02 PM   #14
Elite Member
iTrader: (3)

Mach929's Avatar

Join Date: Oct 2004
Location: lansdale PA
Posts: 2,500
Total Cats: 0
Default

wow good thing you asked
10=10
-10=use map

10 degrees at cruise= way retarded=fail
Mach929 is offline   Reply With Quote
Old 09-29-2009, 01:12 AM   #15
:(
iTrader: (7)

Join Date: Jul 2006
Location: nowhere
Posts: 8,281
Total Cats: 2
Default

rofl omg wow man that if ****** silly im glad you figured it out though gj
magnamx-5 is offline   Reply With Quote
Old 09-29-2009, 01:17 AM   #16
Elite Member
iTrader: (12)

Join Date: Aug 2006
Location: Central-ish VA
Posts: 4,449
Total Cats: 16
Default

Glad I figured it out...
neogenesis2004 is offline   Reply With Quote
Old 09-29-2009, 01:51 AM   #17
Elite Member
iTrader: (28)

Join Date: May 2008
Location: St. Augustine FL
Posts: 2,310
Total Cats: 2
Default

^+1
On a serious note isn't that like one of the first things the mega manual says to do?
Or maybe it's brains sticky...... I don't remember.
Either way I'm glad you figured it out but damn read the basics.....
p51hellfire is offline   Reply With Quote
Old 09-29-2009, 02:21 AM   #18
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by thesnowboarder View Post
My understanding is glowing red is from high EGTs.
Glowing means you're driving under load, or making decent mpg; even your stock exhaust would glow if you ran it hard and popped the hood at night. My cast manifold glowed on the freeway at night, and so does my SS manifold...and no one here is running more advance than me. This is why we have water in the head...or the aluminium would sloop. Cast iron glows at 800*, SS glows even lower. The more I cried and worried about this initially, the more I realized that it was normal.

Quote:
Originally Posted by p51hellfire View Post
^+1
On a serious note isn't that like one of the first things the mega manual says to do?
Or maybe it's brains sticky...... I don't remember.
Either way I'm glad you figured it out but damn read the basics.....
I now refuse to help newbs who don't read stickies on this ****.
hustler is offline   Reply With Quote
Old 09-29-2009, 02:54 AM   #19
Junior Member

Join Date: Mar 2008
Location: Seattle
Posts: 243
Total Cats: 3
Default

oh noes gaiz, we lost hustler, the number 1 n00b hand-holder -- what ever will we do?!
;~~~~~~~~~~~~~;
DontPassTheFence is offline   Reply With Quote
Old 09-29-2009, 03:08 AM   #20
Elite Member
iTrader: (28)

Join Date: May 2008
Location: St. Augustine FL
Posts: 2,310
Total Cats: 2
Default

Quote:
Originally Posted by DontPassTheFence View Post
oh noes gaiz, we lost hustler, the number 1 n00b hand-holder -- what ever will we do?!
;~~~~~~~~~~~~~;
shhh!!! he's always watching
p51hellfire is offline   Reply With Quote
