Old 03-11-2008, 10:42 AM   #101
Elite Member
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

There's a link in my post.
Atlanta93LE is offline   Reply With Quote
Old 03-11-2008, 10:42 AM   #102
Elite Member
iTrader: (24)

Join Date: Jul 2007
Location: Cypress, TX
Posts: 3,778
Total Cats: 35
Default

Bryce is offline   Reply With Quote
Old 03-11-2008, 10:44 AM   #103
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by Atlanta93LE View Post
There's a link in my post.
I saw it. Thanks.
Ben is offline   Reply With Quote
Old 03-11-2008, 10:46 AM   #104
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by Bryce View Post
OK, think I just got thrown off by the "ECE" name. ECE means nothing more than E-code pattern correct? If so, Miatarodster has them for $75/pr shipped.
Ben is offline   Reply With Quote
Old 03-11-2008, 10:47 AM   #105
Elite Member
iTrader: (24)

Join Date: Jul 2007
Location: Cypress, TX
Posts: 3,778
Total Cats: 35
Default

Correct.

And to be honest I never noticed it said ECE.
Bryce is offline   Reply With Quote
Old 03-11-2008, 10:49 AM   #106
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by Saml01 View Post
Why not try some Hella ECE housings? They have a cutoff.
Quote:
Originally Posted by Bryce View Post
And to be honest I never noticed it said ECE.


So E codes + HID eh? Hmm
Ben is offline   Reply With Quote
Old 03-11-2008, 11:03 AM   #107
Elite Member
iTrader: (24)

Join Date: Jul 2007
Location: Cypress, TX
Posts: 3,778
Total Cats: 35
Default

I don't know how much HIDs would change the situation, but they have a cutoff unlike DOT head lights. So why not?
Bryce is offline   Reply With Quote
Old 03-11-2008, 11:57 AM   #108
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

infromashun on e-code lamps and aiming:
http://www.danielsternlighting.com/tech/aim/aim.html

I had the 6054 "everycar in america" ecodes on my celica. i kept the housings in case I ever got another car with that style. the cutoff was impressively non US. worth a shot with the HIDs.

Here you go Ben, 7" projectors. that look like a pair of ****.
http://www.oman4x4.com/hidlights.htm

also:
http://www.suvlights.com/product_inf...79a03feff05167

this place is where I got my visionplus stuff that's in the miata now.
y8s is offline   Reply With Quote
Old 03-11-2008, 12:21 PM   #109
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

X-Sighting Lamps look great, but at $900/pr I can't have them.

Looks like E code + HID
Ben is offline   Reply With Quote
Old 03-11-2008, 12:40 PM   #110
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Quote:
Originally Posted by Bryce View Post
I don't know how much HIDs would change the situation, but they have a cutoff unlike DOT head lights. So why not?
http://72.215.196.56/hummers/headlig...visionplus.htm
I ordered the Hellas from miataroadster. Hopefully I can have them by this weekend.
Ben is offline   Reply With Quote
Old 03-11-2008, 01:09 PM   #111
Elite Member
iTrader: (11)

Join Date: Jun 2007
Location: Overland Park, Kansas
Posts: 5,382
Total Cats: 43
Default

Quote:
Originally Posted by TurboTim View Post
Nice. My dad is a keystone dealer, I didn't know there even existed a 7" projector conversion that I could get for cheap I run the Hella E-codes with the PIAA Extreme white plus's, just like Dan used to. I also run 2 more PIAA H4's in my "driving" lights. I'd be nice to convert all 4 to projectors.
Okay I'm a little rusty on the lighting subject, but if memory serves me correctly this "E-code" talk is nothing more than European headlight housings, which, are technically not legal in the united states anyway.. Which is why they're "e-code."

Second, don't waste your time or money on the socalled 7" projector light housings, they're complete and total ******* trash. Even with my HID lights, they put out less light than in a standard h4 parabolic housing.




Quote:
Originally Posted by danscreations View Post
Alright guys...i'm not sure where the confusion came in or it's just wrong wording but I'M NOT RUNNING PROJECTORS; THEY ARE 7" CONVERSION LIGHTS! I just got off the phone with our old sales rep but Keystone carries soo many different brands/types of these it was hard find out exactly what I bought. This was two years ago that I bought these so I remember ruffly in May of 2006 so he looked back and 2x Pilot WI-HL3's were ordered which was one of the ones we were thinking I had. So I'm 85-90% sure on these however in the photo they look like they have the city light socket but the ones I have don't have that. So it's either the wrong photo or hopefully it's just a shadow. So Here We Go!

2x Pilot 7" Conversion Lights (Part #:WI-HL3; KEYSTONE Part #:WIHL3)
Link To Where/Who I Purchased From (enter the keystone part number into the search)


1x Xentec H4 (low) 8000k HID Kit
Link To Where/Who I Purchased From
I've been running the exact same brand of ballast. They're great for what I paid for em. My expensive set died in 8 months, these have been kicking for 2 years now. I opted for the 6000k bulbs, which put out nearly 1.25 times the lumens of the 8000k. Personally don't see why bulbs are even made > 6000k myself, but whatever. To each their own.

To those calling HID conversion ricers, you can eat my ******* ***. Like ben said, take your m.net thinking back to miata.net. My safety on the road is much more important to me then caring about anyone else on the road. Been driving with HIDs in my miata for 3 years now and have been questioned by the police about them one time. If you want cheeze dick 20 watt yellow lights in your car so some big *** truck can pull out infront of you, fine, just don't **** on my parade cause you've got sand..

This is the bulb I run. First and second pictures are the same bulb. Third photograph is a standard HID light bulb. Notice the little hat on my first bulb? I believe thats a D2R designed for a parabolic reflector housing, where teh D2S (Second bulb) is designed for a projector with horizontal cutoff. While my lights are hellatiously bright, and scatter light in all directions, its not nearly intense to oncoming traffic as a D2S in Parabolic housing. Thats my $0.02 on the matter.






Quote:
Originally Posted by SamS View Post
Where do you source the power for the ballasts?
I've been running mine directly off the factory headlight wiring harness on both my miata and my crotch rocket.
elesjuan is offline   Reply With Quote
Old 03-11-2008, 01:12 PM   #112
Elite Member
iTrader: (11)

Join Date: Jun 2007
Location: Overland Park, Kansas
Posts: 5,382
Total Cats: 43
Default

Quote:
Originally Posted by SamS View Post
www.jrtlighting.com

Granted, they don't sell their kits for $80 shipped.
Yet their Ballasts look IDENTICAL to mine, with a different sticker...
elesjuan is offline   Reply With Quote
Old 03-11-2008, 01:53 PM   #113
Junior Member
iTrader: (7)

Join Date: May 2007
Location: Buffalo, NY
Posts: 332
Total Cats: 0
Default

Quote:
Originally Posted by elesjuan View Post
Yet their Ballasts look IDENTICAL to mine, with a different sticker...
And they look exactly like mine, which is a different brand from ebay. I bet they're all from the same factory in China, just different labels. Just get whatever is cheapest, and if it blows get another one.
longuyen88 is offline   Reply With Quote
Old 03-11-2008, 02:57 PM   #114
Elite Member
iTrader: (11)

Join Date: Jun 2007
Location: Overland Park, Kansas
Posts: 5,382
Total Cats: 43
Default

Quote:
Originally Posted by longuyen88 View Post
And they look exactly like mine, which is a different brand from ebay. I bet they're all from the same factory in China, just different labels. Just get whatever is cheapest, and if it blows get another one.
You found my exact plan! For 80$ if they last a year, sweet. I'll spend it every year if I have to, really. I don't care.
elesjuan is offline   Reply With Quote
Old 03-12-2008, 08:58 AM   #115
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Spent more time working with the ching chong housings to get a decent aim. Got them pretty decent. Actually the cut off is not too bad, and light is distributed pretty well. A strip of tape placed horizontally on the bottom of the lenses would make them totally usable--and a huge improvement over stock. But I've already ordered the Hella E codes so oh well. I'm sure they'll be even better anyway.
Ben is offline   Reply With Quote
Old 03-12-2008, 11:20 AM   #116
Senior Member
iTrader: (2)

SamS's Avatar

Join Date: Jun 2006
Location: Wisconsin
Posts: 1,252
Total Cats: 7
Default

Something's wrong with your progress pics, they're not showing up...
SamS is offline   Reply With Quote
Old 03-12-2008, 11:27 AM   #117
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Didn't have a camera on me this morning
Ben is offline   Reply With Quote
Old 03-12-2008, 11:36 AM   #118
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

BTW, if some one were to want my ching chong housings, cost of shipping and they're yours. They do look and work better than the stock sealed beams with H4 halogens.
Ben is offline   Reply With Quote
Old 03-12-2008, 09:49 PM   #119
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

My cheap-o point-n-shoot doesn't do a very good job of this. These ching chong housings have a much better cut off than what the pics show. Also I think it will be clear that I lowered the driver's side lamp a little extra, just to totally ensure that oncoming traffic won't be blinded. It's a little low and to the right. Bet you've said that before...

In pic 3 I drew in the cut off lines, as the eye sees them. They're not quite as defined as what I've drawn, but not far off either. The reflective garage door was playing tricks with the camera. The two circles are "hot spots" or whatever, caused by light reflecting off the stupid city bulbs in the ching chong housings. Too bad.
Attached Thumbnails
The NA HID Question-1.jpg   The NA HID Question-2.jpg   The NA HID Question-3.jpg   The NA HID Question-5.jpg
Ben is offline   Reply With Quote
Old 03-12-2008, 09:50 PM   #120
Ben
Supporting Vendor
Thread Starter
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

All the pics I took while driving sucked ***. Here's the best 2.

This headlamp set up is amazing compared to stock. Well worth the time and effort. And when aimed as per Daniel Stern's directions (I did aim the driver's side an extra 1.5" low), are not discourteous to oncoming traffic. Driving around tonight resulted in 0 people flashing their high beams at me.
Attached Thumbnails
The NA HID Question-6.jpg   The NA HID Question-7.jpg
Ben is offline   Reply With Quote
