Default Fuel Ve Values Really High

Hey kids im new to this whole turbo/tuning/hope my car doesnt blow up thing, and ive got my little slow mobile running fairly well with VEAL but all my values seem very high, im sure ive over looked something minor and help would be appreciated. Car is a '89 1.6 with a diypnp running an intercooled Greddy turbo kit with a td04h.


mewse is offline   Reply With Quote
Old 02-07-2016, 03:45 AM   #2
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 36,198
Total Cats: 2,584
Default

fix your req fuel
18psi is offline   Reply With Quote
Old 02-07-2016, 03:49 AM   #3
Newb
Thread Starter

Join Date: Dec 2015
Location: Brisbane
Posts: 6
Total Cats: 0
Default

req fuel is 11.7
running stock bluetop injectors
mewse is offline   Reply With Quote
Old 02-07-2016, 04:50 AM   #4
Elite Member

Join Date: Apr 2010
Location: Newcastle, Australia
Posts: 2,640
Total Cats: 25
Default

Quote:
Originally Posted by mewse View Post
req fuel is 11.7
running stock bluetop injectors
Your injectors are far too small. You're adding fuel and they are maxxed so you're adding more.

Hence high ve.
nitrodann is offline   Reply With Quote
Old 02-07-2016, 10:45 AM   #5
Tweaking Enginerd
iTrader: (2)

Join Date: Mar 2013
Location: Boulder, CO
Posts: 480
Total Cats: 37
Default

Quote:
Originally Posted by mewse View Post
req fuel is 11.7
running stock bluetop injectors
As Dann mentioned, at that req fuel the max rpm you can support is ~5200 rpm. Injectors should be sized such that the req fuel is ~8.3msec for a max rpm of 7200.

Edit: and this would be 100% DC ... Bad

You are def in go boom territory

Edit (again): math is wrong up there, but yes bigger injectors

Last edited by Ted75zcar; 02-08-2016 at 12:24 AM. Reason: Bad math
Ted75zcar is offline   Reply With Quote
Old 02-07-2016, 06:22 PM   #6
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

Future of your engine:

Attached Thumbnails
Fuel Ve Values Really High-giphy.gif
aidandj is offline   Reply With Quote
Old 02-07-2016, 06:39 PM   #7
Newb
Thread Starter

Join Date: Dec 2015
Location: Brisbane
Posts: 6
Total Cats: 0
Default

New injectors it is then! Thanks guys <3
mewse is offline   Reply With Quote
Old 02-10-2016, 12:30 AM   #8
Newb
Thread Starter

Join Date: Dec 2015
Location: Brisbane
Posts: 6
Total Cats: 0
Default

Alright so ive obviously done a dumb somewhere, ive upgraded injectors to the 305cc from a 7mge and adjusted the req fuel (which is now 8.8) but the values are still more or less the same idling at 14.7 =/
mewse is offline   Reply With Quote
Old 02-10-2016, 02:33 AM   #9
Sadfab Union President
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 113
Default

If the output pulsewidths are reasonable and your maximum duty cycle is within reason it doesn't really matter.

If you want you can double req fuel and halve all ve values. The only thing that doesn't automatically scale on MS2 is cranking pulsewidth.
deezums is offline   Reply With Quote
Old 02-10-2016, 09:49 AM   #10
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,899
Total Cats: 1,792
Default

Quote:
Originally Posted by Ted75zcar View Post
As Dann mentioned, at that req fuel the max rpm you can support is ~5200 rpm. Injectors should be sized such that the req fuel is ~8.3msec for a max rpm of 7200.

?
Braineack is offline   Reply With Quote
Old 02-10-2016, 10:15 AM   #11
Tweaking Enginerd
iTrader: (2)

Join Date: Mar 2013
Location: Boulder, CO
Posts: 480
Total Cats: 37
Default

Quote:
Originally Posted by Braineack View Post
~sigh~

You will notice I edited admitting a math error (shortly after the original post). But thanks for checking!
Ted75zcar is offline   Reply With Quote
Old 02-11-2016, 03:39 AM   #12
Newb
Thread Starter

Join Date: Dec 2015
Location: Brisbane
Posts: 6
Total Cats: 0
Default

Problem solved! soooo...bad wideband sensor ground anyone? but all seems good now, although ive got a hesitation on light acceleration that sometimes causes the engine to stall.

Last edited by mewse; 02-11-2016 at 04:03 AM.
mewse is offline   Reply With Quote
Old 02-11-2016, 03:59 AM   #13
Sadfab Union President
iTrader: (3)

Join Date: May 2014
Location: Kansas
Posts: 2,690
Total Cats: 113
Default

3.something is probably an OK pulsewidth for idle, though it seems a bit high to me off a wild guess.

The other number you gave me, 21ms at 3100 rpm, That's kinda useless without a map value. 80% duty cycle is 25ms at 3100rpm though, so it's not locked open yet.
deezums is offline   Reply With Quote
