Default Oil sandwich plate: which to get?

Going turbo, I need an oil source for my turbocharger...

Which means sandwich plate. And while I'm doing it, why not a place for an oil temp sender? And an oil pressure sender? And an oil cooler?

This is primarily a street car, so I'm thinking a thermostat might be good for it, or is that not really an issue?

Anyone have a model to recommend? I've found FM's ($$$$), glowshift (unknown), and ebay (even more unknown).
Nagase is offline   Reply With Quote
Old 03-06-2011, 09:21 AM   #2
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Actually, this looks like a good one:

http://www.racerpartswholesale.com/p...Sandwich_Plate

I'm not sure where I'd put the oil temp/pressure though.
Nagase is offline   Reply With Quote
Old 03-06-2011, 09:28 AM   #3
Elite Member
iTrader: (12)

GeneSplicer's Avatar

Join Date: Sep 2009
Location: Birmingham, AL
Posts: 2,006
Total Cats: 147
Default

DO NOT get this ebay type... reason is the filter o-ring will not make a complete seal... see pic. Not sure the difference between the 1.6 and 1.8 plates. I used it, but had to use a larger filter with an outer groove to sandwich in a larger o-ring... yeah, my filter has 2 o-rings You have a VVT in your sig, sounds 1.8 to me...

Name:  BhOlM-wBGkKGrHqUH-DMEsbdFDCSBLIMhEZ.jpg
Views: 361
Size:  12.8 KB
GeneSplicer is offline   Reply With Quote
Old 03-06-2011, 09:30 AM   #4
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Quote:
Originally Posted by GeneSplicer View Post
DO NOT get the ebay type for the 1.6... reason is the filter o-ring will not make a complete seal... see pic. I used it, but had to use a larger filter with an outer groove to sandwich in a larger o-ring... yeah, my filter has 2 o-rings

Thank you very much for that! I'd actually emailed /that seller/ earlier today about what temp the thermostat on that sandwich opened...

And thanks for your build thread. I actually read that earlier tonight and watching the Sun1 video got me motivated to do more work on my car.
Nagase is offline   Reply With Quote
Old 03-06-2011, 09:40 AM   #5
Elite Member
iTrader: (12)

GeneSplicer's Avatar

Join Date: Sep 2009
Location: Birmingham, AL
Posts: 2,006
Total Cats: 147
Default

Cool! - I was 6 beers deep last night and watched the PBOC sun4 vid again SUN4 ... man, I was having some fun taking out them Porsches! Get that turbo on and let the flogging begin!
GeneSplicer is offline   Reply With Quote
Old 03-06-2011, 11:50 AM   #6
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Get the Mocal plate because you can get new rubbers for it.
hustler is offline   Reply With Quote
Old 03-06-2011, 04:14 PM   #7
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Assuming you already have the OEM 1.8 oil cooler, you don't need an external oil cooler, thus you don't need a fancy thermostat plate. You need this:

Joe Perez is offline   Reply With Quote
Old 03-06-2011, 10:01 PM   #8
Elite Member
iTrader: (13)

Join Date: Dec 2009
Location: Fraser Valley, British Columbia
Posts: 2,502
Total Cats: 13
Default

You can remove one of the 1/8 NPT plugs on the head and use that for your oil feed. Much easier.
falcon is offline   Reply With Quote
Old 03-06-2011, 10:07 PM   #9
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Quote:
Originally Posted by Joe Perez View Post
Assuming you already have the OEM 1.8 oil cooler, you don't need an external oil cooler, thus you don't need a fancy thermostat plate. You need this:

Don't need an external oil cooler? I'm pretty sure Sav and Hustler might disagree with that.

Quote:
Originally Posted by falcon View Post
You can remove one of the 1/8 NPT plugs on the head and use that for your oil feed. Much easier.
What plugs are those? I thought those were only on early engines.
Nagase is offline   Reply With Quote
Old 03-06-2011, 10:10 PM   #10
Trackspeed Engineering
iTrader: (9)

Join Date: Jan 2008
Location: Bay Area, California
Posts: 937
Total Cats: 10
Default

Quote:
Originally Posted by Nagase View Post
Don't need an external oil cooler? I'm pretty sure Sav and Hustler might disagree with that.
You said it is a street car. Street cars don't need oil coolers, only tracked cars do.
crashnscar is offline   Reply With Quote
Old 03-06-2011, 10:12 PM   #11
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Quote:
Originally Posted by crashnscar View Post
You said it is a street car. Street cars don't need oil coolers, only tracked cars do.
I said primarily a street car. And I'm posting in 'race prep'. So my secondary purpose for the car is not on the street.
Nagase is offline   Reply With Quote
Old 03-06-2011, 10:21 PM   #12
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Quote:
Originally Posted by Joe Perez View Post
Assuming you already have the OEM 1.8 oil cooler, you don't need an external oil cooler, thus you don't need a fancy thermostat plate. You need this:

Is that glowshift plate any good?

I won't be tracking my car except for casual funsies and I really just need a plate for my oil pressure and temp sensors.
Faeflora is offline   Reply With Quote
Old 03-06-2011, 10:22 PM   #13
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

I've heard good things about it, talked to Abe about it as well. He says sometimes they're not finished entirely and have some burrs, but overall I've heard they're solid.
Nagase is offline   Reply With Quote
Old 03-06-2011, 10:36 PM   #14
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

Do you know which adapter I need? Thread pitch/size etc? Spoon feed?
Faeflora is offline   Reply With Quote
Old 03-06-2011, 10:50 PM   #15
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

Quote:
Originally Posted by Faeflora View Post
Do you know which adapter I need? Thread pitch/size etc? Spoon feed?
...the information is in the link. That you quoted. WTF.

http://www.glowshiftdirect.com/oil-f...15-thread.aspx

Last edited by Nagase; 03-06-2011 at 11:07 PM.
Nagase is offline   Reply With Quote
Old 03-06-2011, 11:12 PM   #16
Senior Member
iTrader: (4)

Join Date: Nov 2009
Location: Toronto, ON
Posts: 1,479
Total Cats: 6
Default

I have that plate, if not a copy of that plate. No problems yet.
dgmorr is offline   Reply With Quote
Old 03-06-2011, 11:15 PM   #17
MT Pony Underground
Thread Starter
iTrader: (6)

Nagase's Avatar

Join Date: May 2009
Posts: 1,811
Total Cats: 0
Default

So I was thinking about this. The thermostat plate would kill flow to the turbo, which would be a /very bad thing./ So for right now I think I should get that glowshift plate, use the turbo feed line, oil temp and pressure... and then is it ok to put another plate on top of that plate for the oil cooler?
Nagase is offline   Reply With Quote
Old 03-06-2011, 11:18 PM   #18
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Quote:
Originally Posted by Faeflora View Post
Is that glowshift plate any good?
It's a piece of metal with some holes drilled in it. The number of ways in which you can **** that up are pretty limited.

Quote:
Originally Posted by Faeflora View Post
Do you know which adapter I need? Thread pitch/size etc? Spoon feed?
Joe Perez is offline   Reply With Quote
Old 03-07-2011, 01:52 AM   #19
Elite Member
iTrader: (2)

Join Date: Jan 2007
Location: Los Angeles, CA
Posts: 8,782
Total Cats: 119
Default

**** yes!

Thank you kanye!
Faeflora is offline   Reply With Quote
Old 03-07-2011, 02:37 AM   #20
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,326
Total Cats: 1,926
Default

Quote:
Originally Posted by Nagase View Post
So I was thinking about this. The thermostat plate would kill flow to the turbo
You've got me wondering here- how exactly would the thermostat plate kill flow to the turbo?
Joe Perez is offline   Reply With Quote
