Old 12-31-2007, 02:42 AM   #1
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default Ebc Attempting To Run More Boost

Okay Heres The Thing Before Ms I Had A Manual Boost Controller Set At 5psi Now That I Have Ms And Can Fine Tune The Afr I Want To Run About 6.5psi Well The Kpa Targets I Have Set Pretty High Like
Starting At 100 Then To 60 At About 3000 Rpm Well If I Change That It Doesnt Affect The Boost If I Turn Them All Up To 100 I Still Get 5psi???? Do I Need To Tighten The Wastegate Up???? ALSO MY AUTO TUNE MIGHT NOT BE WORKING RIGHT? WHEN I TURN IT ON IT SAYS CONNECTED TO CONTROLLER AND THE GREEN AND RED TARGET THINGS MOVE AROUND THE GRID AND SOMETIMES IT SAYS AUTO CORRECTION-0% IT NEVER GOES TO ANYTHING ELSE EXCEPT TARGET OUT OF RANGE??? DOES THAT MEAN ITS NOT WORKING?? OHH YEA AND ALSO DO I WANT MS TO MAKE O2 CORRECTIONS WHILE IN BOOST? IF SO OR NOT HOW DO I CHANGE TO FIX?
turbobluemiata is offline   Reply With Quote
Old 12-31-2007, 02:53 AM   #2
Elite Member
iTrader: (12)

Join Date: Jan 2007
Location: Hermosa Beach, CA
Posts: 2,575
Total Cats: 11
Default

ok, 100 kpa is atmosphere, 0psi. 6.5 psi would be about 145 KPA. So set it for 145 kpa and see where that takes you. Also, take off your manuel boost controller if its still on there.
cardriverx is offline   Reply With Quote
Old 12-31-2007, 02:57 AM   #3
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

Ohh I Thought I Read Somewhere That 100 Was Full Boost???? My Bad Thanks Alot For The Quick Reply!
turbobluemiata is offline   Reply With Quote
Old 12-31-2007, 04:14 AM   #4
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,356
Total Cats: 1,322
Default

Name:  keyboard4.jpg
Views: 3
Size:  32.9 KB
Savington is online now   Reply With Quote
Old 12-31-2007, 04:22 AM   #5
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

cjernigan is offline   Reply With Quote
Old 01-02-2008, 03:36 PM   #6
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

still no change i changed all my boost control settings as it shows in the other thread and i changed the boost duty target table and still i get 5.5 psi? i put it at 100 til 3000 rpm and then to 40 after that but still nothing when im driving it doesnt even show more than 10% tps????
turbobluemiata is offline   Reply With Quote
Old 01-02-2008, 03:36 PM   #7
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

Did you calibrate your TPS?
cjernigan is offline   Reply With Quote
Old 01-02-2008, 03:42 PM   #8
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

are you changing the kPa targets table or the DC% table?

Last edited by Braineack; 01-02-2008 at 04:03 PM.
Braineack is offline   Reply With Quote
Old 01-02-2008, 04:27 PM   #9
Elite Member
iTrader: (9)

Saml01's Avatar

Join Date: Jul 2007
Location: NYC
Posts: 5,730
Total Cats: 2
Default

Quote:
Originally Posted by cjernigan View Post
Did you calibrate your TPS?
His car is a 91, no linear TPS.
Saml01 is offline   Reply With Quote
Old 01-02-2008, 10:06 PM   #10
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

well at first i was changing the kpa target but then the guy with the eskimo avatar said to use the dc table so i did but it wont go over 5 psi no matter what its set at and the tps side of the chart stays at the bottom??
turbobluemiata is offline   Reply With Quote
Old 01-02-2008, 10:15 PM   #11
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

the solenoid is connected to a 12v source and then back to the MS to the wire I told you (blue/wht I think)?

you hooked it up correctly to the wastegate line? from source into solenoid on the single port side, exit through the side with the filter, into the wastgate.




try these targets;;; turn your overboost protection on to 8psi or something. if you hit a rev limiter when you give it gas it's working.



double check you burned js2 to boost control.
Braineack is offline   Reply With Quote
Old 01-02-2008, 10:20 PM   #12
Elite Member
iTrader: (21)

paul's Avatar

Join Date: Jun 2006
Location: Point Pleasant, NJ
Posts: 2,957
Total Cats: 2
Default

take screen shots of your boost duty settings page.
paul is offline   Reply With Quote
Old 01-02-2008, 10:38 PM   #13
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

ouble check you burned js2 to boost control.???? whats that and my boost control parameters look like that exactly except the ambient pressure on mine is 98? the duty cycle thing looks almost like that with the numbers lower cuz i dont want as much boost but even upping the number it doesnt change neither does the highlighted green cell in the tps side but the rpm and numbers change?
turbobluemiata is offline   Reply With Quote
Old 01-02-2008, 10:39 PM   #14
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

ohh yea and i dont know how to take screenshots!???
turbobluemiata is offline   Reply With Quote
Old 01-02-2008, 10:43 PM   #15
Elite Member
iTrader: (21)

paul's Avatar

Join Date: Jun 2006
Location: Point Pleasant, NJ
Posts: 2,957
Total Cats: 2
Default

your car doesn't have a variable TPS. its off or its on. read this page and the link cited https://www.miataturbo.net/forum/showthread.php?t=11199

it's all i needed to figure out my EBC this weekend
paul is offline   Reply With Quote
Old 01-02-2008, 10:55 PM   #16
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

his car is neither on or off, his MS doesn't see the TPS signal at all.

turboblue, the solenoid is hooked up correctly? JS2 is set for boost control under outputs?
Braineack is offline   Reply With Quote
Old 01-02-2008, 11:37 PM   #17
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

yea its hooked up right the red wire to switched 12v and ground to green/wht it shows in megatune output1/boost is highlighted green what does js2 stand for????
turbobluemiata is offline   Reply With Quote
Old 01-02-2008, 11:44 PM   #18
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

the thread that he said got him goin with ebc it says for 90-93 to make all the tps% to 50%??? should I or leave it where it is
turbobluemiata is offline   Reply With Quote
Old 01-03-2008, 12:07 AM   #19
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,833
Total Cats: 1,786
Default

js2 is the location on the mother board where the input is.

leave the TPS% as I posted.

the only thing I can think is the connection is somehow messed up. which 12v source did you use? how did you install the solenoid.

can you tap the ground wire to the frame and make sure the valve clicks/closes.
Braineack is offline   Reply With Quote
Old 01-03-2008, 12:07 AM   #20
Senior Member
Thread Starter
iTrader: (8)

turbobluemiata's Avatar

Join Date: Aug 2006
Location: Springfield, IL
Posts: 1,019
Total Cats: 0
Default

when i go to megatune "more settings" then "outputs" it says x4/js2 then its off and greyed out??
turbobluemiata is offline   Reply With Quote
