Why does my car make no boost with the wastegate safety-wired closed? - Page 3 - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



DIY Turbo Discussion greddy on a 1.8? homebrew kit?

Reply



LinkBack Thread Tools
Old 08-26-2007, 11:47 PM   #41
Elite Member
iTrader: (1)

Join Date: Jun 2005
Location: Charleston, SC
Posts: 2,980
Total Cats: 14
Default

Tennis ball stuffed in the exhaust pipe will test the entire system. I don't listen for a hiss - I get a mustard bottle full of water and 10 drops of soap. It will foam when you find the leak. Just soak the hell out of everything and you will find it if it is a leak.
rmcelwee is offline   Reply With Quote
Old 08-27-2007, 12:21 AM   #42
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Outside of the Loop-ATL
Posts: 754
Total Cats: 0
Default

Quote:
Originally Posted by rmcelwee View Post
Tennis ball stuffed in the exhaust pipe will test the entire system. I don't listen for a hiss - I get a mustard bottle full of water and 10 drops of soap. It will foam when you find the leak. Just soak the hell out of everything and you will find it if it is a leak.
He as a point check for leaks that way.

It really sounds as if your wastegate valve.

If anyone is located near you run a second boost gauge off the turbo and to the wastegate, or straight into the gauge. See what boost the turbo is running off.

I am wondering if maybe you just have a bad turbo? The odds are against it but doesn't mean the the T-25 died and the GT25 was DOA.
wildfire0310 is offline   Reply With Quote
Old 08-27-2007, 12:58 AM   #43
Supporting Vendor
Thread Starter
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Quote:
Originally Posted by rmcelwee View Post
Tennis ball stuffed in the exhaust pipe will test the entire system. I don't listen for a hiss - I get a mustard bottle full of water and 10 drops of soap. It will foam when you find the leak. Just soak the hell out of everything and you will find it if it is a leak.
How would a tennis ball in the exhaust pipe do anything different compared to what I've already done (ABS caps in the turbo inlet to the final elbow at the TB)? The IC pipes aren't broken. This is not a pinhole leak. If it were a pinhole leak or a tiny leak that were exasperated by pressure, the 30psi I fed the IC pipes today would have revealed it.

Can a turbo spin freely, have minimal shaft play, and still be bad?

Again, the wastegate is wired closed.

Last edited by Savington; 08-27-2007 at 01:22 AM.
Savington is offline   Reply With Quote
Old 08-27-2007, 02:48 AM   #44
Elite Member
iTrader: (1)

Join Date: Jun 2005
Location: Charleston, SC
Posts: 2,980
Total Cats: 14
Default

Quote:
Originally Posted by Savington View Post
How would a tennis ball in the exhaust pipe do anything different compared to what I've already done (ABS caps in the turbo inlet to the final elbow at the TB)?
I thought you were looking to check the exhaust side for external leaks?

"I'm going to figure out a way to test the hotside piping"
rmcelwee is offline   Reply With Quote
Old 08-27-2007, 03:18 AM   #45
Supporting Vendor
Thread Starter
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Why would I care about an exhaust leak? That won't cause the turbo to suddenly stop making boost, would it?

Hotside = piping between the turbo compressor and the intercooler
coldside = piping between the intercooler and the throttle body

I'm going to give PR Motorsports a call on Monday. I'll let you all know what the cause of this was.
Savington is offline   Reply With Quote
Old 08-27-2007, 05:40 AM   #46
Elite Member
iTrader: (1)

Join Date: Jun 2005
Location: Charleston, SC
Posts: 2,980
Total Cats: 14
Default

Quote:
Originally Posted by Savington View Post
Why would I care about an exhaust leak? That won't cause the turbo to suddenly stop making boost, would it?

Hotside = piping between the turbo compressor and the intercooler
coldside = piping between the intercooler and the throttle body

I'm going to give PR Motorsports a call on Monday. I'll let you all know what the cause of this was.
My bad - I thought by hotside you were meaning the turbo manifold (losing pressure before it hit the compressor). I've never heard that terminology before concerning turbos (only SC's where hotside refers to the exhaust side of the engine).
rmcelwee is offline   Reply With Quote
Old 08-27-2007, 05:47 AM   #47
Supporting Vendor
Thread Starter
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Quote:
Originally Posted by rmcelwee View Post
My bad - I thought by hotside you were meaning the turbo manifold (losing pressure before it hit the compressor). I've never heard that terminology before concerning turbos (only SC's where hotside refers to the exhaust side of the engine).
No problem. I'm pretty ******* irritated at this problem, so I'm a little on edge. If it was something obvious like a busted wastegate or a failed turbo, I'd be fine with it, but going through every single possible cause of this and still not knowing why is really frustrating.

I've been building this car for a year, and it's only been running for 6 weeks, and I leave for college in 3 weeks and the car fails? **** that. I want to drive the thing, not chase some bullshit ghost problem.
Savington is offline   Reply With Quote
Old 08-27-2007, 08:27 AM   #48
AFM Crusader
iTrader: (18)

olderguy's Avatar

Join Date: Oct 2004
Location: Wayne, NJ
Posts: 4,438
Total Cats: 84
Default

Not that it helps with your problem, but how did you wire the wastegate closed? Picture?
olderguy is offline   Reply With Quote
Old 08-27-2007, 08:40 AM   #49
Elite Member
iTrader: (1)

Join Date: Jun 2005
Location: Charleston, SC
Posts: 2,980
Total Cats: 14
Default

Quote:
Originally Posted by rmcelwee View Post
My bad - I thought by hotside you were meaning the turbo manifold (losing pressure before it hit the compressor). I've never heard that terminology before concerning turbos (only SC's where hotside refers to the exhaust side of the engine).
UGH, I meant turbine not compressor. Screw it, I'm going to bed...
rmcelwee is offline   Reply With Quote
Old 08-27-2007, 12:47 PM   #50
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Outside of the Loop-ATL
Posts: 754
Total Cats: 0
Default

Quote:
Originally Posted by Savington View Post
Can a turbo spin freely, have minimal shaft play, and still be bad?

Again, the wastegate is wired closed.

Normally No if the turbo spins free and has minimal shaft play then normally the turbo is fine, but i think your problem goes pass normal. Maybe one of the interal seals on the turbo is shot and causing it not to build pressure but the bearings maybe fine.... again not a normal thing but I have heard of one turbo back in the DSM world that someone had that one of the seals was bad but the bearing was fine.

IF you know anyone around you with a working t-25, pull it from their car swap it to your and see if corrects the problem. Otherwise I am completely out of ideas man.

Good luck and please tells us what the cause is.
wildfire0310 is offline   Reply With Quote
Old 08-27-2007, 02:52 PM   #51
Supporting Vendor
Thread Starter
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

Quote:
Originally Posted by olderguy View Post
Not that it helps with your problem, but how did you wire the wastegate closed? Picture?
I'll shoot a picture when I load it up. Just some safety wire wrapped around the wastegate arm and the actuator bracket.
Savington is offline   Reply With Quote
Old 04-23-2015, 10:45 AM   #52
Senior Member
iTrader: (6)

Join Date: Sep 2007
Posts: 1,085
Total Cats: 30
Default

So, Andrew, what was the issue here?
albumleaf is offline   Reply With Quote
Old 04-23-2015, 10:52 AM   #53
AFM Crusader
iTrader: (18)

olderguy's Avatar

Join Date: Oct 2004
Location: Wayne, NJ
Posts: 4,438
Total Cats: 84
Default

Quote:
Originally Posted by albumleaf View Post
So, Andrew, what was the issue here?
Yeah! You have had almost eight years to figure it out
olderguy is offline   Reply With Quote
Old 04-23-2015, 11:51 AM   #54
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Thread made by Andrew about something turbo. Must be ancient.
curly is offline   Reply With Quote
Old 04-23-2015, 12:05 PM   #55
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 782
Default

Andrew wiring GT2554r wastegate shut.

I like his style.
concealer404 is offline   Reply With Quote
Old 04-23-2015, 12:29 PM   #56
Supporting Vendor
Thread Starter
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,363
Total Cats: 1,323
Default

The divider that BEGi used to weld into their downpipes was holding the WG flap open, IIRC.

Quote:
Originally Posted by curly View Post
Thread made by Andrew about something turbo. Must be ancient.
Savington is offline   Reply With Quote
Old 04-23-2015, 12:32 PM   #57
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 782
Default

Quote:
Originally Posted by Savington View Post
The divider that BEGi used to weld into their downpipes was holding the WG flap open, IIRC.





concealer404 is offline   Reply With Quote
Old 04-23-2015, 12:54 PM   #58
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

hashtag #throwbackthursday
y8s is offline   Reply With Quote
Old 04-23-2015, 01:05 PM   #59
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,185
Total Cats: 2,582
Default

Attached Thumbnails
Why does my car make no boost with the wastegate safety-wired closed?-1274556790209.jpg
18psi is offline   Reply With Quote
Old 04-23-2015, 01:09 PM   #60
Elite Member
iTrader: (1)

Join Date: Jun 2014
Location: Austin, TX
Posts: 2,843
Total Cats: 271
Default

Attached Thumbnails
Why does my car make no boost with the wastegate safety-wired closed?-mosrwfo.gif
Girz0r is offline   Reply With Quote
