Default did head gasket now car not starting?

hey guys i need some help i did my head gasket on my miata 1.6l i put everything back n i went to start the car n is not startin i have fuel ,spark timing on rite car is juss not startin now ...if any can help me out


thank you..
MiataWave99 is offline   Reply With Quote
Old 10-03-2011, 01:54 PM   #2
Elite Member

Join Date: Mar 2010
Location: Detroit
Posts: 1,524
Total Cats: 27
Default

double check timing, or take a pic of the cam sprockets for me.
flounder is offline   Reply With Quote
Old 10-03-2011, 01:55 PM   #3
Newb
Thread Starter

Join Date: Aug 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by flounder View Post
double check timing, or take a pic of the cam sprockets for me.
ok thankx ill do that ...
MiataWave99 is offline   Reply With Quote
Old 10-03-2011, 02:30 PM   #4
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,106
Total Cats: 518
Default

Most likely timing, although as a last ditch effort switch plug wires 1&4 and 2&3, easier than pulling the valve cover.
curly is online now   Reply With Quote
Old 10-03-2011, 02:32 PM   #5
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,914
Default

Sounds like a case of E=I and I=E perhaps? The photograph should be taken from the front, so we can see the cam gears and the plate behind them. Rotate the crank to #1 TDC before you take the picture.

Though I can't imagine how you'd get the ignition timing to be dead-on in that scenario...
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 02:40 PM   #6
Newb
Thread Starter

Join Date: Aug 2011
Posts: 12
Total Cats: 0
Default

here are the pix guy hope there good
Attached Thumbnails
did head gasket now car not starting?-imag0200.jpg   did head gasket now car not starting?-imag0203.jpg   did head gasket now car not starting?-imag0217.jpg
MiataWave99 is offline   Reply With Quote
Old 10-03-2011, 02:45 PM   #7
Junior Member

Join Date: Sep 2010
Location: SFL
Posts: 376
Total Cats: 3
Default

your cams are not correct.

the left one should be I and the right one should be E both point as straight up as possible.
MD323 is offline   Reply With Quote
Old 10-03-2011, 02:47 PM   #8
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,914
Default

Yeah, if that was taken at #1 TDC, then the cams are way off.

Here's what you want:

Attached Thumbnails
did head gasket now car not starting?-eq9er.gif
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 03:09 PM   #9
Newb
Thread Starter

Join Date: Aug 2011
Posts: 12
Total Cats: 0
Default

Quote:
Originally Posted by joe perez View Post
yeah, if that was taken at #1 tdc, then the cams are way off.

Here's what you want:

thank you guys for the help i have them way off ....
MiataWave99 is offline   Reply With Quote
Old 10-03-2011, 03:14 PM   #10
Newb
Thread Starter

Join Date: Aug 2011
Posts: 12
Total Cats: 0
Default

hey guys cuz i had them off will it had messed anything up cuz i wus tryin to start it? like the valves?
MiataWave99 is offline   Reply With Quote
Old 10-03-2011, 03:30 PM   #11
I'm Miserable!

Join Date: Jun 2009
Location: albany, ga
Posts: 1,869
Total Cats: 3
Default

no
Techsalvager is offline   Reply With Quote
Old 10-03-2011, 03:33 PM   #12
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by MiataWave99 View Post
hey guys cuz i had them off will it had messed anything up cuz i wus tryin to start it? like the valves?
What's the minus of thirty and twenty?
hustler is offline   Reply With Quote
Old 10-03-2011, 03:41 PM   #13
Junior Member

Join Date: Sep 2010
Location: SFL
Posts: 376
Total Cats: 3
Default

Quote:
Originally Posted by MiataWave99 View Post
hey guys cuz i had them off will it had messed anything up cuz i wus tryin to start it? like the valves?
the BP/B6 motors is not an interference motor, random non mazda people love to state otherwise but your fine.
MD323 is offline   Reply With Quote
Old 10-03-2011, 04:32 PM   #14
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,914
Default

Quote:
Originally Posted by MiataWave99 View Post
hey guys cuz i had them off will it had messed anything up cuz i wus tryin to start it?
No, it not will had messed up anything.
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 07:14 PM   #15
Elite Member
iTrader: (11)

Join Date: Feb 2009
Posts: 2,982
Total Cats: 10
Default

Quote:
Originally Posted by Joe Perez View Post
Yeah, if that was taken at #1 TDC, then the cams are way off.

Here's what you want:

If this image isn't in "useful saved posts", then it should. Along with the number of timing belt teeth between the sprockets.
miatauser884 is offline   Reply With Quote
Old 10-03-2011, 10:15 PM   #16
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,106
Total Cats: 518
Default

The more important one is the cam lobe direction at TDC. I've always been fine doing the timing belt unless I've taken the sprockets off. Why Mazda made it so you could put it on wrong is beyond me.
curly is online now   Reply With Quote
Old 10-03-2011, 10:35 PM   #17
Elite Member
iTrader: (11)

Join Date: Feb 2009
Posts: 2,982
Total Cats: 10
Default



I thought there is a notch on the cam that should be pointing at 12 when at . Then place sprockets accotdingly. Seemed to work for me.
miatauser884 is offline   Reply With Quote
Old 10-03-2011, 10:57 PM   #18
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,914
Default

Quote:
Originally Posted by curly View Post
Why Mazda made it so you could put it on wrong is beyond me.


The short answer is that before you start the job, you need to have the engine at #1 TDC, and then just don't rotate anything once you've begun. On interference engines, this rule is absolute.
Attached Thumbnails
did head gasket now car not starting?-pb5pr.gif
Joe Perez is offline   Reply With Quote
Old 10-03-2011, 11:14 PM   #19
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,106
Total Cats: 518
Default

We use these little Star Trek communicators called Voceras at work. The moron (read: geek) that designed them decided to make a charger that would fit the unit forwards or backwards, although it'll only charge when facing forward. Same with the battery, except not only can it fit backwards, but it can fit upside down as well.

Another example of idiocy.
curly is online now   Reply With Quote
Old 10-04-2011, 12:09 AM   #20
Junior Member

Join Date: Sep 2010
Location: SFL
Posts: 376
Total Cats: 3
Default

Quote:
Originally Posted by curly View Post
The more important one is the cam lobe direction at TDC. I've always been fine doing the timing belt unless I've taken the sprockets off. Why Mazda made it so you could put it on wrong is beyond me.
they are designed that way so they only need to tool for one pulley, they fit either side.
MD323 is offline   Reply With Quote
