Default I want to weather proof a small circut.

I know the oems sometimes use a glue or an epoxy to weather proof small circuits. does anyone have experience with this perhaps a 2 part epoxy would be fine? any thoughts on what type of glue to use or what not to use?
psreynol is offline   Reply With Quote
Old 05-23-2012, 11:10 PM   #2
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 406
Default

look up "potting" for what you wanna do. you can buy it quite a few places. like electronics parts stores or mcmaster or amazon even.
y8s is offline   Reply With Quote
Old 05-23-2012, 11:34 PM   #3
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by psreynol View Post
does anyone have experience with this perhaps a 2 part epoxy would be fine?
For simple stuff like back-filling connectors, I use the cheap 2-part clear plastic epoxy that comes in the twin syringe at the hardware store. The kind that comes with a mixing nozzle is easiest, as you can just squirt it right in. This provides a good strain relief for wires as well.

If you're covering a larger area such as a circuit board, you can get conformal coating in a spray can: http://www.mouser.com/ProductDetail/...Nj3ikaWEFdc%3d

This is the stuff that the "pros" use for weatherproofing PCBs. It goes on very thin, like a paint. Doesn't provide any strain relief for things like wire-to-board joints, but is fast and easy to apply, and doesn't add any bulk.
Joe Perez is offline   Reply With Quote
Old 05-24-2012, 07:43 PM   #4
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

What joe says is dumb.

Just go buy some 100% silicone caulk and spoodge the ever living fucky out of it.
Faeflora is offline   Reply With Quote
Old 05-24-2012, 07:47 PM   #5
Elite Member
iTrader: (10)

soviet's Avatar

Join Date: Jan 2010
Location: VA
Posts: 3,516
Total Cats: 255
Default

Quote:
Originally Posted by Joe Perez View Post
If you're covering a larger area such as a circuit board, you can get conformal coating in a spray can: http://www.mouser.com/ProductDetail/...Nj3ikaWEFdc%3d

This is the stuff that the "pros" use for weatherproofing PCBs. It goes on very thin, like a paint. Doesn't provide any strain relief for things like wire-to-board joints, but is fast and easy to apply, and doesn't add any bulk.
Techspray's Turbo-Coat™ Acrylic Conformal Coating
Attached Thumbnails
I want to weather proof a small circut.-tumblr_m3thrqqyoo1qfssyl.jpg
soviet is offline   Reply With Quote
Old 06-13-2012, 04:51 PM   #6
Elite Member
iTrader: (2)

triple88a's Avatar

Join Date: Apr 2006
Location: Chicago, IL
Posts: 9,131
Total Cats: 598
Default

Wrap each connector in electric tape then "paint" it with liquid tape. If you have to open up the connector down the line simply cut into the tape and it will be simple and clean.
triple88a is offline   Reply With Quote
Old 06-22-2012, 01:33 AM   #7
Senior Member
iTrader: (3)

Join Date: Dec 2008
Location: KY
Posts: 698
Total Cats: 48
Default

I was talking to the electronics guru in our shop today and he said just about any commonly available epoxy is fine, jb weld included. He did mentioned to NOT use any RTV sealants because the outgassing process they go through can ---- up electrical components.
jpreston is offline   Reply With Quote
