Default Your Vote Replace Clutch or Transmission -- Engine in or Engine Out?

I am a new Miata owner.

Replacing a five speed with a six speed.

I have researched the threads. Some say pull engine and tranny. Some say do it with the engine in place.

My question for your vote. For those who have actually replaced a clutch or transmission. If you did it again would you:

Pull the engine and transmission?

Replace the clutch or transmission with the engine in place?

What would YOU do??
Roadbird is offline   Reply With Quote
Old 02-06-2013, 12:17 AM   #2
Slowest Progress Ever
iTrader: (26)

thirdgen's Avatar

Join Date: Oct 2007
Location: The coal ridden hills of Pennsylvania
Posts: 5,808
Total Cats: 183
Default

I've done it with the engine still in the car, on jack stands. It went ok. The next time I do it, I'm pulling everything out at once though.
thirdgen is offline   Reply With Quote
Old 02-06-2013, 12:43 AM   #3
Elite Member
iTrader: (6)

Join Date: May 2011
Location: Lebanon, TN
Posts: 1,668
Total Cats: 63
Default

I've done it on a hoist in the air with air tools and jacks, etc. If I didn't have access to a full shop I'd pull the whole thing. In a garage it's easier.
TorqueZombie is offline   Reply With Quote
Old 02-06-2013, 12:44 AM   #4
Elite Member
iTrader: (2)

Join Date: Aug 2012
Location: Indianapolis
Posts: 3,325
Total Cats: 235
Default

Same. Bench pressing a tranny ain't fun, just pull the whole thing.
thenuge26 is offline   Reply With Quote
Old 02-06-2013, 01:08 AM   #5
Newb
Thread Starter

Join Date: Feb 2013
Posts: 40
Total Cats: -8
Default

More info:

I will be doing this in a garage with a car lift and a 25 year experienced and certified mechanic who has unfortunately not done a Miata.

Please keep replying. Nothing replaces experience.
Roadbird is offline   Reply With Quote
Old 02-06-2013, 01:11 AM   #6
Boost Pope
iTrader: (8)

Joe Perez's Avatar

Join Date: Sep 2005
Location: Delicious and Moist.
Posts: 26,323
Total Cats: 1,920
Default

In a proper garage, with a two-post lift *and* a transmission jack, I'd go ahead and leave the engine in.

At home, with jackstands, I will never again pull a transmission separately form the engine. Been there, done that.
Joe Perez is offline   Reply With Quote
Old 02-06-2013, 01:13 AM   #7
Newb

Join Date: Jan 2012
Posts: 27
Total Cats: -2
Default

I can't imagine any reason to pull the entire engine out. With a lift it is a total no brainer. On the ground you definitely need a transmission jack with wheels, I tried to bench it up and it's really not feasible and a regular floor jack has the transmission too unwieldy. I got one at harbor freight and it made putting it back on super easy. As long as he has a transmission jack, it should be a total piece of cake with a lift. It's not a hard job and pulling the engine isn't going to save you any time or stress, it's just going to add it.
ED9man is offline   Reply With Quote
Old 02-06-2013, 03:54 AM   #8
Elite Member
iTrader: (5)

Join Date: Oct 2007
Location: Canton, Ga
Posts: 1,707
Total Cats: 19
Default

Its way easier with the engine out.. Its only two motor mounts, a few wires and hoses more and so much easier than crawling around under the car the whole time.
Stealth97 is offline   Reply With Quote
Old 02-06-2013, 04:49 AM   #9
Elite Member
iTrader: (7)

Join Date: Jan 2007
Location: Renton Washington
Posts: 1,742
Total Cats: 3
Default

I vote for engine in the car. YMMV
SKMetalworks is offline   Reply With Quote
Old 02-06-2013, 08:57 AM   #10
Newb

Join Date: Jan 2013
Location: Charlotte, NC
Posts: 20
Total Cats: 0
Default

Quote:
Originally Posted by Roadbird View Post
25 year experienced and certified mechanic
I would think you would want to defer to their preference.

For just the clutch/transmission, I have not pulled the engine for the simple fact that hoses and electrical connections may be in unknown condition on older cars. If you are replacing radiator/heater hoses (or anything else) along the way, you might as well pull everything.

donour
donour is offline   Reply With Quote
Old 02-06-2013, 09:00 AM   #11
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,896
Total Cats: 109
Default

I have done it both ways, many times. It is faster if you leave the engine in the car, even if the car is on jackstands. And I mean by a long shot.
miata2fast is offline   Reply With Quote
Old 02-06-2013, 09:11 AM   #12
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

Quote:
Originally Posted by thenuge26 View Post
Same. Bench pressing a tranny ain't fun, just pull the whole thing.
deadlifting a tranny into place isn't any easier.





doing a transmission clutch is a two hour job if you're a Boostin' Banger. Pulling the motor... HA, I scoff at you all. I bite my thumb in your general directions.







Engine-pulling clutch-jobers:



take your tutu off and put on a pair of big boy pants. Hell, team Boosting Bangers is going to help crew a Chumpcar this summer, we've debated swapping the trans when no one is looking...just because we can.
Attached Thumbnails
Your Vote Replace Clutch or Transmission -- Engine in or Engine Out?-ribbonstutu1.jpg
Braineack is offline   Reply With Quote
Old 02-06-2013, 09:12 AM   #13
Tour de Franzia
iTrader: (6)

hustler's Avatar

Join Date: Jun 2006
Location: Republic of Dallas
Posts: 29,114
Total Cats: 351
Default

Leave the engine in.
hustler is offline   Reply With Quote
Old 02-06-2013, 09:16 AM   #14
Elite Member
iTrader: (17)

Join Date: Aug 2007
Location: Fort Myers, FL
Posts: 2,791
Total Cats: 130
Default

Quote:
Originally Posted by miata2fast View Post
I have done it both ways, many times. It is faster if you leave the engine in the car, even if the car is on jackstands. And I mean by a long shot.
+1. I can see debating whether it's easier to pull the motor with the transmission or without the transmission. But when you're talking about swapping a clutch it's MUCH easier to just drop the tranny. As long as you've got several feet of extensions and a u-joint socket you can get it out of there pretty quick.

Last edited by pdexta; 02-18-2013 at 09:19 AM.
pdexta is offline   Reply With Quote
Old 02-06-2013, 09:22 AM   #15
Elite Member
iTrader: (9)

TurboTim's Avatar

Join Date: Jun 2006
Location: Chesterfield, NJ
Posts: 6,485
Total Cats: 248
Default

I've done it a few times at a shop with a lift/tranny jack/right tools (long extension and swivel sockets), and only had issues once. Knowing now how silly simple it is to yank the engine with the trans attached, I would probably do it that way in the future.
TurboTim is offline   Reply With Quote
Old 02-06-2013, 09:30 AM   #16
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,776
Total Cats: 1,106
Default

Go to harbor freight and spend the $40 on a transmission jack. Put a jack under the front of the oil pan to keep the engine at the correct angle. Unbolt the trans and pull it back and lower it on the trans jack. Replace the clutch, raise trans and slide it back in. Seriously with a trans jack and the proper extensions it is a piece of cake with the engine in the car.
shuiend is offline   Reply With Quote
Old 02-06-2013, 09:34 AM   #17
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

I remember one of the biggest headaches I ever had was trying to mate a trans to my motor on the floor of my garage.

I'd much rather do a trans swap on jackstands without a tranny jack then attempting that fiacso again.
Braineack is offline   Reply With Quote
Old 02-06-2013, 09:38 AM   #18
Junior Member

Join Date: Oct 2009
Location: Stamford, CT
Posts: 212
Total Cats: 3
Default

Quote:
Originally Posted by Joe Perez View Post
At home, with jackstands, I will never again pull a transmission separately form the engine. Been there, done that.
This.

I did it with no transmission jack, just with a regular jack and a block of wood, and it was a royal pain. If you need to drill/tap the pain or do an oil pan gasket because your motor is old, you're better off pulling the whole thing anyway.
AlexL is offline   Reply With Quote
Old 02-06-2013, 09:52 AM   #19
Boost Czar
iTrader: (61)

Braineack's Avatar

Join Date: May 2005
Location: Chantilly, VA
Posts: 72,872
Total Cats: 1,790
Default

I'm making a note of who the pussies/feeble mechanics on this site are.
Braineack is offline   Reply With Quote
Old 02-06-2013, 10:01 AM   #20
Elite Member
iTrader: (2)

miata2fast's Avatar

Join Date: Aug 2009
Location: Dover, FL
Posts: 2,896
Total Cats: 109
Default

A lot of you guys are forgetting how much needs to be done to remove the engine and tranny together. There is just no comparison on which method is best.

I would suggest locking this thread to save you guys the embarrassment of discussing this any more.
miata2fast is offline   Reply With Quote
