How do YOU tune? - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



MEGAsquirt A place to collectively sort out this megasquirt gizmo

Reply



LinkBack Thread Tools
Old 06-22-2008, 06:40 PM   #1
I'm Miserable!
Thread Starter
iTrader: (5)

bryantaylor's Avatar

Join Date: Dec 2006
Location: jacksonville, fl
Posts: 1,720
Total Cats: 0
Default How do YOU tune?

and i dont want to hear "take it to the tuner"

i have had a friend drive the car before while i was in the pass seat with the laptop and that seems to work decent. but its hard to find someone you trust enough to drive it at the same time that you have time to tune it.

so my question is how is everyone else tunning thier cars? i just upgraded to high res, and just threw in the MSPNP fuel map with my req fuel, and it needs tuned BAD, rich everywhere. just want to hear how others are doing it to get another perspective.
bryantaylor is offline   Reply With Quote
Old 06-22-2008, 06:48 PM   #2
Elite Member
iTrader: (21)

paul's Avatar

Join Date: Jun 2006
Location: Point Pleasant, NJ
Posts: 2,957
Total Cats: 2
Default

you drive & log for 10-15 mins varying the load and rpm combinations to cover the whole fuel map.
run log through VE analyzer in MLV.
accept new msq.

repeat.
paul is offline   Reply With Quote
Old 06-22-2008, 07:01 PM   #3
I'm Miserable!
Thread Starter
iTrader: (5)

bryantaylor's Avatar

Join Date: Dec 2006
Location: jacksonville, fl
Posts: 1,720
Total Cats: 0
Default

i have never used the VE analyzer. looking into it now, thats some cool stuff. much easier that just looking through the logs and trying to tweek the map like i was doing.
bryantaylor is offline   Reply With Quote
Old 06-22-2008, 07:07 PM   #4
Junior Member

Join Date: Dec 2007
Location: San Diego to LA, CA
Posts: 297
Total Cats: 0
Default

MLV is awesome, I always use it
91NApeewee is offline   Reply With Quote
Old 06-22-2008, 08:10 PM   #5
I'm Miserable!
Thread Starter
iTrader: (5)

bryantaylor's Avatar

Join Date: Dec 2006
Location: jacksonville, fl
Posts: 1,720
Total Cats: 0
Default

the only thing i have to say about VE analyzer is

Name:  Borat-VeryNice.jpg
Views: 0
Size:  16.9 KB
bryantaylor is offline   Reply With Quote
Old 06-22-2008, 08:13 PM   #6
Junior Member
iTrader: (2)

Join Date: Dec 2007
Location: Québec, Canada
Posts: 407
Total Cats: -1
Default

When you talk about load, you make reference to what?
Dark Wanderer is offline   Reply With Quote
Old 06-22-2008, 08:29 PM   #7
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

Engine load, 30 kpa is a low load situation 100 kpa is WOT when NA. He means put the engine under varying loads relative to RPM to hit as many cells as possible in the VE table. Then let MLV work it's magic.
cjernigan is offline   Reply With Quote
Old 06-22-2008, 08:33 PM   #8
Elite Member
iTrader: (24)

kotomile's Avatar

Join Date: Oct 2006
Location: Monterey, CA
Posts: 7,578
Total Cats: 40
Default

Quote:
Originally Posted by bryantaylor View Post
How do YOU tune?
a kotomile at a time.
kotomile is offline   Reply With Quote
Old 06-22-2008, 09:00 PM   #9
Elite Member
iTrader: (8)

Join Date: Oct 2007
Location: Dallas
Posts: 1,841
Total Cats: 0
Default

Quote:
Originally Posted by kotomile View Post
a kotomile at a time.
Toddcod is offline   Reply With Quote
Old 06-22-2008, 09:12 PM   #10
Elite Member
iTrader: (8)

Join Date: Oct 2007
Location: Dallas
Posts: 1,841
Total Cats: 0
Default

Quote:
Originally Posted by bryantaylor View Post
i have never used the VE analyzer. looking into it now, thats some cool stuff. much easier that just looking through the logs and trying to tweek the map like i was doing.
I couldn't get my MLV to open. I guess I'm going to have to reinstall it.
I started from an idle touching the pedal and advancing to my brother driving me down the street chasing the green dot on Real time. It took 2 hrs to get a tune so I could drive it to work safely. As soon as you would let out of acceleration it would lean out. I'm lucky to have a Q & W still on the keyboard. LOL
Toddcod is offline   Reply With Quote
Old 06-22-2008, 09:59 PM   #11
Junior Member
iTrader: (7)

Join Date: Aug 2006
Location: Binghamton, NY
Posts: 448
Total Cats: 1
Default

Autotune is much simpler than MLV. You don't have to reload the MSQ all the time just drive the car and it tunes on the fly. Doesn't get any easier.
--Alex
AlexO35 is offline   Reply With Quote
Old 06-22-2008, 10:50 PM   #12
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,809
Total Cats: 1,780
Default

Quote:
Originally Posted by AlexO35 View Post
Autotune is much simpler than MLV. You don't have to reload the MSQ all the time just drive the car and it tunes on the fly. Doesn't get any easier.
--Alex

however it doesnt work nearly as well.


it's easy for me to drive to work and record a log. run it through MLV and flash it at lunch. It's usually good to go after a few sessions, when you get to the point where EGO is almost always 100% I turn MLV to hard, then very hard. I can also tell it to ignore anything under 35 kPa and 1800RPM.

Driving with autotune is a good starting off point to get you in a spot to start using MLV.
Braineack is offline   Reply With Quote
Old 06-22-2008, 11:13 PM   #13
Junior Member
iTrader: (7)

Join Date: Aug 2006
Location: Binghamton, NY
Posts: 448
Total Cats: 1
Default

That's true. I have used MLV to adjust specific parts of a map, and I'll be using it to adjust throttle transitions and off idle conditions. For general tuning (cruise, part and full throttle) though, I like autotune.
--Alex
AlexO35 is offline   Reply With Quote
Old 06-22-2008, 11:20 PM   #14
Elite Member
iTrader: (13)

cjernigan's Avatar

Join Date: Oct 2006
Location: Atlanta, GA
Posts: 8,147
Total Cats: 6
Default

MLV kicks autotunes *** at all tuning end of story. Autotune is incredibly incompetent and slow. MLV gets everything ***** on for me, like Scott said, close enough that EGO hardly has to do anything.

Autotune is far too slow for anything but cruise. Using it for any kind of acceleration is pretty much pointless.
cjernigan is offline   Reply With Quote
Old 06-22-2008, 11:25 PM   #15
Elite Member
iTrader: (15)

Join Date: Dec 2007
Location: San Antonio, Texas
Posts: 4,889
Total Cats: 28
Default

Quote:
Originally Posted by Braineack View Post
however it doesnt work nearly as well.


it's easy for me to drive to work and record a log. run it through MLV and flash it at lunch. It's usually good to go after a few sessions, when you get to the point where EGO is almost always 100% I turn MLV to hard, then very hard.
Ditto. I do the same thing. Log the drive to work, run it through MLV, increase from normal, to hard, to very hard for subesquent tuning logs. Alt-L baby.
ZX-Tex is offline   Reply With Quote
Old 06-23-2008, 09:01 AM   #16
Elite Member
iTrader: (21)

paul's Avatar

Join Date: Jun 2006
Location: Point Pleasant, NJ
Posts: 2,957
Total Cats: 2
Default

Quote:
Originally Posted by Braineack View Post
I can also tell it to ignore anything under 35 kPa and 1800RPM.

good tip. i forgot to mention that. I like to set my idle manually and don't let VEA modify after.

as someone said above, ALT-L Enter to start a log, then just ALT-L Esc to end it.
paul is offline   Reply With Quote
Old 06-23-2008, 10:08 AM   #17
Elite Member
iTrader: (30)

Join Date: Aug 2007
Location: Va Beach
Posts: 7,282
Total Cats: 0
Default

Quote:
Originally Posted by Braineack View Post
however it doesnt work nearly as well.


it's easy for me to drive to work and record a log. run it through MLV and flash it at lunch. It's usually good to go after a few sessions, when you get to the point where EGO is almost always 100% I turn MLV to hard, then very hard. I can also tell it to ignore anything under 35 kPa and 1800RPM.

Driving with autotune is a good starting off point to get you in a spot to start using MLV.
How do you do that?

I do the same thing all these guys said and it works great. Its easy to figure out and work with.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
levnubhin is offline   Reply With Quote
Old 06-23-2008, 10:33 AM   #18
Elite Member
iTrader: (9)

Saml01's Avatar

Join Date: Jul 2007
Location: NYC
Posts: 5,730
Total Cats: 2
Default

^ press on advanced settings in the VE analyzer and you can set bounds.
Saml01 is offline   Reply With Quote
Old 06-23-2008, 11:51 AM   #19
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

ve analyzer is your daddy. I prefer using that interface to tune tables.
hustler is offline   Reply With Quote
Old 06-23-2008, 11:55 AM   #20
Elite Member
iTrader: (24)

kotomile's Avatar

Join Date: Oct 2006
Location: Monterey, CA
Posts: 7,578
Total Cats: 40
Default

Quote:
Originally Posted by paul View Post
ALT-L Esc to end it.
d'oh, I'd been using ALT-F, L, O to end them..
kotomile is offline   Reply With Quote
