Default 1.8 EWG gt2560

**The reason for the lack of torque before 4k is that im running straight spring pressure on the wg. the wg opens gradually which kills spool but this setup is the only way i can get it to not spike when up shifting in higher gears. **


datalog from this dyno run
3000rpm 8psi
3400 10psi
3800 11psi
4500 12psi
5000-7200 13psi






stock bp4w @43k miles
fab9 manifold
tial 38mm wg vta
gt2560 @12-13psi (this is absolute pressure on the ecu. Gauge pressure is more like 13-14psi)
3 inch exhaust from turbo to tip. no cat
flyin miata IC
hydra nemesis
base FM timing map
93 octane

Y I NO MAKE TORQUES????
i believe the power number because of the 3 inch exhaust and the amount of boost. Ive had 2 different boost gauges in the car that both read 1-2 psi "higher" than the ecu. Pretty sure 12 psi absolute is less than gauge pressure. Im upset that i cant turn the power up any more. the car doesnt feel crazy fast now

this is the timing map



Last edited by LownSlow616; 09-03-2016 at 07:36 PM.
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 02:38 PM   #2
Junior Member

Join Date: Nov 2012
Location: Israel
Posts: 493
Total Cats: -271
Default

Check base timing and then add timing!
elior77 is offline   Reply With Quote
Old 09-03-2016, 02:41 PM   #3
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

y
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 02:43 PM   #4
Junior Member

Join Date: Nov 2012
Location: Israel
Posts: 493
Total Cats: -271
Default

Your timing table is very conservative I think you said it is a base map, did you got it tuned?
elior77 is offline   Reply With Quote
Old 09-03-2016, 02:45 PM   #5
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Quote:
Originally Posted by elior77 View Post
did you got it tuned?
no i didnt got it tuned. just power runs
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 02:54 PM   #6
Junior Member

Join Date: Nov 2012
Location: Israel
Posts: 493
Total Cats: -271
Default

You need to tune it and install and tune an ebc.
elior77 is offline   Reply With Quote
Old 09-03-2016, 02:57 PM   #7
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Quote:
Originally Posted by elior77 View Post
You need to tune it and install and tune an ebc.
Since you know everything that i NEED to do why don't i just let u borrow the car for a couple years so u can make it right for me. If u could actually read youd know i cant use EBC or it will spike. Ive tried standalone ebc, mbc, and hydra ebc. The only way it wont spike is straight spring pressure
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 04:45 PM   #8
Junior Member

Join Date: Nov 2012
Location: Israel
Posts: 493
Total Cats: -271
Default

Listen love, I just tuned an NB with the same turbo and ebc, so I think I know what I'm talking about.

Do you actually asking something or just looking to fight?
elior77 is offline   Reply With Quote
Old 09-03-2016, 04:52 PM   #9
Elite Member
iTrader: (8)

Ryan_G's Avatar

Join Date: Jan 2012
Location: Tampa, Florida
Posts: 2,450
Total Cats: 137
Default

Quote:
Originally Posted by LownSlow616 View Post
Since you know everything that i NEED to do why don't i just let u borrow the car for a couple years so u can make it right for me. If u could actually read youd know i cant use EBC or it will spike. Ive tried standalone ebc, mbc, and hydra ebc. The only way it wont spike is straight spring pressure
If it's not creeping on spring pressure an EBC should be able to maintain the same target boost. You just need to keep working on the tune. If you for instance find where it spikes and bleed it off early enough you should prevent the spike. There is no reason that an EBC would cause a spike over just the spring rate other than it not being tuned correctly.
Ryan_G is offline   Reply With Quote
Old 09-03-2016, 06:12 PM   #10
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

I have an aem tru boost. I can set at which pressure the solenoid stops sending pressure to the top of the diaphragm(holding it closed)
If i set that number near or above the spring pressure, it will spike when i shift at high rpms
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 06:24 PM   #11
A living god
iTrader: (23)

viperormiata's Avatar

Join Date: Aug 2008
Location: Key West
Posts: 5,984
Total Cats: 235
Default

OP stop acting like a ----.
viperormiata is offline   Reply With Quote
Old 09-03-2016, 06:48 PM   #12
Elite Member
iTrader: (6)

Join Date: Feb 2013
Location: Staunton, Va
Posts: 2,079
Total Cats: 159
Default

The spool is dookie. I make 6 psi at like 2500. What's wrong with it?
ryansmoneypit is online now   Reply With Quote
Old 09-03-2016, 06:53 PM   #13
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Also..it spools ALOT better on the actual road
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 06:53 PM   #14
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Quote:
Originally Posted by ryansmoneypit View Post
The spool is dookie. I make 6 psi at like 2500. What's wrong with it?
Can u read? It spools worse on the dyno and the wg cracks open at 7 psi and climbs up to its spring pressure
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 06:55 PM   #15
Elite Member
iTrader: (6)

Join Date: Feb 2013
Location: Staunton, Va
Posts: 2,079
Total Cats: 159
Default

Sorry, I would have a bad attitude if I had a dry dick too.

You said it cracks at 7, so why does it spool like **** to 6?
ryansmoneypit is online now   Reply With Quote
Old 09-03-2016, 07:07 PM   #16
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

this is from the previous run. it spools fine. like i said, the wg just opens way earlier than target psi. and if i use ebc to hold it closed longer, it spikes on up shifts.



im happy rn. i made good power to beat mustangs at the strip and not crazy torque to blow the stock engine. im happy asf for 261 whp on a conservative timing map that will never knock
LownSlow616 is offline   Reply With Quote
Old 09-03-2016, 07:21 PM   #17
Elite Member
iTrader: (6)

Join Date: Feb 2013
Location: Staunton, Va
Posts: 2,079
Total Cats: 159
Default

That's good hp on a stock block.
ryansmoneypit is online now   Reply With Quote
Old 09-03-2016, 07:27 PM   #18
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Thx
LownSlow616 is offline   Reply With Quote
Old 09-04-2016, 12:10 AM   #19
Murderator
iTrader: (76)

18psi's Avatar

Join Date: Apr 2008
Posts: 34,869
Total Cats: 2,334
Default

Good power as expected (for that much timing/boost). What really surprises me about the torque is how flat it is and how flat it stays all the way up, but then it looks like you're dropping timing from 19 to 16 if it goes to 14 like you say.

I'd congratulate you on really clever tuning (this is about the least abusive way to make 250 and try to keep the rods intact) but it looks like you got that result on accident lol

Congrats anyway
18psi is offline   Reply With Quote
Old 09-04-2016, 12:23 AM   #20
40 roll
Thread Starter

LownSlow616's Avatar

Join Date: May 2015
Location: Grand Rapids, MI
Posts: 297
Total Cats: -34
Default

Yeah I knew I was going to get flamed for the lack of torque but im actually happy about it for the stock rods. Its just preparing me for the feeling of a big turbo car when i go gt2871 in the future.
Next is 1320 trap speed

ALSO---- thank u for telling me to get a baseline number. I could've started turning things up on the street and popped the engine. I didnt think i was anywhere near the "limit"
LownSlow616 is offline   Reply With Quote
