Has anyone done this before? (seat rails inside) - Page 2 - Miata Turbo Forum - Boost cars, acquire cats.

Welcome to Miataturbo.net   Members



Race Prep Miata race-only chat.
Sponsored by:
Sponsored by:

Reply



LinkBack Thread Tools Search this Thread
Old 12-01-2011, 05:24 PM   #21
Cpt. Slow
Thread Starter
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,105
Total Cats: 518
Default

Yes, it's easier, but making side mount brackets at home is much harder than bottom mount.

Keeping two square bolt patterns inline, both side/side for tranny/door clearance, and front/back for foot/beer belly clearance was difficult enough. Trying to keep track of all that plus back/forth tilt and having one of the bolt patterns in another plane doesn't sound fun.
curly is offline   Reply With Quote
Old 12-01-2011, 05:26 PM   #22
Elite Member
iTrader: (5)

Join Date: Dec 2010
Location: Raleigh, NC
Posts: 1,970
Total Cats: 49
Default

depending on the width of the seat and the size of the "feet" on the side mount, you will not be able to line up the side mount on the steel strips and the 2 humps in the floor.

Ultimately you probably could, but on the driver's side I wasn't able to get the last bit to fit. 2" was too wide and impacted on the transmission tunnel, but 1.75" wasn't wide enough to get the bolt holes to line up on the stock mounts. so therefor, I just cut the rear humps and then made a 6"x4" plate backing plate and bolted it to the floor.
Seefo is offline   Reply With Quote
Old 12-01-2011, 05:44 PM   #23
Senior Member

Join Date: Dec 2010
Location: Auckland, NZ
Posts: 782
Total Cats: 23
Default

I was more thinking the commercial side brackets you can buy to match the seats. I thought they had a lot of room on the bottom part of the "L" shape to match whatever spacing you owuld need but sounds like I am wrong.

As far as the tilt, that is taken care of by the commercial brackets having multiple postioning holes pre drilled.......isn't it?
mx5-kiwi is offline   Reply With Quote
Old 12-01-2011, 05:49 PM   #24
Elite Member
iTrader: (5)

Join Date: Dec 2010
Location: Raleigh, NC
Posts: 1,970
Total Cats: 49
Default

Quote:
Originally Posted by mx5-kiwi View Post
I was more thinking the commercial side brackets you can buy to match the seats. I thought they had a lot of room on the bottom part of the "L" shape to match whatever spacing you owuld need but sounds like I am wrong.

As far as the tilt, that is taken care of by the commercial brackets having multiple postioning holes pre drilled.......isn't it?
Well, like I said, some may work and some may not work. I was able to get my passenger's side to work fine, but the driver's side a lot more difficult thanks to our tapering transmission tunnel bullshit. You will just have to try it out and see.

The tilting can be taken care of. if you have multiple holes then yes it will be taken care of. If you don't you can always add some. Also, if you cut the rear humps, you will have some angle naturally added in.
Seefo is offline   Reply With Quote
Old 12-01-2011, 07:23 PM   #25
Senior Member
iTrader: (4)

Join Date: Aug 2010
Location: Farmington Hills, MI
Posts: 510
Total Cats: 15
Default

Quote:
Originally Posted by Track View Post
The tilting can be taken care of. if you have multiple holes then yes it will be taken care of. If you don't you can always add some. Also, if you cut the rear humps, you will have some angle naturally added in.
Even with the stock humps left in there is a little bit of angle.

I have side mounts installed using strap steel/aftermarket side plates. It's difficult to get to the trans tunnel bolts after the seat is in so I install it assembled. Only difficult part was beating in the trans tunnel/door panel to get the seat to fit straight.
njn63 is offline   Reply With Quote
Old 12-01-2011, 09:21 PM   #26
Cpt. Slow
Thread Starter
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,105
Total Cats: 518
Default

Quote:
Originally Posted by mx5-kiwi View Post
I was more thinking the commercial side brackets you can buy to match the seats. I thought they had a lot of room on the bottom part of the "L" shape to match whatever spacing you owuld need but sounds like I am wrong.

As far as the tilt, that is taken care of by the commercial brackets having multiple postioning holes pre drilled.......isn't it?
Ah, yes, premade brackets. Thought you might be making them yourself, which sounds like no fun.

Whatever you do, I'd suggest buying something like the MOMO Start (newer version) which has both side and bottom mounts, so you have a variety of options.

Quote:
Originally Posted by Track View Post
Well, like I said, some may work and some may not work. I was able to get my passenger's side to work fine, but the driver's side a lot more difficult thanks to our tapering transmission tunnel bullshit. You will just have to try it out and see.
Solution:
Attached Thumbnails
Has anyone done this before? (seat rails inside)-480-thorhammer.jpg
curly is offline   Reply With Quote
Old 12-01-2011, 09:30 PM   #27
Elite Member
iTrader: (5)

Join Date: Dec 2010
Location: Raleigh, NC
Posts: 1,970
Total Cats: 49
Default

I hammered it plenty, but I Guess not enough. waht size hammer did you use? and did you hammer at the front mount or what?
Seefo is offline   Reply With Quote
Old 12-01-2011, 09:41 PM   #28
Cpt. Slow
Thread Starter
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,105
Total Cats: 518
Default

I didn't have to, with a first gen MOMO Start, although it's slightly off center, making it a little painful on my arthritic knees.
curly is offline   Reply With Quote
Old 12-06-2011, 05:03 PM   #29
Supporting Vendor
iTrader: (3)

Join Date: Jul 2006
Location: San Diego
Posts: 2,863
Total Cats: 485
Default

The slightly off-center part is what I can't stand, and with bad knees I'd put up with it even less. No way round that but to do it proper. It's either a lot of work or costs a bit to have someone do it, but it is 100% worth it. My Sparco Circuit is an incredibly narrow bottomed seat, and still, with the butt 1/2" off the tub, to center it the trans tunnel needed alteration.
I'm a die-hard DIYer and on a tight budget, but that was one thing I was happy to pay to have done. I don't think you'd regret it.
ThePass is offline   Reply With Quote
