Default Trouble removing halfshafts from diff

I've been wanting to check the 1.8 rearend I bought to determine whether it is a Torsen, but I wasn't able to remove the halfshafts from the diff. I'm embarrassed to ask, but what's the trick to removing them?
Atlanta93LE is offline   Reply With Quote
Old 05-08-2007, 11:31 PM   #2
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,809
Total Cats: 1,780
Default

prybar works. or hammer from behind.
Braineack is offline   Reply With Quote
Old 05-08-2007, 11:33 PM   #3
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

Hmmm. Damn near busted my finger in half when the prybar slipped. I'll try the hammer tomorrow.
Atlanta93LE is offline   Reply With Quote
Old 05-08-2007, 11:51 PM   #4
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

Chain one end to big oak tree. Chain other to truck. Go for a drive.
Ben is offline   Reply With Quote
Old 05-08-2007, 11:58 PM   #5
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

I could just let your shop dog have a go...but then it'd be split into many more pieces than 3.
Atlanta93LE is offline   Reply With Quote
Old 05-09-2007, 12:13 AM   #6
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

I would NOT recommend pissing off the rottie.

I should have shown you the cave she dug in the back yard.
Attached Thumbnails
Trouble removing halfshafts from diff-dog.jpg
Ben is offline   Reply With Quote
Old 05-09-2007, 11:35 AM   #7
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Is it the early style 1.8 (94-95) where they use stub axles, or are the halfshafts themselves stuck in the differential?
Joe Perez is offline   Reply With Quote
Old 05-09-2007, 12:45 PM   #8
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

'94.
Atlanta93LE is offline   Reply With Quote
Old 05-10-2007, 12:21 AM   #9
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

Bah. I took the longer part of the halfshafts out, but the stubshafts don't seem to want to budge. Not very much room to swing a hammer and make contact.
Atlanta93LE is offline   Reply With Quote
Old 05-10-2007, 11:02 AM   #10
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by Atlanta93LE View Post
Bah. I took the longer part of the halfshafts out, but the stubshafts don't seem to want to budge.
Since you've got the flanged version to work with, you're in luck. Here's a trick.

Using a hammer, drive out two of the threaded studs from each stub shaft, 180 degrees apart. Don't worry, they come out easily.

Now, locate two long bolts that will slip through the holes you just created in one of the stub shafts, and get two nuts to fit on them. I think the bolts can be 3/8 or 5/16 dia, and at least 3" long.

Put one bolt through each hole, and thread the nut onto it. You want the nut in the space between the flange and the body of the diff. Keep turning until the end of the bolt contacts the body of the diff and the nut is pressing against the inside of the flange on the stub shaft.

You have just created a puller. Using a bench vise and a friend (or two friends if you have no vise) turn the nut while holding the bolt stationary. Turn the first one a few turns, then the other, then back to the first, etc. it may take you a couple tries to find a position in the stub shaft's rotation where both bolt tips find a solid purchase against the body of the diff, but it'll happen.
Joe Perez is offline   Reply With Quote
Old 05-10-2007, 11:07 AM   #11
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,809
Total Cats: 1,780
Default

just remember...if they are that hard to pull out, they are that hard to put back
Braineack is offline   Reply With Quote
Old 05-10-2007, 11:37 AM   #12
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

That's a great idea Joe. Scott, you're thinking exactly what I've been thinking. Really, I just want to find out if this is a Torsen or not. Whatever. I need to focus on getting the turbo going before worrying about the diff. Now that the halfshafts are off the stubshafts though, it's easier to store
Atlanta93LE is offline   Reply With Quote
Old 05-10-2007, 01:06 PM   #13
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,315
Total Cats: 1,913
Default

Quote:
Originally Posted by Atlanta93LE View Post
That's a great idea Joe. ... Really, I just want to find out if this is a Torsen or not.
(bow)

Seriously though. If you know what you're looking for (and the diff is out of the car) you can peek through the fill hole while shining a small flashlight into the drain hole. This should give you a sufficient perspective to see whether it has worm gears or spider gears.
Joe Perez is offline   Reply With Quote
Old 05-10-2007, 08:01 PM   #14
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

It's a Torsen!
Atlanta93LE is offline   Reply With Quote
Old 05-10-2007, 09:16 PM   #15
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,809
Total Cats: 1,780
Default

badass! have fun digging into those corners.
Braineack is offline   Reply With Quote
Old 05-12-2007, 04:17 AM   #16
Junior Member
iTrader: (3)

timhill78's Avatar

Join Date: Aug 2006
Location: Oregon
Posts: 241
Total Cats: 0
Default

It may be a little late but you can also call mazda with your VIN and find out 800-222-5500. I juat called today and found out I have an open...Damn!
timhill78 is offline   Reply With Quote
Old 05-12-2007, 09:56 AM   #17
Elite Member
Thread Starter
iTrader: (5)

Atlanta93LE's Avatar

Join Date: Sep 2006
Location: Marietta, GA
Posts: 2,198
Total Cats: 1
Default

Tim, I would have done that first had I ever had the VIN from the car it came from
