Default FM Cast elbow / turbo outlet

This is the current FM design with the divorced wastegate divider, but an early production unit and only fits properly with 2.5" exhaust. It has about 6k miles on it. This unit is ceramic coated.

My 3" exhaust needs the updated part to fit correctly, so I have no further need for this. It's still on the car and may be a week before I can remove it, so keep that in mind.

Would consider trades for MS3 stuff or possibly a solder station with hot air.

$160 + shipping + pp fees to the lower 48.

See below for link to companion downpipe.





Last edited by soloracer; 12-31-2011 at 01:58 PM. Reason: Added pics
soloracer is offline
Old 12-22-2011, 12:52 AM   #2
Newb
iTrader: (1)

Join Date: Jul 2008
Location: greensboro, nc
Posts: 44
Total Cats: 0
Default

damn i want this bad, are you lookin to trade for a 3in magnaflow muffler? hmmm
xander071584 is offline
Old 12-22-2011, 10:05 AM   #3
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

Nope. I have a full 3" FM exhaust from the downpipe - back. Dehd sexeh.
soloracer is offline
Old 12-22-2011, 03:34 PM   #4
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

There's a hybrid downpipe listed here that this should work with if anybody needs to piece together a whole setup.

https://www.miataturbo.net/miata-parts-sale-trade-5/flyin-miata-1-6-hybrid-downpipe-61841/

Last edited by soloracer; 12-22-2011 at 04:17 PM.
soloracer is offline
Old 12-22-2011, 03:43 PM   #5
Newb

Join Date: Apr 2010
Posts: 10
Total Cats: -3
Default

how much shipped to 20906
dc5_champ88 is offline
Old 12-22-2011, 03:59 PM   #6
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

UPS says shipping is $14.21, so $179.30 total.
soloracer is offline
Old 12-23-2011, 12:22 AM   #7
Newb
iTrader: (1)

Join Date: Jul 2008
Location: greensboro, nc
Posts: 44
Total Cats: 0
Default



Uploaded with ImageShack.us

maybe it'll still be here in a week or so when i get paid lol glws!
Attached Thumbnails
FM Cast elbow / turbo outlet-ae92767cf9764ab7ad64def.jpg
xander071584 is offline
Old 12-27-2011, 11:03 AM   #8
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default Bump!

Send me your Xmas monies!!
soloracer is offline
Old 12-28-2011, 08:59 AM   #9
Elite Member
iTrader: (12)

Join Date: Sep 2007
Location: Charlotte, NC
Posts: 6,868
Total Cats: 66
Default

You might want to mention if it's the older open bellmouth design or the one with the divorced wg path. The later ones has a divider wall that impedes into the turbine side to seperate wg gases and may not be compatable with all t25/28 hotside housings.
Doppelgänger is offline
Old 12-28-2011, 10:26 AM   #10
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

Thanks man, changed it. It IS the current design.

I got this from FRT_Fun and he ran it with no issues. Actually it's on my car now with a 3" exhaust with no big problems. The casting seems to lack a little adjustability over the later ones. Everything lines up fine with a 2.5" exhaust, but with the 3" it sits a little too far to one side to allow use of the FM exhaust brace. Since I just wanted to use the brace and wanted everything to line up nice and straight, I bought a new elbow and have this to sell.
soloracer is offline
Old 12-29-2011, 09:17 AM   #11
Elite Member
iTrader: (12)

Join Date: Sep 2007
Location: Charlotte, NC
Posts: 6,868
Total Cats: 66
Default

So what you're saying is that it's the divided design with the protruding divider wall?
Doppelgänger is offline
Old 12-30-2011, 07:39 PM   #12
Destroyer of Inconel
iTrader: (37)

EO2K's Avatar

Join Date: Apr 2010
Location: In ur driveway, abusin' ur WPA
Posts: 9,642
Total Cats: 954
Default

Pics of the mouth on that thing off the turbo would also be awesome...

If I'm reading the FM site correctly, this should work with a GT2554R or GT2560R in any 1.6 or 1.8 NA or NB series car, and provided you are using a FM manifold FM DP, yes?

This gives me naughty thoughts
EO2K is offline
Old 12-30-2011, 09:07 PM   #13
mca
Junior Member
iTrader: (5)

Join Date: Mar 2010
Location: Huntington Beach, CA
Posts: 153
Total Cats: 1
Default

Quote:
Originally Posted by EO2K View Post
Pics of the mouth on that thing off the turbo would also be awesome...

If I'm reading the FM site correctly, this should work with a GT2554R or GT2560R in any 1.6 or 1.8 NA or NB series car, and provided you are using a FM manifold FM DP, yes?

This gives me naughty thoughts
You are correct. I had an identical turbo outlet mated to a GT2554R on a 1.6 NA. And yes, it requires the FM downpipe.

I have a FM 1.6 hybrid downpipe for sale that mates with this turbo outlet (I sold my turbo outlet separately). The hybrid downpipe allows the use of the larger inlet 1.8 catalytic converter.
https://www.miataturbo.net/showthread.php?t=61841
mca is offline
Old 12-31-2011, 01:57 PM   #14
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

Pics added. Note that these are of my new unit as the one for sale is STILL on the car.....they are the same design though.

Also added some more info to the original ad. I forgot to note that this piece is ceramic coated and therefore would be more expensive new.
soloracer is offline
Old 12-31-2011, 08:16 PM   #15
Senior Member
Thread Starter
iTrader: (10)

Join Date: Apr 2007
Location: Ohio
Posts: 800
Total Cats: 3
Default

Sale pending.
