Old 11-20-2012, 10:59 AM   #1
Newb
Thread Starter

Join Date: Nov 2012
Posts: 1
Total Cats: 0
Smile Rear End

1990 Miata FM2 conversion Aug 2012. PRior to that the car ws Vodoo II for 2 years. Last nite serious vibration thru the 5 speed shifter on deceleration. Seconds later boom. The driveshaft decided it no longer wanted to be attached to the rear diff.

Going to upgrade the 1990 rear with a later model rear. Whats the best way to go here. I hear stories of later model torsen rear ends dying at 240 hp, and other stories saying they can take a lot more. From a flat out longevity perspective, will an open rear or torsen rear last longer? I know the more a tire spins, the less strain there is on the rest of the drivetrain. When my 1971 455 convertible GTO with posi rear hooks up, it stressses the entire car. When the wheels spin...well, all that power goes up in smoke.

thanks
1990FM2 is offline   Reply With Quote
Old 11-20-2012, 01:09 PM   #2
Elite Member
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,791
Total Cats: 130
Default

You definitely want something '94+ since that's when Mazda upgraded to a 7" rearend. You'll need to swap the driveshaft, differential, and axles from the newer car.

I can't stand to drive an open diff car, but if you don't have any personal preference, you should be able to pick up an open diff considerably cheaper. Any 7" miata rear should be considerably stronger than your 5 speed or motor (assuming those are still stock). There are plenty of guys pushing them beyond 300whp without issues. Not sure I've seen anyone compare torsen vs open as far as longevity, but neither really seems to be a major weakpoint.
pdexta is offline   Reply With Quote
Old 11-21-2012, 01:55 PM   #3
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,372
Total Cats: 1,333
Default

The only way you're going to break a Torsen at <500whp is by drag racing. If you don't drag race, reliability of the 7" rear end is a non-issue.
Savington is offline   Reply With Quote
Old 11-21-2012, 02:08 PM   #4
Junior Member

Join Date: Jan 2007
Location: EXTREME Southern Illinois
Posts: 281
Total Cats: 0
Default

Quote:
Originally Posted by Savington View Post
The only way you're going to break a Torsen at <500whp is by drag racing. If you don't drag race, reliability of the 7" rear end is a non-issue.
I broke a torsen autocrossing. I guess I unweighted a tire enough to get one of them spinning. When it got traction again it liberated some teeth from its innards. I switched to a 1.5-way clutch pack, but I miss the torsen.
DammitBeavis is offline   Reply With Quote
Old 11-21-2012, 02:37 PM   #5
Junior Member

Join Date: Dec 2010
Location: Hartford, Ct
Posts: 125
Total Cats: -11
Default

Would it be ideal to get an rx-7 turbo 2 diff or a 1.8 torsen?
Eunos93 is offline   Reply With Quote
Old 11-21-2012, 02:57 PM   #6
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,328
Total Cats: 1,926
Default

Can we differentiate here between the two different failure modes of the rear-end?

1: Fracture or shearing of the ring & pinion gear. Fairly common, typically happens to the 1.6-style rearends when turbocharged. Almost unheard of in the 1.8-style rearends except in extreme circumstances.

2: Destruction of the differential itself, which is the thing that the ring gear attaches to. This is the failure mode reported by DammitBeavis, wherein the gears in the limited-slip assembly were destroyed due to extreme tire slippage. Can theoretically happen to any differential which contains internal gearing, be it open or Torsen. This failure mode is uncommon as compared to the first.

That said, forget about trying to piece together a bunch of RX7 parts. If your stock 1.6 rearend stayed alive for this long, the chances of you destroying any component inside a 1.8 unit are extremely small.
Joe Perez is offline   Reply With Quote
Old 11-21-2012, 03:00 PM   #7
Elite Member
iTrader: (2)

Join Date: Aug 2012
Location: Indianapolis
Posts: 3,325
Total Cats: 235
Default

Torsen all the way. Turbo 2 diff has no mounting point for the PPF, so you will have to do much fab work to get it to fit. Since the torsen is stronger than the 6-speed, you would be stupid to do all that work unless you were replacing the whole drive train.

Dem768 has broken a bunch of axles, but not his torsen.
thenuge26 is offline   Reply With Quote
Old 11-21-2012, 03:06 PM   #8
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Quote:
Originally Posted by Savington View Post
The only way you're going to break a Torsen at <500whp is by drag racing. If you don't drag race, reliability of the 7" rear end is a non-issue.
hustler is offline   Reply With Quote
Old 11-21-2012, 04:04 PM   #9
Junior Member

Join Date: Dec 2010
Location: Hartford, Ct
Posts: 125
Total Cats: -11
Default

Well since i've been boosted in march i've broken 2 opens and 2 vlsd diffs all 1.6s and i just broke one my last one Saturday. Idk if they are just that weak or its just my driving style, im addicted to roasting second gear and kicking her out sideways! Im trying to figure out whats my next step here because though its probably worth it i cant see myself spending 1000 bucks on a torsen right now!i know you can get an rx7 diff for 3-400 bucks id have to get custom brackkets to mount it and a custom drive haft. But comfort knowing im not gonna brake it! Right now im at 200 hp when tuned im trying fo 300 hp. What would you guys do? Oh op sorry for stealing your thread!
Eunos93 is offline   Reply With Quote
Old 11-21-2012, 04:19 PM   #10
Junior Member

Join Date: Oct 2011
Location: Montreal, QC
Posts: 194
Total Cats: 28
Default

Did you bother to read the thread that you hijacked, or any of the other 948201290 threads that mention how the 1.6 diffs are weak and have been known to break even under 95 whp abuse?

Open or Torsen 1.8 diff. I've seen the opens for sale for as little as $100. Why? Because they don't break, so there's tons of used ones coming off of wrecked cars, and people are removing them for the (high-demand, low supply and therefore $$$) Torsen units.

If you can't afford a Torsen, I wonder about the lapse in logic that would prompt you to shoot for 300 whp.
TalkingPie is offline   Reply With Quote
Old 11-21-2012, 04:34 PM   #11
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,904
Total Cats: 109
Default

Quote:
Originally Posted by Eunos93 View Post
Well since i've been boosted in march i've broken 2 opens and 2 vlsd diffs all 1.6s and i just broke one my last one Saturday. Idk if they are just that weak or its just my driving style, im addicted to roasting second gear and kicking her out sideways! Im trying to figure out whats my next step here because though its probably worth it i cant see myself spending 1000 bucks on a torsen right now!i know you can get an rx7 diff for 3-400 bucks id have to get custom brackkets to mount it and a custom drive haft. But comfort knowing im not gonna brake it! Right now im at 200 hp when tuned im trying fo 300 hp. What would you guys do? Oh op sorry for stealing your thread!
Did you seriously replace 4 broken diffs with 1.6 parts?

Don't be a glutten for punishment. Do the 1.8 swap. Too cheap for a torsen? Weld the damn thing until you can afford parts. Don't worry, after you drive on a welded rear, you will find a way get the torsen soon enough.
miata2fast is offline   Reply With Quote
Old 11-21-2012, 04:38 PM   #12
Junior Member

Join Date: Dec 2010
Location: Hartford, Ct
Posts: 125
Total Cats: -11
Default

I have read it and i understand 1.6s are weak. Im just trying to see where my next step should be because im tired of braking diffs and i dont want an open i need lsd so im just weighing out my options. And what makes you think I can't make 300 hp if I already have 200 at 8psi. Who 10-12 more psi and a good tune i think 300 is reacheable if not close!
Eunos93 is offline   Reply With Quote
Old 11-21-2012, 04:40 PM   #13
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,328
Total Cats: 1,926
Default

Quote:
Originally Posted by Eunos93 View Post
Im just trying to see where my next step should be
Your next step should be a complete Torsen assembly out of a '94-'05 Miata.
Joe Perez is offline   Reply With Quote
Old 11-21-2012, 04:59 PM   #14
Junior Member

Join Date: Oct 2011
Location: Montreal, QC
Posts: 194
Total Cats: 28
Default

If ballin': Torsen.

If no money: 1.8 open which can be had very cheaply and will get your car running as well as before, but won't break. Realize that adding more power to a drivetrain that you already can't afford to properly support may not be advisable. Engines and transmissions are pricier to change than diffs.
TalkingPie is offline   Reply With Quote
Old 11-21-2012, 05:19 PM   #15
Cpt. Slow
iTrader: (25)

curly's Avatar

Join Date: Oct 2005
Location: Oregon City, OR
Posts: 12,110
Total Cats: 518
Default

I converted my 1.6 VLSD to a clutch pack LSD for $370

$170 of that was converting the 1.8 open to the RX-7 clutch pack diff.

You just have to be frugal. Get the RX-7 diff for cheap either at a junk yard, here, or on an RX-7 forum. Rebuild it with a shim. I used the stock ECU case. Recycle, Reduce, Reuse!
curly is offline   Reply With Quote
Old 11-21-2012, 05:30 PM   #16
Junior Member

Join Date: Dec 2010
Location: Hartford, Ct
Posts: 125
Total Cats: -11
Default

I like that idea curly that's another option that's all!
Eunos93 is offline   Reply With Quote
Old 10-23-2013, 11:48 AM   #17
Junior Member
iTrader: (3)

Join Date: Nov 2007
Location: Boston / '90 Mariner Blue
Posts: 310
Total Cats: 14
Default

Quote:
Originally Posted by curly View Post
I converted my 1.6 VLSD to a clutch pack LSD for $370

$170 of that was converting the 1.8 open to the RX-7 clutch pack diff.

You just have to be frugal. Get the RX-7 diff for cheap either at a junk yard, here, or on an RX-7 forum. Rebuild it with a shim. I used the stock ECU case. Recycle, Reduce, Reuse!
Curly, is there a write-up on how-to do the rebuild? I get just a little nervous when it comes to things unknown.

Greatly appreciate it!
alik is offline   Reply With Quote
Old 10-23-2013, 11:54 AM   #18
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,900
Total Cats: 1,792
Default

you do the rebuild by buying a torsen and not dealing with clutches.


I did my torsen upgrade for $400 total. that includes the axles, driveshaft, and torsen rear end.
Braineack is offline   Reply With Quote
Old 10-23-2013, 12:00 PM   #19
Junior Member
iTrader: (3)

Join Date: Nov 2007
Location: Boston / '90 Mariner Blue
Posts: 310
Total Cats: 14
Default

My Torsen is going.
I somehow have gotten the notion that clutch would perform better in my style of driving (every time Torsen feels like an open diff, and, no, this isn't my first Torsen (lost one due to housing failure.)

And, yeah, using Joe Perez's advice, I got mine for $250.

FC diffs can be had near here for $100. I have the 1.8 in place, so no other hardware is required (save for circlips).
That much I've figured out. As far as preload, shimming, rebuilding, I'm still completely in the dark.

Scott, if you could shed a little light, I'd greatly appreciate it.
alik is offline   Reply With Quote
Old 10-23-2013, 12:09 PM   #20
Elite Member
iTrader: (2)

Join Date: Aug 2012
Location: Indianapolis
Posts: 3,325
Total Cats: 235
Default

I find it hard to believe you've broken 2 torsens at stock power. WTF are you doing to your car?
thenuge26 is offline   Reply With Quote
