Old 03-01-2012, 10:52 PM   #21
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by TNTUBA View Post
PM me your E-Mail address and we can talk there.
Thanks for the MSQ. Unfortunately, almost everything is exactly the same. Strange...time to pull my hair out.
Attached Files
File Type: msl 2012-03-01_20.23.21 (1).msl (649.6 KB, 62 views)
hustler is offline   Reply With Quote
Old 03-02-2012, 02:52 AM   #22
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,441
Total Cats: 199
Default

Are you autotuning AND datalogging at the same time in that datalog?
Reverant is offline   Reply With Quote
Old 03-02-2012, 10:19 AM   #23
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by Reverant View Post
Are you autotuning AND datalogging at the same time in that datalog?
No.
hustler is offline   Reply With Quote
Old 03-02-2012, 11:09 AM   #24
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,110
Total Cats: 518
Default

Quote:
Originally Posted by Reverant View Post
Are you autotuning AND datalogging at the same time in that datalog?
Is this considered a big no-no? Or does it just make the log fairly useless.
curly is offline   Reply With Quote
Old 03-02-2012, 12:55 PM   #25
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by curly View Post
Is this considered a big no-no? Or does it just make the log fairly useless.
Moderately useless.
hustler is offline   Reply With Quote
Old 03-02-2012, 12:55 PM   #26
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

On a related note:
Attached Thumbnails
Huster is tuning Jeff's 99SC blow-through, come answer questions-no-clue.jpg
hustler is offline   Reply With Quote
Old 03-02-2012, 01:25 PM   #27
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,441
Total Cats: 199
Default

First of all, there's no reason to datalog when you are autotuning. Either autotune or grab a datalog to analyze later, either manual or through the "manual" VE Analyzer. Doing both taxes the serial link and you end up with many "gaps" in the datalog.

Having said that, I would like to see a clear, short datalog, showing ONE problem and NOTHING else.
Reverant is offline   Reply With Quote
Old 03-02-2012, 03:23 PM   #28
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

hustler is offline   Reply With Quote
Old 03-02-2012, 03:23 PM   #29
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by Reverant View Post
First of all, there's no reason to datalog when you are autotuning. Either autotune or grab a datalog to analyze later, either manual or through the "manual" VE Analyzer. Doing both taxes the serial link and you end up with many "gaps" in the datalog.

Having said that, I would like to see a clear, short datalog, showing ONE problem and NOTHING else.
I'll do this tomorrow. Thanks.
hustler is offline   Reply With Quote
Old 03-03-2012, 04:19 PM   #30
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

I went and picked-up Jeff's car today. I started back at square one and realized I overlooked a few things, things that were already set-up for me in MS1 from DIY. My CLT and IAT sensor calibrations were wrong, thanks to the DIY site I pulled their information in. The fuel table was so out of shape that VEAL wouldn't work, so I tuned the fuel table by hand. The fuel table is just about done, working on enrichments and played with the fuel injection timing table a bit. I will be done with the road tune in an hour or so...after I get all the damp air out of Jeff's cooling system. What a ***.

Thanks for the help everyone, it's always a stupid mistake on my part. I also broke down and paid for MLV, like a bauce.

On a related note, Jeff's car is slow as ----. Turbonator > Eaton hand dryer.
hustler is offline   Reply With Quote
Old 03-03-2012, 10:59 PM   #31
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

I used these thermistor settings for the CLT:


Temperature F Resistance In Ohms
14 9000
68 2500
176 320

...and CLT says 230 when the gauge and temp-strip say ~210*f. What should I do?
hustler is offline   Reply With Quote
Old 03-04-2012, 04:24 AM   #32
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,441
Total Cats: 199
Default

The ECU came with the calibrations already set perfectly, why did you change them?
Reverant is offline   Reply With Quote
Old 03-04-2012, 12:25 PM   #33
Tour de Franzia
Thread Starter
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by Reverant View Post
The ECU came with the calibrations already set perfectly, why did you change them?
Because I believe CLT and IAT values were off. I also knew the WBO2 settings were off so I changed them all, to be sure. Post-up your values and I'll switch back and see what the car does.

I thought I was doing the right thing by going back and confirming settings. Sorry to be a pest.
hustler is offline   Reply With Quote
Old 03-04-2012, 01:46 PM   #34
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,441
Total Cats: 199
Default

CLT is 34*F -> 5900, 84*F -> 1700, 180*F -> 310. The IAT calibration was the GM IAT, because that was supposed to be used.
Reverant is offline   Reply With Quote
