Default What is newest MS version out? What is next release date?

I'm looking at buying MS for a turbo build and have heard a newer version will be released; however I'm not sure if it is already available?

Does anyone have a link to info on this? What are the main upgrades/releases over the current version?

Thanks!
gnx7 is offline   Reply With Quote
Old 05-05-2010, 05:18 AM   #2
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,107
Total Cats: 518
Default

Well there are three different MS's, MSI, MSII, and MSIII, which each have very different prices and features, but the versions refer to the development stage of each. What are you asking about? Models or versions?

If its versions, just get the latest. If its models, you're probably fine with MSI, however if you can afford MSII get it, it has better resolution and a few other handy features. MSIII as far as I know isn't terribly useful for us, with lots of 4+ injector drives, SD card datalogging, and more input/outputs thingys. Read about them on diyautotune.com.
curly is offline   Reply With Quote
Old 05-05-2010, 06:29 AM   #3
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Right now, you can't buy the MS3; that leaves you with two options, MS2 and MS1. If you can afford the extra ~$60, get the MS2. If not, get the MS1. Note that if you have an NB, you need the MS2.

Dimitris
Reverant is offline   Reply With Quote
Old 05-05-2010, 09:21 AM   #4
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default



oh hai der!
Braineack is offline   Reply With Quote
Old 05-05-2010, 09:31 AM   #5
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

So, you want me to post my MS1, right next to my MS2, right next to my MS3, right next to my GPIO?

Dimitris
Reverant is offline   Reply With Quote
Old 05-05-2010, 09:33 AM   #6
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

I could do that as well minus the GPIO...

But my picture would be (5) MS-Is, (3) MS-IIs, (2) Microsquirts, and the MS-III. Do I win?
Braineack is offline   Reply With Quote
Old 05-05-2010, 09:34 AM   #7
Elite Member
iTrader: (1)

Join Date: Jun 2006
Location: Warrington/Birmingham
Posts: 2,658
Total Cats: 39
Default

You should install that before you break it again :P
richyvrlimited is offline   Reply With Quote
Old 05-05-2010, 09:35 AM   #8
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

Sounds like a plan.
Braineack is offline   Reply With Quote
Old 05-05-2010, 09:37 AM   #9
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Nope. I have plenty more to add. Currently:

1 MS-1, 2 MS-IIs, 3 DIY-PNPs, 2 Microsquirts, the MS-3, the GPIO, and several Innovate boards (1 DL-32, 1 TC-4, 1 SSI-4, 1 LM-1 in a better case with circular mil-spec connectors) and other custom ****.

A draw at best.

Dimitris
Reverant is offline   Reply With Quote
Old 05-05-2010, 10:20 AM   #10
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

Name:  ban_hammer.jpg
Views: 1
Size:  44.1 KB
I win for sure.
Braineack is offline   Reply With Quote
Old 05-05-2010, 11:35 AM   #11
Senior Member
iTrader: (14)

Join Date: Aug 2008
Location: Tinley Park, IL
Posts: 1,488
Total Cats: 0
Default

Quote:
Originally Posted by Braineack View Post


oh hai der!
Does this mean someone is going sequential?
lordrigamus is offline   Reply With Quote
Old 05-05-2010, 12:07 PM   #12
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

when the MSX board is available i'll go full sequential.
Braineack is offline   Reply With Quote
Old 05-05-2010, 12:17 PM   #13
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,775
Total Cats: 1,106
Default

Quote:
Originally Posted by Braineack View Post
when the MSX board is available i'll go full sequential.
But only after I do it. But this all still comes down to us figuring out why we randomly run on 2 cylinders.
shuiend is offline   Reply With Quote
Old 05-05-2010, 12:17 PM   #14
Junior Member

Join Date: May 2007
Location: Columbia, MD
Posts: 248
Total Cats: 0
Default

I think a lot of people underestimate the benefits of sequential injection.

It usually won't help power that much, but it can/does help drivability a lot, and often, once you get the injection timing correct it makes fuel and accel enrichment easier to tune.

Also, the MS3 is 2x/4x as fast as the ms2 (50MHz with a 100MHz co-processor that we use to drive all the ignition and injection outputs). Several people have noticed differences in smoothness and drivability even without sequential in areas of the code we didn't change (which leaves only compiler changes and the faster processor to "blame" for the improvements).

Ken
muythaibxr is offline   Reply With Quote
Old 05-05-2010, 12:18 PM   #15
Junior Member

Join Date: May 2007
Location: Columbia, MD
Posts: 248
Total Cats: 0
Default

Quote:
Originally Posted by shuiend View Post
But only after I do it. But this all still comes down to us figuring out why we randomly run on 2 cylinders.
We'll figure that one out. I don't think it's firmware but one way or the other I'm sure we'll get to the bottom of it.

Ken
muythaibxr is offline   Reply With Quote
Old 05-05-2010, 12:33 PM   #16
Supporting Vendor
iTrader: (10)

Reverant's Avatar

Join Date: Jun 2006
Location: Athens, Greece
Posts: 5,440
Total Cats: 198
Default

Quote:
Originally Posted by Braineack View Post
I win for sure.
Every time one of your kitties purr for your victories, I die a little.



Dimitris
Reverant is offline   Reply With Quote
Old 05-05-2010, 01:17 PM   #17
Elite Member
iTrader: (1)

Join Date: Jun 2006
Location: Warrington/Birmingham
Posts: 2,658
Total Cats: 39
Default

Quote:
Originally Posted by muythaibxr View Post
I think a lot of people underestimate the benefits of sequential injection.

It usually won't help power that much, but it can/does help drivability a lot, and often, once you get the injection timing correct it makes fuel and accel enrichment easier to tune.

Also, the MS3 is 2x/4x as fast as the ms2 (50MHz with a 100MHz co-processor that we use to drive all the ignition and injection outputs). Several people have noticed differences in smoothness and drivability even without sequential in areas of the code we didn't change (which leaves only compiler changes and the faster processor to "blame" for the improvements).

Ken
Maybe becuase the Megamanual http://www.megamanual.com/MSFAQ.htm#sequential implies that its 'not all that'

I do prefer my car now it's running sequential injection, small opening times makes for a sucky idle.
richyvrlimited is offline   Reply With Quote
Old 05-05-2010, 03:57 PM   #18
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,775
Total Cats: 1,106
Default

Quote:
Originally Posted by muythaibxr View Post
We'll figure that one out. I don't think it's firmware but one way or the other I'm sure we'll get to the bottom of it.

Ken
Hopefully I will get all new grounds ran this weekend. Then see if I still have the problems. Other then that and idle settings being off, the car has been running good with MS3.
shuiend is offline   Reply With Quote
Old 05-05-2010, 04:02 PM   #19
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,865
Total Cats: 1,790
Default

i don't think the 2-cyl issue has anything to do with grounds. Mine never did this until I went from MS-III back to MS-II, I have a feeling it's how the cpu is sitting in the socket...but it's completely retarded and not cool.
Braineack is offline   Reply With Quote
Old 05-05-2010, 04:36 PM   #20
!!! NOT CONFIRMED !!!
iTrader: (1)

Join Date: Oct 2008
Location: Cleveland Ohio
Posts: 67
Total Cats: 0
Default

Whats the word on controlling VVT with MS3? Whats new to the MS3 that allows this possibility? I will soon need to decide between ms2, and ms3.
mrtbon is offline   Reply With Quote
