Should I safety wire 2 piece wilwood rotors?

Old 12-12-2012, 03:51 PM
  #1
Senior Member
Thread Starter
iTrader: (6)

Join Date: Jun 2010
Location: San Rafael, CA
Posts: 1,319
Total Cats: 57
Default Should I safety wire 2 piece wilwood rotors?

I think most track prepped guys safety wire the 2 piece wilwood rotors. My used kit came without the proper bolts to do so. Should I order the bolts needed to safety wire them? If so what about caliper mounting bolts? Should they receive the same attention?
k24madness is offline
Old 12-12-2012, 04:55 PM
  #2
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 15,012
Total Cats: 1,820
Default

We wire our rotors. Un-wired rotors scare me.
__________________
Trackspeed Engineering
High-Performance Turbo Specialists - Sunnyvale, CA - 650-701-7223 - Email us!
Originally Posted by codrus View Post
Basically I've come over to the camp of "If something is a reliability problem on the track, just ask Andrew and do what he says".
Savington is offline
Old 12-12-2012, 05:06 PM
  #3
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,085
Total Cats: 367
Default

Wire the rotors and live to tell about it.
hustler is offline
Old 12-12-2012, 07:06 PM
  #4
Senior Member
Thread Starter
iTrader: (6)

Join Date: Jun 2010
Location: San Rafael, CA
Posts: 1,319
Total Cats: 57
Default

Thanks guys I just ordered the correct bolts so they can be wired. Do the calipers need to be wired as well?
k24madness is offline
Old 12-12-2012, 07:32 PM
  #5
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 15,012
Total Cats: 1,820
Default

The calipers bolts don't get flung around hundreds of times a minute in a circular direction while enduring near-constant thermal cycling, so it's not necessary to wire them.
__________________
Trackspeed Engineering
High-Performance Turbo Specialists - Sunnyvale, CA - 650-701-7223 - Email us!
Originally Posted by codrus View Post
Basically I've come over to the camp of "If something is a reliability problem on the track, just ask Andrew and do what he says".
Savington is offline
Old 12-12-2012, 07:38 PM
  #6
Senior Member
Thread Starter
iTrader: (6)

Join Date: Jun 2010
Location: San Rafael, CA
Posts: 1,319
Total Cats: 57
Default

Thanks Sav!

I spoke to the Wilwood tech guys to confirm that I was ordering the correct bolts. He was surprised the Miata brake kits have changed to torx button heads for the rotor/hat mounting. He agreed safety wire was best for a track car.
k24madness is offline
Old 12-12-2012, 08:04 PM
  #7
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 15,012
Total Cats: 1,820
Default

We're still using high-grade drilled hex head screws in every kit we sell. I doubt that will ever change.
__________________
Trackspeed Engineering
High-Performance Turbo Specialists - Sunnyvale, CA - 650-701-7223 - Email us!
Originally Posted by codrus View Post
Basically I've come over to the camp of "If something is a reliability problem on the track, just ask Andrew and do what he says".
Savington is offline
Old 12-12-2012, 08:36 PM
  #8
Elite Member
iTrader: (3)

Join Date: Mar 2008
Location: Granbury, TX
Posts: 6,132
Total Cats: 646
Default

Torx button heads can be safety wired too. See it all the time on jet engines (those are actually hex button heads, not torx). Hex head is a more positive safety though.
hornetball is offline
Old 12-15-2012, 02:46 PM
  #9
Junior Member

Join Date: May 2009
Location: Bay Area, CA and Portland, OR
Posts: 99
Total Cats: 0
Default

Always secure safety critical components.
gaius49 is offline
Old 08-22-2013, 05:04 PM
  #10
Elite Member

Join Date: Oct 2011
Location: OKC, OK
Posts: 3,149
Total Cats: 107
Default

Originally Posted by k24madness View Post
Thanks Sav!

I spoke to the Wilwood tech guys to confirm that I was ordering the correct bolts. He was surprised the Miata brake kits have changed to torx button heads for the rotor/hat mounting. He agreed safety wire was best for a track car.
Don't suppose a guy would have a link to these, would ya?

I picked up the Super Miata 11" kit and it has the same screws you are talking about, I'm not putting it together with those.
z31maniac is offline
Old 08-22-2013, 05:36 PM
  #11
Junior Member
iTrader: (1)

Join Date: Aug 2006
Location: Ellicott City, MD
Posts: 456
Total Cats: 6
Default

Also interested in the correct bolts. I haven't driven it much but was not happy to put them on without safety wire.
MicaCeli is offline
Old 08-25-2013, 09:59 PM
  #12
Bannisheded

Join Date: Jul 2013
Location: LA (Lower Alabama) Elberta, Al
Posts: 25
Total Cats: 1
Default

I Drill the bolts myself and safety almost everything. But after 20 years as an Aircraft maintainer, it's just a habit.
Utter is offline
Old 08-27-2013, 07:44 PM
  #13
Elite Member

Join Date: Oct 2011
Location: OKC, OK
Posts: 3,149
Total Cats: 107
Default

Found these, getting ready to order.

http://www.summitracing.com/parts/arp-300-0802
z31maniac is offline
Old 09-10-2013, 09:40 AM
  #14
Elite Member

Join Date: Oct 2011
Location: OKC, OK
Posts: 3,149
Total Cats: 107
Default

Originally Posted by z31maniac View Post
Found these, getting ready to order.

http://www.summitracing.com/parts/arp-300-0802
And these don't work with SuperMiata 11" kit with 949 curved rotors.

The shank is too long to allow the bolt to actually tighten the rotor to the hat.
z31maniac is offline
Old 09-10-2013, 12:36 PM
  #15
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,888
Total Cats: 46
Default

I'm sure you can find what you need here:

Stainless Drilled Hex Bolts


But a safety wire drill jig and a pile of 1/16" jobber length drills would probably cost you less than the pre-drilled hardware.


Fastenal and places like that also carry pre-drilled stainless socket head capscrews, btw..
vehicular is offline
Old 09-10-2013, 01:16 PM
  #16
Elite Member

Join Date: Oct 2011
Location: OKC, OK
Posts: 3,149
Total Cats: 107
Default

Originally Posted by vehicular View Post
I'm sure you can find what you need here:

Stainless Drilled Hex Bolts


But a safety wire drill jig and a pile of 1/16" jobber length drills would probably cost you less than the pre-drilled hardware.


Fastenal and places like that also carry pre-drilled stainless socket head capscrews, btw..
Thanks for the link, it's too bad they don't show the bolt dimensions on the shank.

I'm a pay more for solutions vs doing my own stuff. Limited garage/tool space and a lack of time means I'm willing to pay for convenience.
z31maniac is offline
Old 09-10-2013, 03:13 PM
  #17
Elite Member
iTrader: (3)

Join Date: Feb 2008
Location: Huntsville, AL
Posts: 1,888
Total Cats: 46
Default

They make these things called rulers that make it really easy to find the lengths of other things. They (rulers) are graduated, and the markings can be compared to the item being measured, and a length can be determined by how many of the markings the item corresponds to.


Attached Thumbnails Should I safety wire 2 piece wilwood rotors?-10687wooden_ruler.jpg
vehicular is offline
Old 09-10-2013, 03:29 PM
  #18
Elite Member

Join Date: Oct 2011
Location: OKC, OK
Posts: 3,149
Total Cats: 107
Default

Thanks!
z31maniac is offline
