Old 01-04-2016, 03:10 PM   #41
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,881
Total Cats: 45
Default

Quote:
Originally Posted by asmasm View Post
If you want a 16 cell there is a guy on ebay selling batteries in the same configuration as the ballistic evo 2 16. People are RC forums say the cells are legit and that the quality is good:

A123 16 Cell 4S4P 13 2V9 2AH motorbike Battery Starter with Black Case | eBay

Ballistic has the evo 3 line now, it would be good to find out what is inside the cases.
I can't say anything knowledgeable about those Ebay batteries.

I'm 99% sure that the EVO3 Ballistics are internally the same as the EVO2s. They just redesigned the cases, use different terminals, and have a bunch of new case configuration options.
vehicular is offline   Reply With Quote
Old 01-04-2016, 03:14 PM   #42
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

Possibly. Based on the look of the cases I was thinking they might have gone down to using the smaller a123 18650 cells. If you email ballistic and ask what is inside (or any other battery manufacturer) they will tell you it is a custom battery chemistry. So far, every example of an opened battery I have seen says otherwise (including ballistic).

I have also noticed battery manufacturers using terms like 12 cell or 16 cell when it doesn't accurately reflect the number of cells in the box.
asmasm is offline   Reply With Quote
Old 01-04-2016, 03:54 PM   #43
Boosting since 1984
iTrader: (1)

stefanst's Avatar

Join Date: Sep 2011
Location: Levittown
Posts: 1,198
Total Cats: 68
Default

I recently bought an "Alien Motion" LiFePO4 battery. Just hooked it up with alligator clips and it started and ran the Miata just fine. Don't have any long-term data yet, since it's not installed. Planning on putting in where the passenger airbag currently resides.

Alien Motion Lithium Battery - LiFePo4 Lightweight Power Sports Battery
stefanst is offline   Reply With Quote
Old 01-04-2016, 03:59 PM   #44
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

I put a 12 cell alien motion in my car and so far it is working well.
asmasm is offline   Reply With Quote
Old 01-04-2016, 04:08 PM   #45
Boost Pope
Thread Starter
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Quote:
Originally Posted by asmasm View Post
I have also noticed battery manufacturers using terms like 12 cell or 16 cell when it doesn't accurately reflect the number of cells in the box.
I'm curious to know what you've found here.

Assuming a nominal voltage of 3.3v, we can assume that any auto battery is going to be a 4S configuration of LiFePO4 cells. So I would think that 3P (12 cell) and 4P (16 cell) configurations would be commonplace. Are you seeing manufacturers use higher degrees of parallelism with lower-rated cells?
Joe Perez is offline   Reply With Quote
Old 01-04-2016, 04:14 PM   #46
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

I get that is what they are referencing but it seems like some manufactures also use it as a convention to try and make a product hierarchy. For example, that alien motion AM16 is not a 4s4p configuration of the same cells in their AM12 - the specs don't work out to a total that would make sense if it was a 4s4p of those cells. Looking at the battery box, it looks like prismatic pouches and the 16 designation is just an attempt to differentiate it above the 12 cell.
asmasm is offline   Reply With Quote
Old 01-04-2016, 04:22 PM   #47
Boosting since 1984
iTrader: (1)

stefanst's Avatar

Join Date: Sep 2011
Location: Levittown
Posts: 1,198
Total Cats: 68
Default

Quote:
Originally Posted by asmasm View Post
I get that is what they are referencing but it seems like some manufactures also use it as a convention to try and make a product hierarchy. For example, that alien motion AM16 is not a 4s4p configuration of the same cells in their AM12 - the specs don't work out to a total that would make sense if it was a 4s4p of those cells. Looking at the battery box, it looks like prismatic pouches and the 16 designation is just an attempt to differentiate it above the 12 cell.
Correct. Mine has 4 prismatic cells in the box.
stefanst is offline   Reply With Quote
Old 01-04-2016, 04:28 PM   #48
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

It seems like the battery vendors really don't want people to know what is in the battery box. This braille battery that has been posted in the past, it is advertised at 7 amp hours, they went so far as to shrinkwrap the cells with their branding.

http://i.imgur.com/9BecH5f.jpg

Unless they managed to invent a new battery chemisty and create created a cell with the same external dimensions, and the same case coloring, as an a123 26650-a, but at 3.5 amp hour instead of 2.3, they are lying about the capacity.

Most of the other battery manufacturers are smart enough to call it PB/EQ amp hours if they want to make up numbers.
asmasm is offline   Reply With Quote
Old 01-04-2016, 04:33 PM   #49
Boost Pope
Thread Starter
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Quote:
Originally Posted by asmasm View Post
I get that is what they are referencing but it seems like some manufactures also use it as a convention to try and make a product hierarchy. For example, that alien motion AM16 is not a 4s4p configuration of the same cells in their AM12 - the specs don't work out to a total that would make sense if it was a 4s4p of those cells. Looking at the battery box, it looks like prismatic pouches and the 16 designation is just an attempt to differentiate it above the 12 cell.
I'm sure you're right about the cells used in the smaller batteries being of a different construction. The molding of the case would suggest that they're cylindrical.

I hadn't noticed the AM22, but that one does seem to break the math. All of the others are an even multiple of 4, but 22 isn't; the next step after the AM16 should be AM20. And yet they very clearly claim it contains 22 cells.

That's rather curious...



Quote:
Originally Posted by stefanst View Post
Correct. Mine has 4 prismatic cells in the box.
4 cells, or 4 groups of 4 cells?
Joe Perez is offline   Reply With Quote
Old 01-04-2016, 04:40 PM   #50
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

The two off the shelf pouches a123 advertises are 14 and 20 amp hour and 3.3v. They are definitely using something different since they are lower capacity but I think its just 4 pouches in series.
asmasm is offline   Reply With Quote
Old 01-04-2016, 04:50 PM   #51
Boost Pope
Thread Starter
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Attached Thumbnails
Lightweight battery snobs...-shenanigans-south-park.jpg
Joe Perez is offline   Reply With Quote
Old 01-04-2016, 04:55 PM   #52
Boosting since 1984
iTrader: (1)

stefanst's Avatar

Join Date: Sep 2011
Location: Levittown
Posts: 1,198
Total Cats: 68
Default

Quote:
Originally Posted by Joe Perez View Post
4 cells, or 4 groups of 4 cells?
4 of the 'pouches' if memory serves right. And any number different from a multiple of 4 would have raised a flag with me, so I'm pretty sure it's 4.
No markings on the pouches either, so I couldn't confirm capacity without running a controlled discharge/charge cycle.
stefanst is offline   Reply With Quote
Old 01-04-2016, 07:05 PM   #53
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

How were they packed? that has been my concern with the pouches.. They have less dimensional stability than cylindrical cells.
asmasm is offline   Reply With Quote
Old 01-04-2016, 07:09 PM   #54
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

Damn you guys and your $250 batteries.

Any experience with my $25 option?
aidandj is offline   Reply With Quote
Old 01-04-2016, 07:39 PM   #55
Elite Member
iTrader: (1)

Leafy's Avatar

Join Date: Jun 2012
Location: NH
Posts: 9,093
Total Cats: 90
Default

Quote:
Originally Posted by stefanst View Post
4 of the 'pouches' if memory serves right. And any number different from a multiple of 4 would have raised a flag with me, so I'm pretty sure it's 4.
No markings on the pouches either, so I couldn't confirm capacity without running a controlled discharge/charge cycle.
My prismatic type hobby battery is the biggest I've seen at 8Ah rating. The lower rated ones seem smaller. Stated the car better than the stock battery starts a stock miata when I moved the racecar into the garage in 40F weather after it sat for 2 months.
Leafy is offline   Reply With Quote
Old 01-04-2016, 07:54 PM   #56
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

Quote:
Originally Posted by aidandj View Post
Damn you guys and your $250 batteries.

Any experience with my $25 option?
Not anything both light and streetable in that price range. I got my alien motion 12 cell for $150 on sale over the holidays. I think that is a pretty good price to capacity balance.

The hobby king battery leafy posted is really good for $/amp hour:
ZIPPY Flightmax 8400mAh 4S2P 30C LiFePo4 Pack
asmasm is offline   Reply With Quote
Old 01-04-2016, 07:56 PM   #57
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

Quote:
Originally Posted by aidandj View Post
Anyone have info about Apex batteries? Deka "replacements"

Deka ETX14 Motorcycle Battery
Deka replacement.
aidandj is offline   Reply With Quote
Old 01-04-2016, 07:57 PM   #58
Senior Member
iTrader: (1)

Join Date: Jul 2012
Location: durham NC
Posts: 767
Total Cats: 115
Default

That is scary cheap. My big crank etx9, which should be cheaper since it is smaller, was $60.
asmasm is offline   Reply With Quote
Old 01-04-2016, 08:00 PM   #59
SADFab Destructive Testing Engineer
iTrader: (5)

aidandj's Avatar

Join Date: Apr 2014
Location: Beaverton, USA
Posts: 17,999
Total Cats: 1,466
Default

Deka's aren't $60 anymore. Most places want like $90. Found some at lowes for $75ish.
aidandj is offline   Reply With Quote
Old 01-04-2016, 08:25 PM   #60
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,778
Total Cats: 1,106
Default

Quote:
Originally Posted by aidandj View Post
Damn you guys and your $250 batteries.

Any experience with my $25 option?
Sixshooter and I both use lawn mower batteries from Advance. They cost like $20-$25 and I have never not had it be able to start my car unless it had been sitting for a few weeks. I could get a new one every year and still get 10 years out of them before I hit the price point of those fancy smancy batteries.
shuiend is offline   Reply With Quote
