Which are the two most important turbo gauges to have within direct line of sight? - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



General Miata Chat A place to talk about anything Miata

Reply



LinkBack Thread Tools
Old 09-24-2008, 04:06 PM   #1
Junior Member
Thread Starter
iTrader: (3)

Join Date: Dec 2007
Posts: 219
Total Cats: 0
Default Which are the two most important turbo gauges to have within direct line of sight?

I'm keeping AC, but plan on sacrificing the two center AC "eyeballs" to put two gauges in...then putting the rest below the stereo...which two should I put in the eyeballs? I have a 94 so already have a proper oil pressure gauge and also have these:

-boost
-pyrometer/EGT
-oil temp
-water temp
-wideband air/fuel gauge

Which two would you put in the eyeballs and are there other gauges I should get that I have not covered? Thanks!
scottv is offline   Reply With Quote
Old 09-24-2008, 04:18 PM   #2
Junior Member
iTrader: (6)

Join Date: Oct 2007
Location: So Cal
Posts: 331
Total Cats: 0
Default

I would have to say AFR & Boost because your cluster should have an oil pressure gauge, and it shouldn't be a dummy one because you can invest 30 dollars for a VDO sender prior to boosting.
99NBMia is offline   Reply With Quote
Old 09-24-2008, 04:25 PM   #3
Elite Member
iTrader: (33)

RotorNutFD3S's Avatar

Join Date: Jan 2007
Location: Newnan, GA
Posts: 2,539
Total Cats: 29
Default

I vote boost and WB as well.
RotorNutFD3S is offline   Reply With Quote
Old 09-24-2008, 04:26 PM   #4
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,831
Total Cats: 1,786
Default

"oh ****" and "danger to the manifold" gauges.
Braineack is online now   Reply With Quote
Old 09-24-2008, 04:30 PM   #5
Junior Member
iTrader: (6)

Join Date: Oct 2007
Location: So Cal
Posts: 331
Total Cats: 0
Default

Quote:
Originally Posted by Braineack View Post
"oh ****" and "danger to the manifold" gauges.
Name:  mechanic.jpg
Views: 4
Size:  65.8 KB
& just because this is my favorite, yet unrelated
Name:  lion.jpg
Views: 4
Size:  40.1 KB
99NBMia is offline   Reply With Quote
Old 09-24-2008, 04:32 PM   #6
Junior Member
iTrader: (1)

Join Date: Mar 2008
Location: Arizona
Posts: 75
Total Cats: 0
Default

This is a no brainer. F/A and Boost. Both of which you need to monitor if you're pounding your car. Go lean and it pops. Overboost and it will pop. Oil/water/egt temps are great for monitoring, but to me, they're not as important and if there is an issue, it wont be as instantaneous as say, a lean out or a boost creep spiking to 20psi or some ****.

My girlfriends 240sx has her gauges under her stereo and it isnt convenient at all to keep a quick glance on things.
BoostCreep is offline   Reply With Quote
Old 09-24-2008, 04:46 PM   #7
Elite Member
iTrader: (7)

samnavy's Avatar

Join Date: Apr 2006
Location: VIRGINIA BEACH, VA
Posts: 6,020
Total Cats: 175
Default

VEI dual gauges allow you to display 2 things on one gauge.

I'd say a dual OIL/WATER temp for one... and a dual AFR/EGT for the other.

Any mechanical boost gauge in a single pod holder can be mounted directly to the top of the steering column cover.

Pod:
http://www.superchargersonline.com/i.../vx-cd1200.jpg

Gauges:
http://www.vgauges.com/catalog/index...c0321ef6836067

Dual gauges for your eyeball vents, and boost right in front of you. My NB build will have the boost gauge right on top like I'm suggesting.

If somebody made something like this:http://www.puredieselpower.com/catalog/images/15014.jpg
for a Miata, they'd sell a bunch.

There are universal options:
http://static.summitracing.com/globa...um-g2878_w.jpg
http://www.glowshiftdirect.com/Unive...-Dash-Pod.aspx

You'd want to trim it to sit a little lower, and possibly buy a spare steering column cover off a salvage car and maybe try and intergrate it a little better (sit lower) and what not.
samnavy is offline   Reply With Quote
Old 09-24-2008, 04:46 PM   #8
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Chicago (Over two miles from Wrigley Field. Fuck the Cubs. Fuck them in their smarmy goat-hole.)
Posts: 26,317
Total Cats: 1,913
Default

Boost and wideband AFR. The only two parameters with the potential to transform your finely tuned engine into a heap of shattered, useless slag in just a second or two, should they go horribly, horribly wrong.
Joe Perez is offline   Reply With Quote
Old 09-24-2008, 04:56 PM   #9
Former Vendor

Join Date: Jun 2006
Location: Bell Tuning & Performance
Posts: 1,338
Total Cats: -78
Default

Wideband O2 and Boost.
Stephanie
Stephanie Turner is offline   Reply With Quote
Old 09-24-2008, 05:15 PM   #10
Junior Member

Join Date: Sep 2008
Location: Tulsa, Oklahoma
Posts: 350
Total Cats: -1
Default

The wideband and EGT are my vote. I'd have the Boost nearby too though. Perhaps right in front of me if possible. So, my setup would look like the (imagine really hard and tap your heels together), boost on A pillar or on steering column, as not you avert my eyes from the road too much when glimpsing down. Then the wideband is in the closest eyeball location with the EGT next to it. This way, I can scan all my vitals quickly if I need to and if the car is feeling funny, I only need to glance down at my Boost gauge, which will also show me if my oil pressure is off.
944obscene is offline   Reply With Quote
Old 09-24-2008, 05:20 PM   #11
Junior Member

Join Date: Sep 2008
Location: Tulsa, Oklahoma
Posts: 350
Total Cats: -1
Default

Well, on the other hand... If you had the O2 gauge directly in front of you, you'd know right quick if something was off. You only need the boost gauge to see if somethings leaking or borked. My alternate setup would have the O2 in front of me on the column or A pillar with the boost gauge and Pyrometer in the eyeballs. Looking at the boost gauge or Pyrometer only really helps, if something already happened. Sometimes you can catch a problem if something is on its way out, but I'd only look at boost for the thrill of seeing how high the needle goes. I'd want to know what my fuel mix is at all times and having the pyrometer just off to the side keeps everything viewable without mixing my priorities.
944obscene is offline   Reply With Quote
Old 09-24-2008, 05:21 PM   #12
Ben
Supporting Vendor
iTrader: (33)

Ben's Avatar

Join Date: Jul 2006
Location: atlanta-ish
Posts: 12,689
Total Cats: 99
Default

EGT and boost/vac or water temp
Ben is offline   Reply With Quote
Old 09-24-2008, 05:38 PM   #13
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 406
Default

FUEL and SPEEDO.

those two seem to be hardest to keep under control in a turbo miata.
y8s is offline   Reply With Quote
Old 09-24-2008, 07:00 PM   #14
Newb

Join Date: Dec 2007
Location: UK
Posts: 23
Total Cats: 0
Default

An alternative to the VEI dual gauges are the SPA DGs:

http://www.spa-uk.co.uk/design/dualgauges.asp

Not cheap, but precise (after calibration) and with neat extra features (warning lights on reaching customizable tresholds, etc.).
Eiffel is offline   Reply With Quote
Old 09-24-2008, 07:04 PM   #15
Elite Member
iTrader: (1)

Join Date: Jun 2007
Location: VA, Germany, Afghanistan
Posts: 2,967
Total Cats: 3
Default

If you got the $$ to drop on gauges this is hands down thebest way to go IMHO...

http://www.miatagauges.com/
KPLAFIN is offline   Reply With Quote
Old 09-24-2008, 08:17 PM   #16
Senior Member
iTrader: (4)

Join Date: May 2007
Location: Ontario
Posts: 790
Total Cats: 0
Default

Quote:
Originally Posted by Eiffel View Post
An alternative to the VEI dual gauges are the SPA DGs:

http://www.spa-uk.co.uk/design/dualgauges.asp

Not cheap, but precise (after calibration) and with neat extra features (warning lights on reaching customizable tresholds, etc.).
I have one, some of the best gauges in the world.
reddroptop is offline   Reply With Quote
Old 09-24-2008, 10:20 PM   #17
Elite Member
iTrader: (15)

Join Date: Dec 2007
Location: San Antonio, Texas
Posts: 4,889
Total Cats: 28
Default

Agreed, AFR and boost. That is how mine is set up. The gauges are in a DIN mount above the radio, which is a similar location to the eyeball vents. From left to right the gauges are AFR, boost, and coolant temperature.
ZX-Tex is offline   Reply With Quote
Old 09-24-2008, 10:29 PM   #18
Senior Member

Join Date: Jul 2008
Location: Phoenix
Posts: 657
Total Cats: 12
Default

A/C and A/C

Unless you don't like your wife, then A/C and one-of-the-above-mentioned-gauges.
oilstain is offline   Reply With Quote
Old 09-24-2008, 10:42 PM   #19
Elite Member
iTrader: (9)

Join Date: Aug 2006
Location: Concord, North Carolina
Posts: 4,172
Total Cats: 5
Default

Along these lines, I'm a ricer and have a dual pillar gauge pod...which is more important? Boost or Wideband? Which should go on the top pod and which should go on the bottom one...I'm thinking boost on top, AFR on the bottom.
miatamania is offline   Reply With Quote
Old 09-25-2008, 12:52 PM   #20
Junior Member

Join Date: Sep 2008
Location: Head Wound City, CT
Posts: 215
Total Cats: 0
Default

Quote:
Originally Posted by oilstain View Post
A/C and A/C

Unless you don't like your wife, then A/C and one-of-the-above-mentioned-gauges.
Pfft, the wife can have the eyeball on the right for the A/C.
MattEGTR is offline   Reply With Quote
