Old 09-16-2015, 04:13 PM   #21
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,196
Total Cats: 2,584
Default

everything comes down to beading
with cars and toys and everything
18psi is offline   Reply With Quote
Old 09-16-2015, 04:14 PM   #22
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 783
Default

Mmmmmm beading.

Attached Thumbnails
Worm drive clamps are better than t-bolt clamps-giphy.gif
concealer404 is offline   Reply With Quote
Old 09-16-2015, 04:34 PM   #23
Junior Member
iTrader: (3)

Join Date: Apr 2011
Location: Bay Area- East Bay
Posts: 290
Total Cats: 1
Default

How about the part where the thread is about worm drive clamps being better. I said, is bogusbogus, from enough experience in my field to not be talking out of my ***.
brainzata is offline   Reply With Quote
Old 09-16-2015, 04:37 PM   #24
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 783
Default

Please show your work.
concealer404 is offline   Reply With Quote
Old 09-16-2015, 04:53 PM   #25
Senior Member

Join Date: Jun 2015
Location: TAMPA, FL
Posts: 644
Total Cats: 27
Default

I've used worm and t-bolt clamps, often alongside one another for the same task. The worm gears fail in various ways that the t-bolts don't. That isn't to say a hose on an unbeaded pipe with tbolts won't come off eventually, but it will take longer and even with proper beads, the tbolts last a lot longer (in terms of years and loosen-tighten cycles).

Yes yes I know anecdotes aren't hard data, but my experience has been more in favor of tbolts. In my opinion it comes down to the worm clamp putting all its load on the grooves of the flat portion and the edge of the threads of the bolt. On a t-bolt, the force is distributed over a much wider area. I've seen worm gears fail at those load points (the grooves on the metal ribbon) on a whole bunch of occasions so data.

If worm gears incorporated a bolt into the tensioning mechanism I'd be much more in favor of them. The problem is that once you design a proper worm gear with a bolt to hold the screws of the worm drive.... you have a t bolt clamp.
AlwaysBroken is offline   Reply With Quote
Old 09-16-2015, 04:55 PM   #26
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 783
Default

Are we talking about effectiveness or ability to withstand multiple cycles?

The article is about one. Not the other.
concealer404 is offline   Reply With Quote
Old 09-16-2015, 04:59 PM   #27
Senior Member
iTrader: (1)

Join Date: Jun 2006
Location: Sweden
Posts: 1,391
Total Cats: 58
Default

IC things should not change temp much, but for things that do, spring clamps are hard to beat (install and keeps clamping in changing temps after 20 years).

Removing at the reroute at the back of the head is a nightmare of course....
NiklasFalk is offline   Reply With Quote
Old 09-16-2015, 05:35 PM   #28
SADFab Destructive Testing Engineer
Thread Starter
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

<p>Once again. Thread title should be changed to &quot;worm drive clamps are better at this one specific thing that I didn't know they were better at and I thought you guys would want to know because i've read different on the forum&quot;</p><p>Mod plz.</p>
aidandj is offline   Reply With Quote
Old 09-16-2015, 05:52 PM   #29
Elite Member
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,797
Total Cats: 248
Default

Quote:
Originally Posted by AlwaysBroken View Post
Does it all come down to proper beading? What is allowing those other cars to run 30-50 psi and not pop hoses off?
Yes the beading is what keeps the hoses together at high pressure. The force of the hose trying to push away from the pipe no longer relies on friction between the two surfaces supplied by the clamp. Now when the hose tries to slide off, the diameter change causes the coupler to stretch, but the clamp resist this, so the pressure/friction shoots up until it stops moving, or until the clamp breaks.
patsmx5 is offline   Reply With Quote
Old 09-16-2015, 05:58 PM   #30
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,196
Total Cats: 2,584
Default

Quote:
Originally Posted by brainzata View Post
How about the part where the thread is about worm drive clamps being better. I said, is bogusbogus, from enough experience in my field to not be talking out of my ***.
LOL

so how about some actual info then?
18psi is offline   Reply With Quote
Old 09-16-2015, 06:02 PM   #31
Junior Member
iTrader: (3)

Join Date: Apr 2011
Location: Bay Area- East Bay
Posts: 290
Total Cats: 1
Default

Well one of our long time customers is Lockheed Martin, over 65 units we service... All you need for proof, is hold one of each in your hand. It's obvious which is superior. There is no benefit of using a worm drive other than budget or confined space maybe. Though the only way you save enough is buying the cheap Chinese clamps from, say ace or home dip ****. I have never broken a t-bolt clamp, not even 30 year old clamps off military equipment. I have lost count of the number of fatigued, broken, won't fully tighten worm drive clamps.
brainzata is offline   Reply With Quote
Old 09-16-2015, 06:08 PM   #32
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,196
Total Cats: 2,584
Default

Quote:
Originally Posted by brainzata View Post
Well one of our long time customers is Lockheed Martin, over 65 units we service... All you need for proof, is hold one of each in your hand. It's obvious which is superior. There is no benefit of using a worm drive other than budget or confined space maybe. Though the only way you save enough is buying the cheap Chinese clamps from, say ace or home dip ****. I have never broken a t-bolt clamp, not even 30 year old clamps off military equipment. I have lost count of the number of fatigued, broken, won't fully tighten worm drive clamps.
chevy should use that argument to sell their 4000lb camaros
LOOK HOW MUCH MORE WEIGHT YOU GET FOR THE MONEY

I mean........c'mon.

The question here is ability to hold down a clamp effectively. People are saying a worm clamp can do it just fine if it's a quality clamp and the tube/coupler are proper, you're saying it's bogus. When called on it, you're saying "well it's lighter, and most use the cheap ones, so........"

I'm not completely disputing your opinion ( I happen to still want to use t-bolts because they're actually cheaper than quality worm clamps) but it's just a prefrence due to being cheap
18psi is offline   Reply With Quote
Old 09-16-2015, 06:10 PM   #33
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,196
Total Cats: 2,584
Default

The point here is - you don't need fifty billion footpounds of clamping force to hold together an intercooler setup. Effective beading, proper couplers, and proper worm clamps work just fine. dozens of seriously high boost and high power applications from reputable companies confirms this.

I used to agree with you, until I was proven wrong, just for the record.
18psi is offline   Reply With Quote
Old 09-16-2015, 06:10 PM   #34
SADFab Destructive Testing Engineer
Thread Starter
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

<p>All that is being said is that they seal better with silicone tubing on aluminum intake tubes.</p>
aidandj is offline   Reply With Quote
Old 09-16-2015, 06:21 PM   #35
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 783
Default

Worm gear clamps disrespected my family.
concealer404 is offline   Reply With Quote
Old 09-16-2015, 06:23 PM   #36
SADFab Destructive Testing Engineer
Thread Starter
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

<p>T-bolt clamps hold on condoms better than worm gear clamps.</p>
aidandj is offline   Reply With Quote
Old 09-16-2015, 06:28 PM   #37
Elite Member
iTrader: (15)

patsmx5's Avatar

Join Date: Aug 2007
Location: Houston, TX
Posts: 8,797
Total Cats: 248
Default

Quote:
Originally Posted by brainzata View Post
Well one of our long time customers is Lockheed Martin, over 65 units we service... All you need for proof, is hold one of each in your hand. It's obvious which is superior. There is no benefit of using a worm drive other than budget or confined space maybe. Though the only way you save enough is buying the cheap Chinese clamps from, say ace or home dip ****. I have never broken a t-bolt clamp, not even 30 year old clamps off military equipment. I have lost count of the number of fatigued, broken, won't fully tighten worm drive clamps.
Agreed with the real world experience of failed work drive clamps. I'm bad about overtightening things, and I've overtightend t-bolts and they don't break, I've stripped several worm clamps from overtightening. Now this is admiting that I ACTUALLY caused the failure, but sitll, the t-bolt was more robust to my overtightening no doubt.

I was shopping for Otikier clamps a while back, and found some company that makes a clamp that's makes a hose clamp with a slick inside sleeve so it doesn't damage the soft hose it's clamping as a traditional worm drive clamp does. Some of the benefit of a T-bolt without any of the downsides I would think.

Still, end of the day I'm still using t-bolts. But I have unbeaded steel pipes. So I am relying on friction only, and I can pinch the crap out of a T-bolt and it won't leak, and won't slip. Once my new IC setup is tested I'm going to remove and bead all my pipes fore reliability though.
patsmx5 is offline   Reply With Quote
Old 09-16-2015, 06:29 PM   #38
Junior Member
iTrader: (3)

Join Date: Apr 2011
Location: Bay Area- East Bay
Posts: 290
Total Cats: 1
Default

It's hard to disagree against someone that makes up things. Where did I say t-bolt clamps were lighter? First off, I know worm drive clamps are lighter weight. Secondly most worm drive clamps are steel, coated with some anti-corrosion Nickle or such. Whereas almost all, at least quality brand t bolt clamps are pure stainless with some brands have in the exception of the nylon lock nut being zinc or something. I was under the impression that the thread was about one clamp being better than the other and the link was more explaining why one clamp is better for silicone hose. The only way that would be true is if you were using smooth inner band worm drive clamps. Most people don't use those they just buy what you can get at the hardware store. I really thought most of you we're all about reliability so that's why I chimed in, but I don't want to get banned so I'll just keep my experience to myself
brainzata is offline   Reply With Quote
Old 09-16-2015, 06:29 PM   #39
Elite Member
iTrader: (3)

concealer404's Avatar

Join Date: Aug 2011
Posts: 8,465
Total Cats: 783
Default

I put T-bolts on my intake on my car.
concealer404 is offline   Reply With Quote
Old 09-16-2015, 06:34 PM   #40
SADFab Destructive Testing Engineer
Thread Starter
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

<p>I put t-bolts on my coolant hoses.</p>
aidandj is offline   Reply With Quote
