Default Trying to finish my tranny swap today and have a question! Please Help!!

Hey all,

I am just about bolted up with the MSM transmission where a damn automatic used to be. The point where I am at now is a little sticky to me; so I thougt I would ask before breaking something.

How far away is the bellhousing going to be from the transmission plate / block before I can start cranking the bolts? My issue is that I have what looks like the entire trans aligned but there is still a significant gap between the bellhousing and the block? What's the rule of thumb and is this an indication that my shaft is not all the way in the cluch or pilot bearing maybe?

Thanks all and cheers,
Prospero
Prospero is offline   Reply With Quote
Old 04-05-2009, 07:15 PM   #2
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,366
Total Cats: 1,327
Default

It's like a quarter inch. It can be a serious bitch to get in there; put a SMALL amount of motor oil or some other lube on the tranny input shaft to help you out. The other trick is to put the tranny in gear, install the driveshaft, and spin the tranny a little bit to try to get the splines to line up.
Savington is offline   Reply With Quote
Old 04-05-2009, 07:19 PM   #3
Elite Member
iTrader: (21)

paul's Avatar

Join Date: Jun 2006
Location: Point Pleasant, NJ
Posts: 2,957
Total Cats: 2
Default

I know I've run into trouble with the bracket for the EGR pipe getting in the way. Not sure you guys even have that over there but if you do it's worth a look to see if it's interfering.
paul is offline   Reply With Quote
Old 04-05-2009, 07:26 PM   #4
Senior Member
iTrader: (5)

Join Date: Apr 2008
Location: VA
Posts: 828
Total Cats: -2
Default

that last bit can be a bear. like they say, lube the shaft a bit and make sure the front of the engine is jacked up a little. It'll go
thymer is offline   Reply With Quote
Old 04-05-2009, 08:52 PM   #5
y8s
2 Props,3 Dildos,& 1 Cat
iTrader: (8)

y8s's Avatar

Join Date: Jun 2005
Location: Fake Virginia
Posts: 19,038
Total Cats: 407
Default

and make sure the thin sheetmetal gasket is on the bosses too.
y8s is offline   Reply With Quote
Old 04-05-2009, 09:19 PM   #6
Elite Member
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,791
Total Cats: 130
Default

If everything is going in square and it's close enough that I can get all the bolts started I go ahead and start cranking them down. Not saying that you want to go crazy trying to beat the thing into place or anything, but it definitely takes a little force to get it in there. In the 4-5 times I've put the tranny/motor together it's never just fallen together.
pdexta is offline   Reply With Quote
Old 04-05-2009, 09:29 PM   #7
Senior Member
Thread Starter

Join Date: Nov 2007
Location: somewhere in NoVA
Posts: 550
Total Cats: -1
Default

Wow!!! Thank you all for the help!

After a bit of manipulation the whole thing went right on... I was just nervous about that last little bit but once the bolts were threading evenly the whole damn thing went on like it grew there..

So now I have the trans bolted up and whatnot, the plumbing all needs to go into place for the clutch line and then of cours the pedals need to be installed....

Then I need to find out how to get the neutral safety switch to work and the speedo... and the reverse lights.... and the this and the that... OMG this is still a ways away

Thanks again all and cheers!

Prospero
Prospero is offline   Reply With Quote
Old 04-05-2009, 09:35 PM   #8
Senior Member
iTrader: (6)

Join Date: Sep 2007
Posts: 1,085
Total Cats: 30
Default

The big things are done! Awesome
albumleaf is offline   Reply With Quote
Old 04-06-2009, 12:40 AM   #9
Elite Member
iTrader: (33)

RotorNutFD3S's Avatar

Join Date: Jan 2007
Location: Newnan, GA
Posts: 2,539
Total Cats: 29
Default

FWIW, I just installed mine today (out of the car). I have the engine on a hoist with a load leveler and I put the transmission on a mechanic's creeper. Lowered the engine and leveled it to be even, rolled the trans forward to it, and everything engaged smoothly. Then put the bolts on. It was nice to have it work out so well.
RotorNutFD3S is offline   Reply With Quote
Old 04-06-2009, 01:56 AM   #10
Supporting Vendor
iTrader: (31)

Savington's Avatar

Join Date: Nov 2006
Location: Sunnyvale, CA
Posts: 14,366
Total Cats: 1,327
Default

That is why I almost prefer to pull the engine to do tranny/clutch work. It is *SO* much easier to get the two mated outside of the car, and pulling the motor really isn't a lot of work.
Savington is offline   Reply With Quote
Old 04-06-2009, 10:28 AM   #11
Senior Member
Thread Starter

Join Date: Nov 2007
Location: somewhere in NoVA
Posts: 550
Total Cats: -1
Default

Tell you what... that damn automatic was much more of a pain to get out than it was to install the manual. The auto box is just larger, heavier, and had so much more going on... what a royal pain in the ***! Glad that the SOB is out of my car and now I can have a little more fun!

I also think that a contributing factor was also that I was installing a tranny from a much newer car onto an older car... sure they are supposed to fit perfectly but in actuality there was one damn bell housing bolt that refused to go in easily. The threads were perfect... it was just a slight interference fit with the shoulder of the bolt.

Anyhow... it was not the type of project that I would do for fun! It was not too bad while doing the work; but hell... I am sore as **** now.

Cheers,
Prospero
Prospero is offline   Reply With Quote
Old 04-06-2009, 10:38 AM   #12
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

Quote:
Originally Posted by Savington View Post
It is *SO* much easier to get the two mated outside of the car, and pulling the motor really isn't a lot of work.

I just shake the **** out of it till it lines up...
Braineack is offline   Reply With Quote
Old 04-06-2009, 11:35 AM   #13
Senior Member
Thread Starter

Join Date: Nov 2007
Location: somewhere in NoVA
Posts: 550
Total Cats: -1
Default

Hmm... that sounds like the right way of doing it...

Or there is always the other way!!!!

Trying to finish my tranny swap today and have a question! Please Help!!-04062009-060.jpg

Trying to finish my tranny swap today and have a question! Please Help!!-04062009-061.jpg
I love the big hammer!!!!!
Prospero is offline   Reply With Quote
Old 04-06-2009, 11:40 AM   #14
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

its really what i do. once the input shaft is lined up, i wiggle/rotate/shake the **** out of it till it comes together.
Braineack is offline   Reply With Quote
Old 04-10-2009, 10:58 PM   #15
Newb

Join Date: Sep 2008
Posts: 32
Total Cats: 0
Default

Nice pillows
Fritz is offline   Reply With Quote
Old 04-10-2009, 10:59 PM   #16
Newb

Join Date: Sep 2008
Posts: 32
Total Cats: 0
Default

If you can get someone to turn teh driveshaft while you wiggle that ma help.
Fritz is offline   Reply With Quote
