Old 02-17-2015, 10:54 AM   #21
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by 18psi View Post
the cool thing about t25's is you can slap in a 2560 or 2860 and retain everything else, and voila - instant topend gains without giving up almost any of the lowend. win/win
yeah 2560 is coming once I am used to this power
gr4v3r is offline   Reply With Quote
Old 03-12-2015, 03:57 PM   #22
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Coolant Reroute and 949 stage 1 brake kit installed with carbotech ax6 pads. FM butterfly brace and miataroadster shifter on order. Too bad everything is on back order....

Oh and hard top in storage!

gr4v3r is offline   Reply With Quote
Old 03-12-2015, 09:29 PM   #23
I take big bites
iTrader: (1)

turbofan's Avatar

Join Date: Sep 2010
Location: Hurricane, UT
Posts: 6,924
Total Cats: 526
Default

I also wish to echo the beauty that was your FRS. The Miater looks really nice though, and those are really strong numbers. Must be a total blast to drive.
turbofan is offline   Reply With Quote
Old 03-13-2015, 10:10 AM   #24
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by turbofan View Post
I also wish to echo the beauty that was your FRS. The Miater looks really nice though, and those are really strong numbers. Must be a total blast to drive.
Dont make me regret my decision!
gr4v3r is offline   Reply With Quote
Old 03-14-2015, 05:52 AM   #25
Senior Member
iTrader: (2)

Join Date: Oct 2011
Location: SE NM
Posts: 1,460
Total Cats: 48
Default

I just bought a BRZ and the torque dip kills all street enjoyment for me. What did you think of it before you supercharged your FRS?
Chilicharger665 is offline   Reply With Quote
Old 03-14-2015, 09:51 AM   #26
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by Chilicharger665 View Post
I just bought a BRZ and the torque dip kills all street enjoyment for me. What did you think of it before you supercharged your FRS?

Just always drive above 4k rpms :P also a good header and tune will help the dip issues
gr4v3r is offline   Reply With Quote
Old 03-19-2015, 12:24 PM   #27
Newb

Join Date: Mar 2015
Location: Indianapolis
Posts: 17
Total Cats: 0
Default

That torque curve almost makes me think an NA 1.8 head wouldn't be the worst thing in the world. Nice build so far, very similar to what I am planning.
Michael13 is offline   Reply With Quote
Old 03-19-2015, 12:39 PM   #28
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by Michael13 View Post
That torque curve almost makes me think an NA 1.8 head wouldn't be the worst thing in the world. Nice build so far, very similar to what I am planning.
Thanks, we will see how it handles the first autox on saturday. I will have videos
gr4v3r is offline   Reply With Quote
Old 03-20-2015, 09:02 AM   #29
Newb

Join Date: Mar 2015
Location: Indianapolis
Posts: 17
Total Cats: 0
Default

Quote:
Originally Posted by gr4v3r View Post
Thanks, we will see how it handles the first autox on saturday. I will have videos
Subscribed, and holding you to that.
Michael13 is offline   Reply With Quote
Old 03-20-2015, 01:00 PM   #30
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by Michael13 View Post
Subscribed, and holding you to that.
So for some reason mother nature decided we needed a blizzard.... Event cancelled. Theres another event next weekend though so we will have video then.
gr4v3r is offline   Reply With Quote
Old 03-23-2015, 12:36 PM   #31
Junior Member
iTrader: (1)

Join Date: Jul 2013
Location: Jacksonville, FL
Posts: 65
Total Cats: 7
Default

Where's the next event you're talking about? I'm in the Lehigh Valley and have been looking for something to checkout.
pshgomiata is offline   Reply With Quote
Old 03-23-2015, 01:12 PM   #32
Junior Member

Join Date: Apr 2011
Location: Gurnee, IL
Posts: 56
Total Cats: 1
Default

Sweet. Setup is very similar to what I am working on. Looking forward to when I am dyno-tuned in May and I will ping you so we can compare I will only be having it tuned to wastegate limit though for le safety :(
Schadenfreude is offline   Reply With Quote
Old 03-23-2015, 01:33 PM   #33
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,775
Total Cats: 1,106
Default

Quote:
Originally Posted by Schadenfreude View Post
Sweet. Setup is very similar to what I am working on. Looking forward to when I am dyno-tuned in May and I will ping you so we can compare I will only be having it tuned to wastegate limit though for le safety :(
If you have a standalone ECU and big enough injectors, there is no reason to run the SR20 T25 at only wastegate for safety. You can push 15psi with it and a decent tune and not blow up the motor. It will peak around 225ft/lbs of torque no matter how much boost you give it, then fall drastically once past 5k rpms.
shuiend is offline   Reply With Quote
Old 03-23-2015, 02:12 PM   #34
Junior Member

Join Date: Apr 2011
Location: Gurnee, IL
Posts: 56
Total Cats: 1
Default

Quote:
Originally Posted by shuiend View Post
If you have a standalone ECU and big enough injectors, there is no reason to run the SR20 T25 at only wastegate for safety. You can push 15psi with it and a decent tune and not blow up the motor. It will peak around 225ft/lbs of torque no matter how much boost you give it, then fall drastically once past 5k rpms.
Sorry for threadjack, OP.

@shuiend: I will be using a dieselmiata built DIYPNP and rx8 injectors. I worry about running past wastegate because I plan on building my car for HPDE. I need to make sure it can handle 20 minute sessions in Midwest summers. Will you statement still hold true then?
Schadenfreude is offline   Reply With Quote
Old 03-23-2015, 02:22 PM   #35
mkturbo.com
iTrader: (24)

shuiend's Avatar

Join Date: May 2006
Location: Charleston SC
Posts: 13,775
Total Cats: 1,106
Default

Quote:
Originally Posted by Schadenfreude View Post
Sorry for threadjack, OP.

@shuiend: I will be using a dieselmiata built DIYPNP and rx8 injectors. I worry about running past wastegate because I plan on building my car for HPDE. I need to make sure it can handle 20 minute sessions in Midwest summers. Will you statement still hold true then?
I would get on a dyno and do a good number of runs. See what power differences you make going from 10-12-15psi. The SR20 T25 just starts blowing hot air around 12-14psi and you will probably find that you don't make to much more power above that. I know way back in 2008 or so at a MT.net dyno day I did a few runs with spikes up to 16-18psi I believe and realized more boost was not making much more power. For track use in a hot environment I would probably stick to 10-12psi just to keep intake temps down.

If you are on the dyno, I would tune higher, then just turn down boost for the track.
shuiend is offline   Reply With Quote
Old 03-29-2015, 07:51 PM   #36
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

OP Delivers. Here are my runs at Hershey Park autox. Sadly I am now slower than I was before I turbo'd. Could be a ton of things, lack of skill, soft spring rates, 205 tires, lack of skill.... Still had a blast and was way more fun than N/A

gr4v3r is offline   Reply With Quote
Old 04-05-2015, 08:57 PM   #37
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

interior view of my wife and my best runs from today and last week. The wheel shot is the same as last week.

gr4v3r is offline   Reply With Quote
Old 04-06-2015, 12:14 PM   #38
Junior Member

Join Date: Apr 2011
Location: Gurnee, IL
Posts: 56
Total Cats: 1
Default

Lookin solid man. What are you running for suspension/tires?
Schadenfreude is offline   Reply With Quote
Old 04-06-2015, 04:28 PM   #39
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

Quote:
Originally Posted by Schadenfreude View Post
Lookin solid man. What are you running for suspension/tires?
Wheels are 15x8 konig wide opens with 205 bfg rivals and suspension is 7/6 tein flex. I am upgrading to 700/400 xidas and 225 tires this month though.
gr4v3r is offline   Reply With Quote
Old 04-19-2015, 10:08 PM   #40
Junior Member
Thread Starter

Join Date: May 2014
Posts: 154
Total Cats: 4
Default

I have been having a ton of fun but am having trouble getting the power down at the autox. Currently I have running a RB front sway bar, stock rear, 15x8 +20 wheels on 205 BFG rivals. Is there anyone following this with a similar setup that has some advice?

Is 220 trq too much for a 205 street tire or do I just need to learn to use them? I am getting spanked by the STS guys. Is it worth going up to a 225 street tire or will it not make a huge difference unless I make the jump to R Comps?
gr4v3r is offline   Reply With Quote
