Old 06-02-2012, 03:13 AM   #81
Oni
Junior Member
iTrader: (1)

Join Date: Jan 2009
Location: Tasmania, AUS
Posts: 164
Total Cats: 3
Default

I think im going to do this Brains way. Out of interest what are your EGO settings Brain?

Cheers
Scott
Oni is offline   Reply With Quote
Old 06-02-2012, 11:04 AM   #82
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

here:
.
Attached Thumbnails
MAT Correction-ego.jpg
Braineack is offline   Reply With Quote
Old 06-02-2012, 11:55 AM   #83
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

I still wonder why

1) You are using the "simple" algorithm
2) You are not enabling it below 1500rpm
Reverant is offline   Reply With Quote
Old 06-02-2012, 12:04 PM   #84
Elite Member
iTrader: (11)

Join Date: Feb 2009
Posts: 2,982
Total Cats: 10
Default

Quote:
Originally Posted by Reverant View Post
I still wonder why

1) You are using the "simple" algorithm
2) You are not enabling it below 1500rpm
What RPM are you activating yours?

My PID is 20,20,10 respectively
miatauser884 is offline   Reply With Quote
Old 06-02-2012, 12:05 PM   #85
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

600rpm
Reverant is offline   Reply With Quote
Old 06-02-2012, 12:37 PM   #86
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

I always been against EGO at idle. It's never worked well for me, and tuning it to work at idle caused it to be horrible off idle.

When I enable EGO at idle the AFRs fight everything else that's going on and caused oscillation. With all the idle improvements: ve idle table, timing corrections, voltage corrections, PID code, there's no point for EGO at idle, my AFRs are on point and smooth and constant and my idle is better than it's ever been.

I had tuned the EGO PID at one point and fucked around with it one day and forgot to redo it, simple actually works fairly well.

I still wonder HOW you are using EGO at idle, you're probably the only person running MS that does it.
Braineack is offline   Reply With Quote
Old 06-02-2012, 12:44 PM   #87
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Simple causes oscillations. PID does not.
Reverant is offline   Reply With Quote
Old 06-02-2012, 01:01 PM   #88
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

yeah but when i tuned PID for idle, and it was great (before idle ve table)....it sucked in all other RPM ranges. I'm not the only one who's complained about this.

that's why im back on simple, as i fucked up my pid settings trying to get it to work at idle, and then i never tuned it back.
Braineack is offline   Reply With Quote
Old 06-02-2012, 01:29 PM   #89
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Is this on the MS3? I have no complaints on the MS2...so do my customers.
Reverant is offline   Reply With Quote
Old 06-02-2012, 01:50 PM   #90
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

yeah. but whatever, i don't need it at idle. my afrs are flat, as well as my idle speed, it's pretty delicious.
Braineack is offline   Reply With Quote
Old 06-02-2012, 06:23 PM   #91
Junior Member
iTrader: (1)

Join Date: Jun 2011
Location: Australia
Posts: 178
Total Cats: 3
Default

Quote:
Originally Posted by Reverant View Post
Simple causes oscillations. PID does not.
Arguably, PID can produce oscillations too if not correctly tuned.

G
gslender is offline   Reply With Quote
Old 06-02-2012, 07:52 PM   #92
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

I personally think that the EGO pid is by far the easiest to tune.
Reverant is offline   Reply With Quote
Old 06-10-2012, 05:46 AM   #93
Junior Member
iTrader: (1)

Join Date: Jun 2011
Location: Australia
Posts: 178
Total Cats: 3
Default

Okay - so I've got a new MOD (v2.7) finished and in testing that has AirCorrection calcs and scaling in 10ths plus it allows for RPM based linear scaling so that you can have a table that allows for 50% at idle, 100% above 1000 rpm and then taper down from 4000rpm down to 0% at 5000rpm onwards... so plenty of options for whatever you need to ensure the MAT Correction does what you want. I should be looking to release this soon - anyone want to test the code? (it is based on a beta 3.3 of ms2/extra version 2.6 of my mod which many have tried and are getting great results) http://www.msextra.com/forums/viewto...p?f=91&t=44946
gslender is offline   Reply With Quote
Old 06-10-2012, 12:56 PM   #94
Elite Member
iTrader: (11)

Join Date: Feb 2009
Posts: 2,982
Total Cats: 10
Default

Quote:
Originally Posted by Reverant View Post
I personally think that the EGO pid is by far the easiest to tune.
So what's your method for tuning PID idle? It was one of the first things I messed with, and it seems to do alright.
miatauser884 is offline   Reply With Quote
Old 06-10-2012, 01:36 PM   #95
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,860
Total Cats: 1,788
Default

Quote:
Originally Posted by Reverant View Post
I personally think that the EGO pid is by far the easiest to tune.
i agree. im just lazy.
Braineack is offline   Reply With Quote
Old 06-10-2012, 01:36 PM   #96
Senior Member
iTrader: (8)

Join Date: Jun 2010
Location: Navarre, FL
Posts: 1,127
Total Cats: 39
Default

Quote:
Originally Posted by gslender View Post
Okay - so I've got a new MOD (v2.7) finished and in testing that has AirCorrection calcs and scaling in 10ths plus it allows for RPM based linear scaling so that you can have a table that allows for 50% at idle, 100% above 1000 rpm and then taper down from 4000rpm down to 0% at 5000rpm onwards... so plenty of options for whatever you need to ensure the MAT Correction does what you want. I should be looking to release this soon - anyone want to test the code? (it is based on a beta 3.3 of ms2/extra version 2.6 of my mod which many have tried and are getting great results) http://www.msextra.com/forums/viewto...p?f=91&t=44946
great! thanks for all the work. Again, wish I had a running car.
aaronc7 is offline   Reply With Quote
Old 06-12-2012, 01:20 AM   #97
Junior Member
iTrader: (1)

Join Date: Jun 2011
Location: Australia
Posts: 178
Total Cats: 3
Default

Quote:
Originally Posted by gslender View Post
Okay - so I've got a new MOD (v2.7) finished and in testing that has AirCorrection calcs and scaling in 10ths plus it allows for RPM based linear scaling so that you can have a table that allows for 50% at idle, 100% above 1000 rpm and then taper down from 4000rpm down to 0% at 5000rpm onwards... so plenty of options for whatever you need to ensure the MAT Correction does what you want. I should be looking to release this soon - anyone want to test the code? (it is based on a beta 3.3 of ms2/extra version 2.6 of my mod which many have tried and are getting great results) http://www.msextra.com/forums/viewto...p?f=91&t=44946
No takers?
gslender is offline   Reply With Quote
Old 06-12-2012, 12:56 PM   #98
Junior Member
Thread Starter

Join Date: Apr 2010
Posts: 107
Total Cats: 0
Default

Quote:
Originally Posted by gslender View Post
No takers?
I'd offer to try it out, but it'll probably be a while before I really have a chance to play with it.
bearda is offline   Reply With Quote
Old 06-16-2012, 04:20 PM   #99
Moderator
iTrader: (11)

sixshooter's Avatar

Join Date: Nov 2008
Location: Tampa, Florida
Posts: 15,669
Total Cats: 1,560
Default

Quote:
Originally Posted by Braineack View Post
unsure, can you confirm the leaness is actually the gammae going below 100%?
I confirmed it today. Gammae is going around 85-90% when cruising around in hot weather.
sixshooter is online now   Reply With Quote
Old 06-16-2012, 05:57 PM   #100
Junior Member
iTrader: (1)

Join Date: Jun 2011
Location: Australia
Posts: 178
Total Cats: 3
Default

Quote:
Originally Posted by sixshooter View Post
I confirmed it today. Gammae is going around 85-90% when cruising around in hot weather.
.... and MAT should show the same corresponding movement. Did you grab a log of that?

Is this on MS2 or MS3?

G
gslender is offline   Reply With Quote
