Old 05-14-2008, 04:03 PM   #41
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

This appears to be what I want... Is it? http://www.miata.net/cgi-bin/isc/cla...revaction=show
icantthink4155 is offline   Reply With Quote
Old 05-14-2008, 04:07 PM   #42
Junior Member
iTrader: (1)

Join Date: Jul 2006
Location: Colorado
Posts: 403
Total Cats: 2
Default

Quote:
Originally Posted by Savington View Post
You have to really, properly **** it up to blow the case apart. It's an exclusive club.
Can I join?
Chris Swearingen is offline   Reply With Quote
Old 05-14-2008, 04:12 PM   #43
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

showoff!
icantthink4155 is offline   Reply With Quote
Old 05-14-2008, 04:23 PM   #44
Trackspeed Engineering
iTrader: (9)

Join Date: Jan 2008
Location: Bay Area, California
Posts: 937
Total Cats: 10
Default

Quote:
Originally Posted by Chris Swearingen View Post


How the hell did that happen? Any pics of the internals? That very well could be worse than Savington's.
crashnscar is offline   Reply With Quote
Old 05-14-2008, 05:09 PM   #45
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,323
Total Cats: 1,920
Default

Quote:
Originally Posted by icantthink4155 View Post
This appears to be what I want... Is it? http://www.miata.net/cgi-bin/isc/cla...revaction=show
I can't really say if it's what you want or not. Personally, I want a ******* from Katee Sackhoff and no amount of drivetrain hardware is going to change that. It does sound like the diff package you linked to will fit your car however.

Quote:
oh crap, would a diff from an auto work?
Yes. Auto cars didn't get Torsens, but otherwise it'll fit.
Joe Perez is offline   Reply With Quote
Old 05-14-2008, 05:19 PM   #46
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

awesome
icantthink4155 is offline   Reply With Quote
Old 05-14-2008, 05:19 PM   #47
Junior Member
iTrader: (1)

Join Date: Jul 2006
Location: Colorado
Posts: 403
Total Cats: 2
Default

Quote:
Originally Posted by crashnscar View Post


How the hell did that happen? Any pics of the internals? That very well could be worse than Savington's.
No internal pictures. It's an old pic so the remains are long gone.

How did it happen?

Take one supercharged miata + a 1.6 diff and loan it to your high school senior son to use in a movie project then call the tow truck.

In fairness to him it had been whining a bit and I knew it was on its last legs.
Chris Swearingen is offline   Reply With Quote
Old 05-14-2008, 06:37 PM   #48
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,366
Total Cats: 1,327
Default

Quote:
Originally Posted by BenR View Post
No one likes a braggadocio.
Name:  x4-Bentley4.jpg
Views: 2
Size:  14.6 KB

Savington is offline   Reply With Quote
Old 05-14-2008, 06:41 PM   #49
Elite Member
iTrader: (13)

Join Date: Dec 2006
Location: Taos, New mexico
Posts: 5,703
Total Cats: 237
Default

Lmfao, man would i be stoked if my dad lent me a ubercharged miata for any reason- especially if i was still in highschool.
Fireindc is offline   Reply With Quote
Old 05-14-2008, 06:55 PM   #50
Elite Member
iTrader: (5)

Join Date: Oct 2007
Location: Canton, Ga
Posts: 1,707
Total Cats: 19
Default

Quote:
Originally Posted by Chris Swearingen View Post

holy crap. that one is broke proper. spit the bearings through the case!
Stealth97 is offline   Reply With Quote
Old 05-14-2008, 10:28 PM   #51
Elite Member
iTrader: (21)

Join Date: Jun 2007
Location: Rochester, NY
Posts: 5,686
Total Cats: 559
Default

Call partsgroup. The guy there has everything, and most at a decent price. I get stuff from them all the time. After my last "emergency", I got the parts in 1 day.
rleete is offline   Reply With Quote
Old 05-14-2008, 11:18 PM   #52
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

I looked on their website they didnt have what I needed.
icantthink4155 is offline   Reply With Quote
Old 05-15-2008, 02:15 AM   #53
Elite Member
iTrader: (9)

Join Date: Aug 2006
Location: Concord, North Carolina
Posts: 4,173
Total Cats: 5
Default

To do a 1.8 swap, either open or limited slip...

You will need the driveshaft, axles, complete housing and diff unit from a 94-05 car.

Expect to spend between 600-900 bucks for everything if its a limited slip, 300-600 if its an open (based off what I have seen).

Sound about right guys?
miatamania is offline   Reply With Quote
Old 05-15-2008, 04:02 AM   #54
Junior Member
iTrader: (2)

Join Date: Jan 2008
Location: sonora ,CA
Posts: 48
Total Cats: 0
Default

If you want i have a parts car and will sell you any thing needed to fix it 90 running gear.
p.s. the differential I have is open, but it stronger because instead of putting the stress on the ring and pin. you just do a burn out.
andygoesfast is offline   Reply With Quote
Old 05-15-2008, 11:04 AM   #55
Elite Member
iTrader: (12)

Join Date: Sep 2007
Location: Charlotte, NC
Posts: 6,868
Total Cats: 66
Default

oh yeah bitches.... i don't have any pics... but i snapped a PPF in half Several people in Ga can vouch for me.

Actually, i snapped the top half at one point (didn't realize it, i thought i ripped a diff mount because when i would get on the throttle the shift lever would torque over to one side HARD) and then i went to the Gap and drove the snot out of the car. I was on my way home from The Gap, about 10mi, and the bottom part snapped and the whole drivetrain was hanging down about 6in. I win.
Doppelgänger is offline   Reply With Quote
Old 05-15-2008, 11:40 AM   #56
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

Im in communication with someone that has a 1.8swap
icantthink4155 is offline   Reply With Quote
Old 05-15-2008, 11:59 AM   #57
Senior Member
iTrader: (14)

Join Date: Aug 2007
Location: Buffalo, NY
Posts: 734
Total Cats: 1
Default

Quote:
Originally Posted by icantthink4155 View Post
Im in communication with someone that has a 1.8swap
Communicate with me instead. I'm in Buffalo, too, so no shipping delay/expense/hassle.

Can provide a 1.8 swap with either a torsen or open diff.

deliverator is offline   Reply With Quote
Old 05-15-2008, 12:20 PM   #58
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

deliverator Responded to your PM
icantthink4155 is offline   Reply With Quote
Old 05-16-2008, 04:44 PM   #59
Elite Member
Thread Starter
iTrader: (12)

Join Date: Apr 2008
Location: Longs, SC
Posts: 2,583
Total Cats: 13
Default

ok so Ive been reading up on this, saw a few posts that say chisel off a spacer, and remove the exhaust and alot of stuff that seems very time consuming so I have some questions. If Im just swapping it all out, do I still need to do all this? Can I take the current diff out with the halfshafts still attached? Can I put the new one in with them attached? Is there any chance of the driveshaft being rusting in the transmission?

Also what is the PPF?

Last edited by icantthink4155; 05-16-2008 at 04:58 PM.
icantthink4155 is offline   Reply With Quote
Old 05-16-2008, 05:14 PM   #60
Elite Member
iTrader: (2)

Newbsauce's Avatar

Join Date: Jul 2006
Location: NoVA
Posts: 2,304
Total Cats: 2
Default

Quote:
Originally Posted by icantthink4155 View Post
ok so Ive been reading up on this, saw a few posts that say chisel off a spacer, and remove the exhaust and alot of stuff that seems very time consuming so I have some questions. If Im just swapping it all out, do I still need to do all this? Can I take the current diff out with the halfshafts still attached? Can I put the new one in with them attached? Is there any chance of the driveshaft being rusting in the transmission?

Also what is the PPF?
PPF = powerplant frame, which runs along the driveshaft tunnel there.

The swap itself is and isn't time consuming. If you know what your doing it can be done fairly quickly. If you don't, you will not do it quickly. Certain things can affect the speed of it... namely rusted ****. My axle was seized and consumed about 5 hours of effort and a broken extractor.

You will want to disconnect the 4 bolts holding the stubshafts onto the axle, and drop it that way. Then pull the axles out. The rust will not be on the driveshaft as much as it is on every single nut and bolt under the car

Edit ** I apologize but i'm getting ready to leave work and i just used the first underbody pic i could find.

1> is where you will disconnect your stubs
2> is a general area where your driveshaft bolts will disconnect
3> are the spline nuts that connect the PPF to the diff

Newbsauce is offline   Reply With Quote
