04-22-2015, 05:55 PM

#41

patsmx5

Elite Member

iTrader: (16)

Join Date: Aug 2007

Location: Houston, TX

Posts: 9,297

Total Cats: 477

Thanks Joe!

I looked at his engine build thread, and this post shows that piece is in fact installed in his block.

04-22-2015, 06:55 PM

#42

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

Quote:

Originally Posted by patsmx5

Try something man!

ROFL

04-22-2015, 06:57 PM

#43

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

I guess I could try 50w although 40w did nada. I'm trying another trick too.

04-22-2015, 07:00 PM

#44

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

Quote:

Originally Posted by Joe Perez

That plug goes in the galley which feeds oil up from the block into the head. It's present in every Miata engine from 1990 through 2005, be it HLA, solid or VVT.

Thanks all, I didn't know what that was either, and thanks Pat for looking up the pic for me!

04-23-2015, 07:53 AM

#45

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

I blocked the cam cover dumps with JB Weld and drilled to 1/16" which raised idle pressure ~5-8lb but max pressure still 40lb and not enough for VVT operation.

04-23-2015, 07:56 AM

#46

sixshooter

Moderator

iTrader: (12)

Join Date: Nov 2008

Location: Tampa, Florida

Posts: 20,652

Total Cats: 3,011

VVT will not operate at 40lbs, huh? That's interesting.

04-23-2015, 08:00 AM

#47

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

What do you infer from this?

04-23-2015, 09:32 AM

#48

sixshooter

Moderator

iTrader: (12)

Join Date: Nov 2008

Location: Tampa, Florida

Posts: 20,652

Total Cats: 3,011

I would just assume that 40psi would be adequate to actuate the system. 40psi is within the parameters of what I would consider normal oil pressure.

04-23-2015, 09:39 AM

#49

Joe Perez

Boost Pope

iTrader: (8)

Join Date: Sep 2005

Location: Chicago. (The less-murder part.)

Posts: 33,027

Total Cats: 6,593

Quote:

Originally Posted by sixshooter

I would just assume that 40psi would be adequate to actuate the system. 40psi is within the parameters of what I would consider normal oil pressure.

It's very slightly below the lower end of the spec (warm @ 3,000 is quoted as 43-56), however it should certainly be adequate to operator the VVT mechanism.

04-23-2015, 10:15 AM

#50

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

The engine light comes on at ~2500-3000 & ~30-35lb. The VVT may function at higher rpm tho.

04-23-2015, 10:37 AM

#51

Joe Perez

Boost Pope

iTrader: (8)

Join Date: Sep 2005

Location: Chicago. (The less-murder part.)

Posts: 33,027

Total Cats: 6,593

Quote:

Originally Posted by stigish

The engine light comes on at ~2500-3000 & ~30-35lb.

That seems reasonable.

(I assume that the CEL is for P0012.)

Just to double-check, you are using engine oil in your engine, and not Italian salad dressing, right?

04-23-2015, 11:30 AM

#52

stigish

Junior Member

Thread Starter

Join Date: Aug 2014

Posts: 87

Total Cats: -1

Quote:

Originally Posted by Joe Perez

That seems reasonable.

(I assume that the CEL is for P0012.)

Just to double-check, you are using engine oil in your engine, and not Italian salad dressing, right?

= >

Attached Thumbnails

02 VVT oil pressure loss-original_dressing.jpg

02 VVT oil pressure loss-k2-_607d5e9e-1015-490a-8d89-f3090f5284f0.v1.jpg

11-18-2015, 04:15 AM

#53

Itty

Junior Member

Join Date: Jul 2015

Location: Bremerton, WA

Posts: 440

Total Cats: 34

Soo, did you ever figure this out? I'm going to look at a car this weekend with a P0012 but maybe I won't bother if it's this much of a pain in the ***.
